Samsung SCO-2370 User Manual

High resolution 37x weatherproof camera
Hide thumbs Also See for SCO-2370:
Table of Contents

Advertisement

Quick Links

High Resolution 37x
Weatherproof Camera
User Manual
SCO-2370

Advertisement

Table of Contents
loading

Related Manuals for Samsung SCO-2370

Summary of Contents for Samsung SCO-2370

  • Page 1 High Resolution 37x Weatherproof Camera User Manual SCO-2370...

  • Page 2: Safety Information

    Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but abnormal heat generation or fi re. no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on Securely plug the power cord into the power receptacle.
  • Page 3 This device must accept any interference received including interference that may cause undesired operation. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems CAUTION caused by unauthorized modifi cations or attempted repair.) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of FCC Rules.

  • Page 4: Table Of Contents

    important safety instructions contents Read these instructions. Features INTRODUCTION What’s included Keep these instructions. Component names and functions Heed all warnings. Follow all instructions. Clean only with dry cloth. INSTALLATION & CONNECTION Connecting to Monitor Do not block any ventilation openings. Install in accordance with the manufacturer’s Connecting to Power instructions.

  • Page 5: Introduction

    WHAT’S INCLUDED Check if the following items are included in the product package. 37x Optical Zoom The built-in SCO-2370 optical zoom lens is a highly durable component. It features auto focus, auto iris, and zoom functions. High Resolution By adopting a diagonal 1/4” 410,000 (NTSC) pixel, 470,000(PAL) pixel SONY CCD, the camera produces clear picture quality with a horizontal resolution of 600TV lines for color and a horizontal resolution of 700TV lines for BW mode.

  • Page 6: Component Names And Functions

    introduction COMPONENT NAMES AND FUNCTIONS Back Front ➊ Camera Sunshield ➋ Sunshield adaptor : Fixing the sunshield onto the camera. ➌ Lens ➍ Video Output Terminal to Monitor : Used for monitoring of video output When camera installation. ➎ Function Setup Switch : Display the menu on the screen and move the cursor ➊...

  • Page 7: Connecting To Monitor

    installation & connection introduction COMPONENT NAMES AND FUNCTIONS CONNECTING TO MONITOR Heater & Fan Please connect the video output terminal located on the back of the camera to the monitor. This product is equipped with a built-in heater & fan that helps maintaining operational temperature and humidity.

  • Page 8: Connecting To Power

    There may be some deviation in voltage drop depending on the type of wire and the manufacturer.  When making a control system to control the camera, please use to the protocol(SAMSUNG-T, SAMSUNG-E, PELCO-P, PELCO-D, VICON, PANASONIC, BOSCH, HONEYELL,AD). ...

  • Page 9: Using Coaxial Communications

    installation & connection setup USING COAXIAL COMMUNICATIONS MENU CONFIGURATION Coaxial Communications System MAIN SETUP MENU OSD Control method ● OFF ● ON SSDR CAMERA CONTROLLER ● ATW ● MANUAL ● AWC MENU/ENTER OSD KEY WHITE BAL ● OUTDOOR ● INDOOR UP KEY JOYSTICK UP ●...

  • Page 10: Menu Setup

    MENU SETUP SSDR (Samsung Super Dynamic Range) SSDR illuminates darker spots of an image while retaining the same light level for brighter Use the Function Setup switch within the camera. spots to even out the overall brightness of images with high contrast between bright and dark spots.
  • Page 11 ➊ Color or screen changes unnaturally. ➋ Noise appears in the bright part of the screen. Unlike conventional cameras, the SCO-2370 is designed to deliver a distinctive subject  Since the performance of the BLC function may be affected by the area of the bright part of the and background at the same time, even when the subject is backlight, by using the screen, optimize the installation angle for the best BLC performance.
  • Page 12 setup HLC : Enable the user to change the level, MOTION DETECTION HLC SETUP mask tone area. This product has a feature that will detect movements of objects in 8 different areas on LEVEL MIDDLE the screen. The camera detects an object’s movement by sensing disparity of outline, MASK TONE IIIIIIIIIIIIIIIIIIII IIIIIIIIIIIIIIIIIIIII brightness levels and color.
  • Page 13 setup START ZOOM : By moving the Function - AUTO : Select AUTO and press the ZOOM POS SETUP SMART ZOOM SETUP Setup switch in the ‘SMART ZOOM’ item Function Setup switch to confi rm. Increase or decrease optical zoom to select the zoom position from 1x to 37x START ZOOM to be returned after the ‘SMART ZOOM’...
  • Page 14 setup ZOOM TRACK : Select ‘ON’ for the ZOOM POS INIT : Moves to the controlled FOCUS SETUP FOCUS SETUP ‘SMART ZOOM’ item in the MOTION ZOOM position when the power is truned on MODE AUTO MODE AUTO DETECTION menu and press Function and the initial ZOOM position has been set.
  • Page 15 setup SHUTTER : Control image brightness by EXPOSURE EXPOSURE SETUP adjusting shutter speed. BRIGHTNESS IIIIIIIIII IIIIIIIIIII ➊ Position the indicator over ‘SHUTTER’ using Press the Function Setup switch to access IRIS AUTO MAIN SETUP the main setup menu and then position the the Function Setup switch.
  • Page 16 SSNR3 (Samsung Super Noise Reduction): On screen noise reduction. SPECIAL LOW : Low noise reduction MEDIUM : Medium noise reduction Press the Function Setup switch to access the MAIN SETUP main setup menu and then position the indicator HIGH : High noise reduction SSDR over ‘EXPOSURE’...
  • Page 17 EXT : This mode allows you to apply a desired filter to external signals. of the Function Setup switch. PROTOCOL : Select the communication PROTOCOL. (SAMSUNG-T/PELCO-D/  You cannot control the DAY/NIGHT menu when AGC in the EXPOSURE menu is ‘OFF’.
  • Page 18 setup H-REV : You can fl ip the picture IMAGE SETUP horizontally on the screen. H-REV V-REV : You can fl ip the picture V-REV vertically on the screen. CONTROLLER SHARPNESS SHARPNESS : As you increase this RETURN value, the picture outline becomes stronger and clearer.
  • Page 19 setup USER : Please use this menu item when using USER MONITOR SETUP a monitor other than standard ones.  GAMMA 0.55 You can change the gamma, PED Correcting Mistakes level, and color gain in the sub menus. Move the cursor th ‘CLR’ and press the Function Setup switch to clear the entire entry. PED LEVEL IIIIIIII IIIIIIIIIIIIIIIIIIIII To modify one character, use LEFT or RIGHT to position the cursor above the character to be...

  • Page 20: Troubleshooting

    specifications troubleshooting TROUBLESHOOTING SPECIFICATIONS SCO-2370N SCO-2370P If the product does not function properly, please see the below for trouble shooting. POWER PROBLEM SOLUTION Input Voltage Dual ( AC 24V, DC12V ) Max. 3.8W, 4.8W ( DC12V / AC 24V, Fan & Heater Off ) Nothing appears on the screen.

  • Page 21: Dimension

    On / Off Communication RS-485 & Coaxial Control (Pelco Coaxitron) Protocol Samsung-T, Samsung-E, Pelco-D, Pelco-P, AD, Bosch, Honeywell, Vicon, Panasonic ENVIRONMENTAL -50°C to +50°C / Less than 90% RH (AC 24V) Operating Temperature / Humidity -30°C to +50°C / Less than 90% RH (DC 12V)

  • Page 22: Stw Protocol Command Description

    STW protocol command description STW PROTOCOL COMMAND DESCRIPTION Byte1 Byte2 Byte3 B yte4 ll Byte5 Byte 6 Byte7 Byte8 Byte9 Byte10 Byte11 Command Packet CAM ID HOST ADDR CAMMAND DATA3 DATA4 DATA5 DATA6 CHECKSUM Return Packet CAM ID HOST ADDR CAMMAND DATA3 DATA4...
  • Page 23 STW protocol command description Function Command Packet CAM ID HOST ADDR 00FFh CHECK SUM Return Packet CAM ID HOST ADDR 00FFh CHECK SUM ZOOM Direct Parameter P1, P2 : OPTICAL ZOOM = 0000h~06EAh P3 : DIGITAL ZOOM = ((256*10)/Ratio)-1 EX) D-ZOOM 1.1x : P3 = E7h = ((256*10)/11)-1, Ratio 11 me ans 1.1x. D-ZOOM 2.0x : P3 = 7Fh = ((256*10)/20)-1, Ratio 20 me ans 2.0x.
  • Page 24 STW protocol command description Function Display OSD menu on the screen. Clear OSD menu and save current menu setup. Command Packet CAM ID HOST ADDR 00B1h CHECK SUM OSD Menu On/Off Return Packet CAM ID HOST ADDR 00B1h CHECK SUM Parameter P1 : 00h = ON 01h = OFF...

  • Page 25: Declaration Of Conformity

    MEMO DECLARATION OF CONFORMITY Application of Council Directive(s) 2004 / 108 / EC Manufacturer's Name SAMSUNG TECHWIN CO., LTD Manufacturer's Address SAMSUNG TECHWIN CO., LTD 42, SUNGJU-DONG CHANGWON-CITY, KYUNGNAM, KOREA, 641-716 European Representative Name European Representative Address Equipment Type/Environment CCTV Camera...
  • Page 26 MEMO MEMO...
  • Page 27 MEMO MEMO...
  • Page 28 MEMO MEMO...
  • Page 29 TEL : +82-70-7147-8740~60, FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 1480 Charles Willard St, Carson, CA 90746, UNITED STATES Samsung House, 1000 Hillswood Drive, Hillswood Business Park Tol Free : +1-877-213-1222, FAX : +1-310-632-2195 Chertsey, Surrey, UNITED KINGDOM KT16 OPS www.samsungcctvusa.com TEL : +44-1932-45-5300, FAX : +44-1932-45-5325 www.samsungtechwin.com...
