Page 1: Table Of Contents
WELCOME Congratulations on your choice of PHILIPS satellite receiver. This PHILIPS satellite receiver will allow you to obtain digital satellite programmes and services. Note: - This product is destined for Netherlands. - You need to take out a subscription to access the services of CANALDIGITAAL. Refer to your "Welcome packet".
Page 2 Radio channels _________________23 The channels ___________________24 11.1 List of the channels _____________24 11.2 Altering the numbering of the channels ______________________24 11.3 Adding new channels ____________25 11.4 Removing channels ______________25 11.5 Reinstalling channels _____________25 Subscription programmes (not yet available) ______________________26 Information for subscribers (not yet available) ______________________26 Troubleshooting ________________27 Technical specifications _________29...
Page 3: Safety Instructions
1 Safety instructions All the safety and operating Instructions Mains connection should be read and understood before the Before connecting the receiver to the appliance is operated. mains, check that the mains supply voltage corresponds to the voltage printed on the For best results: rear of the receiver.
Page 4: Product Description
2 Product description 2.1 Front view 2.1.1 Type 1 Front Stand-by button: Switch receiver On or Standby. Reset the receiver, in case of hanging up, after a 5 second keypress. "W": Move down in the screens or select the previous program. "V": Move up in the screens or select the next program Smart card reader.
Page 5: Rear View
"W" button: Channel down. Red LED indicator: Is lit whenever the receiver is operating. Is lit with lower intensity whenever the receiver is in Stand-by mode (*). “V” button: Channel up. (*): Note: if the LED is slowly blinking, it indicates that a free over the air upgrade of your receiver is taking place.
Page 6: The Remote Control
2.3 The remote control SATELLITE MODE (SAT) Standby B On/Off button. Detailed information about a programme or selection of language and/or subtitling. A, B, C, D, E: INFO Function buttons. To display on screen an information bar with information about the programme.
Page 7 At every keypress, lights blink to indicate in which MODE you are in. Note: The Philips batteries supplied with your some keys are shortcut keys to other MODES. In receiver's remote control do not contain this case, the lights do not indicate the current any heavy metals such as Mercury or Nickel MODE! (e.g.
Page 8: Connecting Up The Receiver
3 Connecting up the receiver In this chapter, you will learn how to connect up the Philips digital satellite receiver to your existing equipment, such as a TV or VCR. Satellite dish Scart socket Satellite receiver Mains plug Scart socket...
Page 9: Connecting To Your Hifi/Audio Receiver Equipement (Analogue/Digital)
3.1 Connecting to your HiFi/Audio receiver equipement (Analogue/Digital) Satellite receiver HiFi Depending on your HiFi / Audio receiver equipment, you might have several options to connect your digital receiver. ANALOGUE CONNECTION Connect the L/R audio output sockets to the relevant L/R audio input sockets of your audio equipment using a double CINCH cable (not supplied).
Page 10: Menu Structure
4 Menu structure Setting the time and the channel to tape a video. Setting your favourite channels. MENU Entering and altering of the code and entering of a parental lock. PROGRAMMA'S OPNEMEN VOORKEURKANALEN KIEZEN Installation of the receiver, TV, VCR and modem. CODE EN KINDERSLOT INSTELLINGEN To enter, add and remove channels, to alter the...
Page 11: Installing The Satellite Receiver
5 Installing the satellite receiver How to install your satellite receiver: MENU Turn on your TV. PROGRAMMA‘S OPNEMEN When you power on the box, the front LED will turn on. VOORKEURKANALEN KIEZEN CODE EN KINDERSLOT The Menu screen will then appear. INSTELLINGEN Make sure your smart card is inserted in the slot, the chip KANALEN INSTALLEREN...
Page 12 5.1.1.3 Sound With this option, you choose the standard level of the volume. When you watch a programme, you can adjust the volume with the buttons 5.1.1.4 Duration of the information bar With this option, you choose how long the bar with the name and the number of the selected channel must remain on the screen.
Page 13: Technical Information
Technical information SIGNAALSTERKE From the menu, press 7 (TECHNISCHE INFORMATIE) and then 1 (SIGNAALKWALITEIT). VOEDINGSSPANNING LNB With the screen SIGNAALKWALITEIT, you can find out SIGNAALSTERKE the strength of the signal received. We advise you to have the dish installed by a GOED MATIG professional with suitable measuring devices.
Page 14: Storing The Channels
• If the signal quality is orange, you may change the direction of the dish in order to get a better signal. • If the signal quality is red, the signal is bad. The signal may be bad when: - the dish is not positioned in the right direction. - the connection between the dish and the decoder with the feeder is not well made.
Page 15: The Menu
6 The menu The MENU button MENU With the MENU of your satellite receiver, you can install a lot of useful settings, as for example a parental lock, PROGRAMMA‘S OPNEMEN your favourite channels, using the timer to tape various VOORKEURKANALEN KIEZEN CODE EN KINDERSLOT programmes, etc...
Page 16: Choosing Your Favourite Channels
6.1.3 Watching a locked channel When by flicking you meet a locked channel, you see an information bar in the lower part of the screen. It asks whether you want to access this channel: press OK and enter your pincode. Now, you can watch the programme. Choosing your favourite channels VOORKEURKANALEN INSTELLEN •...
Page 17 6.3.2 Recording a programme that must be PROGRAMMA'S OPNEMEN broadcast later VERGEET NIET DE VIDEORECORDER TE PROGRAMMEREN You first have to preselect your videorecorder on the 24.09 PLANETE 15:10-16:10 24.09 PLANETE 15:10-16:10 decoder. Then you will have to program your digital PROGRAMMA BESCHIKBAAR receiver so that it will switch on at the right time and on PROGRAMMA BESCHIKBAAR...
Page 18: Information About Subscription And Postbox
6.3.4 Recording indications • If the receiver is set on standby, it will automatically switch on on the channel and the time at which you want to record. • If you're watching another channel than this that you want to record, you'll have a reminder. - When you press +, a message appears to set the channels you want to record.
Page 19: Informations Bars (Info)
7 Informations bars (Info) INFO button When you press the INFO button while To see what programme is currently being watching a programme, information bars broadcast on another channel: will appear on the screen. On these bars, - Press the number of a channel or select you will find information about the the channel with the arrow buttons programmes that are being broadcast at...
Page 20: Electronical Programme Guide (Epg)
8 Electronical programme guide (EPG) EPG button 8.1 List of the programmes The electronical programme guide (EPG) Here you find all the programmes in gives you information about all the chronological order. You can consult all the programmes that will be broadcast next programmes up to one week ahead.
Page 21: Films, Sports, Youth, Documentaries And Other Kinds Of Programmes
+ button 8.2 Films, sports, youth, When you press the + button, you will get documentaries and other detailed information about the selected kinds of programmes programmes (summary of the programme, Here you find all the programme which are actors, presentators, directors, selected according to the various kinds: producers,...).
Page 22: Selecting Programmes
- For afternoon programmes between WARNING! 14:00 and 20:00 press the DAG button - When a programme which has been stored is - For evening programmes between broadcast, it will be automatically erased from 20:00 and 24:00 press the AVOND the memory.
Page 23: When You Are Watching A Programme
9 When you are watching a programme 9.1 When you are watching a 9.2 When you consult the EPG programme When you are in the EPG and press the + button, then you get further information The + button about the programme you have selected as When you are watching a programme and well as a summary of the programme, the you press the + button, you can choose a...
Page 24: The Channels
11 The channels 11.1 List of the channels LIJST VAN KANALEN To consult the list of the channels: CANAL DIGITAAL - press MENU and 5. The menu KANALEN INSTALLEREN appears on the screen. RTL4 - select option 1 to consult the LIJST VAN KANALEN. RTL5 SBS6 VERONICA...
Page 25: Adding New Channels
11.3 Adding new channels 11.5 Reinstalling channels It can happen that new digital channels are During the installation, you had to choose launched. You may add these new channels between the numbering of in the memory of your decoder. CANALDIGITAAL or a random numbering. You may add new channels with the menu This option gives you the possibility to go KANALEN INSTALLEREN:...
Page 26: Subscription Programmes (Not Yet Available)
12 Subscription programmes (not yet available) When this manual was being printed, subscription programmes were not yet available. You will be informed when these services will be available. 13 Information for subscribers (not yet available) When you press the SERV button whilst watching one of CANAL DIGITAL the channels of CANADIGITAAL, you may request WELKOM...
Page 27: Troubleshooting
15 Troubleshooting When you have problems with your Philips satellite receiver, first check the following points. PROBLEM POSSIBLE CAUSE ACTION No picture, no sound and no Receiver is not plugged into the Check mains connection. front panel display. mains or is not switched on.
Page 28 PROBLEM POSSIBLE CAUSE ACTION The dish is damaged. Install a new dish. Irregular reception, "mosaic" Wrong cable connections Check all the connections and effect of the picture. (damaged, broken or squashed cables. connectors or wires). A weak signal because the dish Reposition the dish.
Page 29: Technical Specifications
16 Technical specifications This product is in conformity with the requirements of the 95/47/EC and 2002/21/EC directives. Video decoding Application system resources Accessories - MPEG-2 DVB compliant up to Processor clock speed 166 MHz - Remote control: RC2585102/01 MP@ ML SDRAM-CPU/Video-Graphics 8 MB - Scart cable - Video bit rate: up to 15 Mbit/sec...
Page 30: More On Your Remote Control
If you wish to check that you have entered the right code. By default, your remote control is preset to control most of the Philips audio video 1. press digits 1 and 6 simultaneously for more appliances. than 3 seconds. The destination mode lights will blink twice and turn off.
Page 31: Tv Mode (Tv)
17.1 TV mode (TV) Red (A), Green (B), Yellow (C), Blue (D), Teletext on/off. White (E) teletext keys. +/OSD Access or remove on screen display. MENU Toggles between teletext and Opens the menu function TV mode. P+/P- Selects the next/previous Exits the menu function.
Page 32: Vcr And Dvd Mode (Vcr, Dvd)
17.2 VCR and DVD mode (VCR, DVD) (A) G : fast rewind +/OSD (B) K : pause access or remove on screen (C) L : stop display. (D) B : play (E) F : fast forward Displays sub-titles. MENU Opens the menu function. Exits the menu Function.
Page 33: Amplifier/Tuner Mode (Amp)
Mutes the Amplifier/Tuner. Ä Selects the TV picture format Selects the external source of (16/9, 4,3, etc.). the Amplifier. * Only available for philips products. YO U R R E M O T E C O N T R O L 33...
Page 34 Alle fabrikanten hechten veel belang aan de voortdurende verbetering van hun producten. Ofschoon de RC2585100/RC2585102 met de meeste toestellen uit de onderstaande lijst compatibel is, kan Philips niet garanderen dat u hem met alle producten die op de markt verkrijgbaar zijn kunt gebruiken All manufacturers are concerned about the constant improvement of their products.
Page 35 Allstar 0064 0401, 0291, Amplivision 0427, 0244, 0397 0064 Amstrad 0064, 0398, 0245, 0439, 0274, 0101, 0397, 0445 0543, 0036, 0291 CS Electronics 0243, 0245, 0274 Anam National 0677 0274 Anglo 0291 Canton 0245 Anitech 0036, 0064, 0291, 0309 Carad 0637 Ansonic 0397, 0129, 0036, 0064,...
Page 36 Elin 0036, 0064, 0131 Goldline 0364 Elite 0245 Gooding 0514 Elman 0129 Goodmans 0064, 0398, 0036, 0099, Elta 0036 0063, 0245, 0507, 0244, Emco 0274 0401, 0514, 0651, 0291, Emerson 0064, 0114, 0309, 0097, 0362, 0543, 0661 0274, 0398 Gorenje 0397 Emperor 0309...
Page 37 0221, 0539, 0039, 0072, Kyoto 0190 0120, 0128, 0131, 0135, La Sat 0513 0136, 0223, 0243, 0253, Lenco 0131 0265, 0317, 0318, 0319, Leyco 0099, 0064, 0291, 0321, 0321, 0397, 0401, 0583 0606 0291, 0243, 0398 Liesenk & Tter 0064 0190, 0507, 0500, 0235, Liesenkotter 0064, 0354...
Page 38 Myryad 0583 Philips 0039, 0583, 0114, 0064, 0197 0401 0064, 0364, 0398 Phoenix 0243, 0114, 0513 Nakimura 0064, 0401 Phonola 0064, 0039, 0114, 0243 Nakio 0507 Pioneer 0136, 0064, 0513, 0190 Neckermann 0064, 0397, 0438, 0583, Plantron 0036 0114, 0274, 0354, 0445...
Page 39 0321, 0543 Stern 0233, 0286, 0190, 0291, SEI-Sinudyne 0064 0438 Saba 0136, 0223, 0190, 0114, Strato 0064, 0291 0362, 0225, 0652, 0543 Stylandia 0244 Saccs 0265 Sunkai 0637, 0321, 0382, 0482 Sagem 0637, 0482 Sunstar 0064, 0036, 0398 Saisho 0543, 0038, 0244, 0036, Sunwood 0064 0291...
Page 40 Tristar 0245 Akai 0342, 0133, 0068, 0047 Triumph 0373, 0543, 0583 Akiba 0099 Tsoschi 0309 Akura 0099 Uher 0233, 0513, 0064, 0401, Alba 0099, 0047, 0027, 0305, 0445 0379, 0342, 0375 Ultravox 0064, 0129, 0243, 0114, Allstar 0108 0274 Ambassador 0047 Unic Line 0064, 0500...
Page 41 Diamant 0064 Hinari 0031, 0099, 0068, 0379, Dual 0068, 0108, 0305 0267, 0305 Dumont 0108, 0027, 0131 Hisawa 0379 0047, 0267, 0305 Hischito 0072 Elbe 0065, 0305 Hitachi 0069, 0193, 0068, 0267, Elcatech 0099 0027, 0031, 0108 Electrohome 0064 Hornyphone 0108 Electrophonic 0064...
Page 42 0069, 0064, 0267 Shogun 0267 Pentax 0069 Shorai 0031 Perdio 0027 Siemens 0131, 0108, 0222, 0064, Philco 0065, 0099 0374 Philips 0108, 0411 Siera 0108 Phonola 0108 Silva 0064 Pioneer 0108, 0069, 0094 Singer 0072, 0099 Portland 0305, 0047 Sinudyne...
Page 43 Lecson 0723 Technics 0253 Magnavox 0530 Teleavia 0068, 0520 Oritron 0678 Telefunken 0068, 0347, 0348, 0520, Panasonic 0517 0411, 0521, 0607 Philips 0566, 0530 Teletech 0099 Pioneer 0552, 0598 Tenosal 0099 Proline 0679 Tensai 0099, 0031, 0027 Samsung 0600 Thom...
