JVC KD-AVX11 Instructions Manual

Dvd/cd receiver
Hide thumbs Also See for KD-AVX11:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
DVD/CD RECEIVER
RECEPTOR CON DVD/CD
RÉCEPTEUR DVD/CD
KD-AVX11
For canceling the display demonstration, see page 5.
Para cancelar la demonstración en pantalla, consulte la página 5.
Pour annuler la démonstration des affichages, référez-vous à la page 5.
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l'installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
For customer Use:
Enter below the Model No.
and Serial No. which are
located on the top or bottom
of the cabinet. Retain this
information for future
reference.
Model No.
Serial No.
LVT1655-001A
[J]

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-AVX11

Summary of Contents for JVC KD-AVX11

  • Page 1 DVD/CD RECEIVER RECEPTOR CON DVD/CD RÉCEPTEUR DVD/CD KD-AVX11 For canceling the display demonstration, see page 5. Para cancelar la demonstración en pantalla, consulte la página 5. Pour annuler la démonstration des affichages, référez-vous à la page 5. For installation and connections, refer to the separate manual.
  • Page 2 Caution – Pictures may not appear clearly or may move Changes or modifications not approved by JVC could slowly. Pictures may not be synchronized with void the user’s authority to operate the equipment. the sound or picture quality may decline in such environments.

  • Page 3: Table Of Contents

    How to reset your unit Contents INTRODUCTION Playable disc type ......4 Before operating the unit ....5 OPERATIONS • Your preset adjustments (except for the registered Basic operations—Control panel ..7 Bluetooth devices) will also be erased. Basic operations— How to forcibly eject a disc Remote controller (RM-RK241) ..

  • Page 4: Playable Disc Type

    Playable disc type Disc type Recording format, file type, etc. Playable DVD Video (Region Code: 1)* DVD Audio DVD-ROM DVD Recordable/Rewritable DVD Video (DVD-R* /-RW, +R/+RW* DivX/MPEG1/MPEG2 • Compliant to UDF bridge format JPEG • DVD-RAM cannot be played. MP3/WMA/WAV MPEG4 DVD-VR, +VR Dual Disc...

  • Page 5: Before Operating The Unit

    Before operating the unit Cancel the display demonstration and set the clock. (☞ also pages 38 and 39) Indication language: In this manual, English indications are used for purpose of explanation. You can select the indication language on the monitor. (☞ page 39) Setup menu icon AV Menu Setup...
  • Page 6 (twice) Clock Time Set 12Hours/24Hours OSD Clock 1:00AM ¤ fi Return to the <Setup> menu. Select either the 12-hour or 24-hour system. Select <Clock> ]<Time Set>, then 12Hours/24Hours activate the <Time Set> screen. 12 Hours ‹ 24 Hours Set the clock time. Time Set Exit Hours...

  • Page 7: Operations

    Basic operations — Control panel • Turn on the power. Select the source. TUNER = SAT (SIRIUS/XM) = DISC (DVD/VCD/CD) =CD-CH, • Turn off the power [Hold]. iPod, D.PLAYER, or EXT-IN = Bluetooth Phone = • Attenuate the sound (if the Bluetooth Audio = AV-IN =(back to the beginning) power is on).

  • Page 8: Remote Controller (Rm-Rk241)

    EXTRA MONITOR sensor on the unit. Monitor control buttons • DO NOT expose the remote sensor to bright light • Used for a JVC monitor—KV-MR9010, or KV- (direct sunlight or artificial lighting). MH6510. DVD/RECEIVER The unit is equipped with the steering wheel remote control function.
  • Page 9 Dials preset phone number. – Selects a channel if pressed. Enters phone number/PIN code. For Apple iPod/JVC D. player operations: Ends the call for Bluetooth phone operations. (☞ • ∞: Pauses/stops or resumes playback. page 26) • 5: Enters the main menu (then 5 / ∞ / Answers the incoming call for Bluetooth phone 4 / ¢...

  • Page 10: Listening To The Radio

    Listening to the radio Band Preset No. POWER]ON ☞ TUNER FLAT page 35 FM1 Preset1 ABC Radio 87.5 MHz 3: 45 ☞ Tuner indicators Assigned station name ( page 36). If no name is assigned, “No Name” appears. Select “TUNER.” Ÿ...

  • Page 11: Fm Station Automatic Presetting

    Tuning in to stations with FM station automatic presetting sufficient signal strength —SSM (Strong-station Sequential Memory) This function works only for FM bands. Once you have activated this function (selected This function works only for FM bands. <Local>), it always works when searching for FM You can preset six stations for each band.

  • Page 12: Manual Presetting

    Manual presetting Selecting preset stations Ex.: Storing FM station of 92.5 MHz into preset On the remote: number 4 of the FM1 band. DISC + TOP M MENU Tune in to a station you want to preset. SHIFT ENTER No Name 92.5 MHz Store On the unit:...

  • Page 13: Disc Operations

    Disc operations The disc type is automatically detected, and playback starts automatically (for some discs: automatic start depends on its internal program). If a disc does not have any disc menu, all tracks in it will be played repeatedly until you change the source or eject the disc.
  • Page 14 While playing the following discs, press • Each time you press the button, playback picture and disc information screens appear alternately. • For discs except DVD and VCD: The control screen appears on the connected external monitor. (☞ page 50) ☞...
  • Page 15 ☞ page 35 FLAT 0:45:38 Disc Title Artist Name Current Track Title 3:45 4 ¢ Press: Select track Disc title/Artist name/Track Track no./Playing time Hold: Reverse/forward search title (only for CD Text) Audio format ☞ (MP3/WMA/WAV) page 35 FLAT 0:45:38 Current Folder Name Current File Name.mp3 3:45...

  • Page 16: Selecting Playback Modes

    Selecting playback modes You can use only one of the following playback Mode modes—Intro/Repeat/Random. All Off Intro Ex. To select Track Repeat Repeat Random AV Menu Repeat Setup Enter Track Folder AV Menu When one of the playback modes is selected, Mode Enter the corresponding indicator lights up on the disc...

  • Page 17: Selecting Tracks On The List

    Selecting tracks on the list Prohibiting disc ejection If a disc includes folders, you can display the Folder/ You can lock a disc in the loading slot. Track (File) Lists, then start playback. Folder List My Best Cinema NO EJECT? Pops EMERGENCY EJECT? My Best2...
  • Page 18 Operations using the remote controller—RM-RK241 EXTRA MONITOR : Stop playback. MODE ASPECT MENU : Pause (Frame by frame playback if pressed during pause). : Start playback. DVD / RECEIVER ZOOM Reverse/forward search* . (No sound can be heard.) SOURCE (Slow motion* during pause.
  • Page 19 : Stop playback. DIRECT : Shows the current file until you change it. Select track (within the same folder). : Start playback (Slide show: each file is shown for a few seconds.). DIRECT DIRECT : Select track. Select folder. : Select folder. : Select aspect ratio.
  • Page 20 Enlarging the view (Zoom in) While pausing... During moving picture playback... ZOOM 1 ZOOM 2 ZOOM OFF ZOOM 1 ZOOM 2 ZOOM 3 ZOOM 4 ZOOM OFF ZOOM 6 ZOOM 5 To cancel zoom, select “ZOOM OFF.” Move the enlarged portion.
  • Page 21 On-screen bar Information T02-C03 TOTAL 1:25:58 DVD -V C. RPT Operation TIME TITLE CHAP Above example is of DVD Video. Items shown on the bar vary due to the disc type. 1 Disc type 6 Playback status 2 • DVD: Audio signal format Play •...

  • Page 22: Using The Bluetooth® Devices

    Using the Bluetooth® devices — Cellular phone/audio player For Bluetooth operations, it is required to connect the Bluetooth Adapter (KS-BTA200) to the CD changer jack on the rear. • Refer also to the instructions supplied with the Bluetooth Adapter and the Bluetooth device. •...
  • Page 23 Connecting a special device Operate the target Bluetooth device. Enter the same PIN code (as entered in the above Perform steps 1 to 3 on page 22, then... step) on the device to be connected. NEW DEVICE Dial Menu Message Now connection is established and you can use the Open Search...

  • Page 24: Using The Bluetooth Cellular Phone

    Deleting a registered device Perform steps 2 and 3 on page 22, then... • Select <Delete Pair>, then <Yes>. Select “Bluetooth Phone” or “Bluetooth Audio,” then select a registered device you want to delete. Using the Bluetooth cellular phone Connected device Bluetooth icon lights up when the adapter is connected.

  • Page 25: Making A Call

    Select the method to make a call. When a Text Message comes in... If the cellular phone is compatible with Text Message and <Message Info> is set to <Auto> (☞ page 46), the unit rings and “Receiving Message” appears on the monitor to inform you of the arrival of the message.
  • Page 26 Presetting the phone numbers • Preset List can also be accessed through <AV Menu> = <List>. You can preset up to six phone numbers. Display the phone number you want to AV Menu preset by using one of <Dial Menu> items. Jack Store 12312341234...

  • Page 27: Using The Bluetooth Audio Player

    • The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Victor Company of Japan, Limited (JVC) is under licence. Other trademarks and trade names are those of their respective owners.

  • Page 28: Listening To The Cd Changer

    5 ∞ Press: Select folder (MP3 only) Hold: Display Disc List It is recommended to use a JVC MP3-compatible CD • While playing an MP3 disc, you can select and changer with your unit. start playing a track in the disc using the Lists: •...
  • Page 29 Selecting playback modes You can use only one of the following playback Mode modes—Intro/Repeat/Random. All Off Intro Ex. To select Track Repeat Repeat Random AV Menu Repeat Setup Enter Track Disc AV Menu When one of the playback modes is selected, the Mode corresponding indicator lights up on the monitor.

  • Page 30: Listening To The Satellite Radio

    Before operating, connect either one of the following (separately purchased) to the CD changer jack on the rear of this unit. • JVC SIRIUS radio DLP—Down Link Processor, for listening to the SIRIUS Satellite radio. • XMDirect Universal Tuner Box—With a JVC Smart Digital Adapter (XMDJVC100: not supplied), for listening to the XM Satellite radio.
  • Page 31 DISP —artist name/song name/ : Switch to display the preset list, program information composer name (only for SIRIUS Satellite radio). Preset no. Channel no. ☞ SIRIUS/XM Band page 35 POWER]ON FLAT XM1 Preset1 01ch Category Name Channel Name 3: 45 Signal strength Category name Channel name...

  • Page 32: Storing Channels In Memory

    Storing channels in memory Selecting on the lists You can preset six channels for each band. You can select a channel using one of the following Ex.: Storing a channel into preset number 5 lists—Preset list/Category list/Channel list. Tune in to a channel you want. AV Menu FLAT 3Bch...

  • Page 33: Listening To The Ipod/D. Player

    • To resume, press again. It is required to connect the interface adapter (KS- Confirm the selection. PD100 for Apple iPod or KS-PD500 for JVC D. player) to the CD changer jack on the rear. Repeat steps 2 and 3 to select a track.

  • Page 34: Listening To Other External Components

    You can connect an external component to the CD changer jack on the rear using the Line Input Adapter—KS-U57 (not supplied) or AUX Input Adapter—KS-U58 (not supplied). • You can also connect the JVC PnP (SIRIUS radio tuner) using the JVC SIRIUS radio adapter—KS-U100K. ☞...

  • Page 35: Settings

    Sound equalization POWER]ON Edit Store 60.0 Hz Storing your own adjustment Selecting sound mode You can store your adjustment into User1, User2, and User3. AV Menu Repeat steps ~ and Ÿ, then... Setup Enter Equalizer Flat Hard Rock Ÿ R&B Equalizer menu icon Jazz Exit...

  • Page 36: Assigning Titles To The Sources

    Assigning titles to the sources Press: Change character set Hold: Erase title POWER]ON Title Entry Station Name ABC Radio A a 0 Á á Store DISP You can assign titles as follows. FM/AM stations Up to 16 characters—up to 30 Mode Mono stations.

  • Page 37: Menu Operations

    Menu operations Setup Equalizer Sound POWER]ON AV Menu Setup Enter Mode List Bluetooth Ex. Changing the <High Pass Filter> setting Sound Fader/Balance AV Menu Volume Adjust Subwoofer High Pass Filter Crossover Through Setup Enter • For some items, repeat this steps to set the Non-available items will be displayed being sub-items.
  • Page 38 Initial: Underlined Setup Menu items Selectable settings, [reference page] Demonstration Off : Cancels. On : Activates the demonstration on the monitor. Wall Paper You can select the background picture of the monitor. Crystal-Blue, Crystal-Pink, Crystal-Green, Wave-Yellow, Wave-Green, Metal-A, Metal-B, Ball-A, Ball-B, Ball-C, Clown Fish, Simple-Red, Simple-Orange, Simple-Bluegreen, Simple-Blue Scroll Off : Cancels.
  • Page 39 Menu items Selectable settings, [reference page] Aspect* You can change the aspect ratio of the picture. Aspect ratio of incoming signal 16:9 Full : For 16:9 original pictures Auto : • For “DISC”: Aspect ratio is automatically selected to match to the incoming signals. •...
  • Page 40 Menu items Selectable settings, [reference page] Menu Language Select the initial disc menu language; Initial English (☞ also page 53). Audio Language Select the initial audio language; Initial English (☞ also page 53). Subtitle Select the initial subtitle language or erase the subtitle (<Off>); Initial Off (☞...
  • Page 41 Menu items Selectable settings, [reference page] D. Audio Output Select the signal format emitted through the DIGITAL OUT (optical) terminals. (☞ also page 52) PCM Only : Select this when connecting an amplifier or a decoder incompatible with Dolby Digital, DTS, or MPEG Audio, or connecting to a recording device.
  • Page 42 : CD changer, iPod, D. player, etc. ☞ [28, 33] Changer/iPod/D. Player* External Input : Any other than the above. ☞ [34] • For connecting the Bluetooth adapter/JVC DLP/XMDJVC100, this setting is not required. It is automatically detected. Beep Off : Cancels.
  • Page 43 Equalizer Menu items Selectable settings, [reference page] ☞ [35] Flat/Hard Rock/R&B/Pop/Jazz/ Dance/Country/Reggae/Classic/ User1/User2/User3 Sound Menu items Selectable settings, [reference page] Fader/Balance Adjust fader—speaker output balance between the front and rear Adjusts fader speakers. • Upmost—front only • Downmost—rear only When using a two-speaker system, set the fader to the center (00). Adjust balance—speaker output balance between the left and right speakers.
  • Page 44 Mode Menu items Selectable settings, [reference page] Only for FM. (Off, On), ☞ [10] Mono Only for FM. (DX, Local), ☞ [11] DX/Local Only for FM. ☞ [11] Only for FM/AM stations, “AV-IN,” and “EXT-IN.” ☞ [36] Title Entry All Off/Intro/Repeat/Random Only for disc playback and iPod/D.
  • Page 45 Menu items Selectable settings, [reference page] Message Only for the device connected for “Bluetooth Phone.”* You can read a message from the following message histories. Unread : Messages you have not read. Read : Messages you have read. Unsent : Messages you have not sent. Sent : Messages you have sent.
  • Page 46 Adjust microphone volume connected to the Bluetooth adapter. 01, 02, 03 Version* The Bluetooth software and hardware versions are shown. Only for the device connected for “Bluetooth Phone.” Not selectable for “NEW DEVICE.” If you wish to receive more information about Bluetooth, visit our JVC web site.

  • Page 47: References

    Maintenance How to clean the connector To keep discs clean Frequent detachment will deteriorate the connectors. A dirty disc may not play correctly. To minimize this possibility, periodically wipe the If a disc does become dirty, wipe it with connectors with a cotton swab or cloth moistened with a soft cloth in a straight line from center alcohol, being careful not to damage the connectors.

  • Page 48: More About This Unit

    More about this unit Ejecting a disc General • If the ejected disc is not removed within 15 seconds, Turning on the power the disc is automatically inserted again into the • By pressing SRC (source) on the unit, you can also loading slot to protect it from dust.
  • Page 49 Playing DivX files Playing MP3/WMA/WAV files • This unit can play back DivX files with the extension • This unit can play back files with the extension code code <.divx>, <.div>, <.avi> (regardless of the <.mp3>, <.wma>, or <.wav> (regardless of the letter case—upper/lower).

  • Page 50: Current Folder

    Control screen • The following control screens appear only on the TIME 00:14 T. RPT external monitor. Track : 6 / 14 DivX/MPEG1/MPEG2/JPEG/MP3/WMA/WAV Cloudy Fair Hail Indian summer Track Information Rain T. RPT TIME 00:00:14 Album Shower Four seasons Snow Folder : 2 / 3 Track : 6 / 14 (Total 41)

  • Page 51: Menu Settings

    <4:3 Letterbox> for some discs. Satellite radio operations • You can also connect the JVC SIRIUS radio PnP (Plug and Play), using the JVC SIRIUS radio adapter, KS- U100K (not supplied) to the CD changer jack on the rear.

  • Page 52: Characters Shown On The Monitor

    Sound signals emitted through the rear terminals Through the analog terminals (Speaker out/LINE OUT) 2-channel signal is emitted. When playing multi-channel encoded disc, multi-channel signals are downmixed. • DTS sound cannot be reproduced. Through the DIGITAL OUT terminal Digital signals (Linear PCM, Dolby Digital, DTS, MPEG Audio) are emitted. •...
  • Page 53 Language codes (for DVD/DivX language selection) Code Language Code Language Code Language Code Language Code Language Afar Persian Greenlandic Occitan Sesotho Abkhazian Finnish Cambodian (Afan) Oromo Sundanese Afrikaans Fiji Kannada Oriya Swahili Ameharic Faroese Korean (KOR) Panjabi Tamil Arabic Frisian Kashmiri Polish Telugu...

  • Page 54: Troubleshooting

    Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • No sound comes out of the speakers. • Adjust the volume to the optimum level. • Check the cords and connections. •...
  • Page 55 Symptoms Remedies/Causes • Disc cannot be played back. • Change the disc. • Record the tracks using a compliant application in the appropriate discs. (☞ page 4) • Add appropriate extension codes to the file names. • Noise is generated. The track played back is not a playable file format.
  • Page 56 Symptoms Remedies/Causes • “No Disc” appears on the monitor. Insert a disc into the magazine. • “No Magazine” appears on the monitor. Insert the magazine. • “No Files” appears on the monitor. Disc does not include playable files. Replace the disc with playable files.
  • Page 57 Symptoms Remedies/Causes • The iPod/D. player does not turn on or does • Check the connecting cable and its connection. not work. • Charge the battery. • For D. player: Update the firmware version. • The sound is distorted. Deactivate the equalizer either on this unit or the iPod/ D.

  • Page 58: Specifications

    Specifications Power Output: 20 W RMS × 4 Channels at 4 Ω and ≤ 1% THD+N Signal-to-Noise Ratio: 70 dB (reference: 1 W into 4 Ω) 4 Ω (4 Ω to 8 Ω allowance) Load Impedance: Equalizer Control Range: Frequencies: 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz Level:...
  • Page 59 Signal Detection System: Non-contact optical pickup (semiconductor laser) Frequency Response: DVD, fs=48 kHz: 16 Hz to 22 000 Hz DVD, fs=96 kHz: 16 Hz to 22 000 Hz VCD/CD: 16 Hz to 20 000 Hz Dynamic Range: 93 dB Signal-to-Noise Ratio: 95 dB Wow and Flutter: Less than measurable limit...
  • Page 60 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Still having trouble?? USA ONLY Call 1-800-252-5722 http://www.jvc.com We can help you! EN, SP, FR 1206MNMMDWJEIN © 2006 Victor Company of Japan, Limited...
  • Page 61 NEGATIVA. Si su vehículo no posee type d’alimentation, il vous faut un convertisseur de tension, que vous voltage inverter is required, which can be purchased at JVC car audio este sistema, será necesario un inversor de tensión, que puede ser dealers.
  • Page 62 JVC car audio dealer or a company supplying kits. instalación, consulte con su concesionario de JVC de equipos de audio d’installation, consulter votre revendeur d’autoradios JVC ou une •...
  • Page 63 JVC. de JVC de equipos de audio para automóviles. • It is recommended to connect to the speakers with maximum • Il est recommandé de connecter des enceintes avec une puissance •...
  • Page 64 ENGLISH ESPAÑOL FRANÇAIS Typical connections Conexiones tipicas Raccordements typiques Before connecting: Check the wiring in the vehicle carefully. Antes de la conexión: Verifique atentamente el conexionado del Avant de commencer la connexion: Vérifiez attentivement le câblage Incorrect connection may cause serious damage to this unit. vehículo.
  • Page 65 Cable remoto (Azul con rayas blancas) Au fil de télécommande de l’autre appareil Fil d’alimentation à distance (Bleu avec bande blanche) Rear speakers Altavoces posteriores Enceintes arrière SUBWOOFER JVC Amplifier Amplificador de JVC JVC Amplificateur KD-AVX11 JVC Amplifier Amplificador de JVC Subwoofer JVC Amplificateur Subwoofer...
  • Page 66 • Turning on/off the unit can also turns on/off the JVC PnP. XMDJVC100 (not supplied). También podrá conectar la PnP JVC a través de este receptor utilizando el adaptador para radio SIRIUS JVC, KS-U100K • Para escuchar la radio satelital XM, también puede conectar el Sintonizador universal (no suministrado).

Table of Contents
