- Page 1 ROTISSERIE • PRODUCT GUIDE 5995166 To insure your satisfaction and for follow-up service, register your Rotisserie online at www.grillregistration.com 5995166 • 80016771 • 05-07-08...
-
Page 2: Table Of Contents
WARNING: Indicates an potentially hazardous situation • To order non-warranty replacement parts or accessories which, if not avoided, could result in death or serious please visit us on the web at www.charbroil.com or call injury. 1-800-241-7548 and one of our friendly and knowledgeable agents will be glad to assist you. -
Page 3: Food Safety
Food Safety How To Tell If Meat Is Grilled Thoroughly •Meat and poultry cooked on a grill often browns very fast on the Food safety is a very important part of enjoying the outdoor cooking experience. To keep food safe from harmful bacteria, outside. -
Page 4: Assembly
Rotisserie Brackets Assembly Attach the rotisserie motor side bracket to the right side of the grill bottom using two #10-24x3/8 screws, 5mm lock washer, and 5mm flat washer and from outside and two #10 hex nuts on the inside of the grill bottom show A. Attach the spit rod bracket to the left side of the grill bottom in the same manner show B. - Page 5 Rotisserie Rod Assembly Assembly the two forks to spit rod (forks should be pointing toward each other). Insert thumbscrews into collar and forks. Thumbscrews Thumbscrew Spit rod Collar Fork Fork Rotisserie Assembly On right side of grill, slide rotisserie motor onto motor bracket. Switch should be oriented at top of motor. Insert spit rod fully into motor.
-
Page 6: Warranty
Defective or missing parts subject to this limited warranty will not be replaced without registration or proof of purchase. Register online at http://www.charbroil.com or complete and return via mail the Product Registration Card located on the last page of the Use & Care manual included with this product and retain your sales receipt for proof of purchase. -
Page 7: Registration Card
Please register your product online at: www.grillregistration.com (If you register online, you do not need to send in this registration card.) PLEASE FILL OUT THIS CARD AND RETURN IT WITHIN 10 DAYS OF PURCHASE. FAILURE TO RETURN MAY AFFECT YOUR WARRANTY COVERAGE. FOR WARRANTY SERVICE PROOF OF PURCHASE WILL BE REQUIRED. - Page 8 STOP Should you encounter a problem with our product CALL US FIRST Do not return this product to the store. WE CAN HELP GRILL SERVICE CENTER 1-800-241-7548 HOURS 8AM-6PM EST Mon-Fri Please ensure your warranty registration is complete. Grilling Safety Checklist Read and understand owners manual.
