O w n e r's Manual
This Product is Brought to You by:
Thane International, Inc. La Quinta, CA 92253
Thane Direct Canada, Inc. Toronto, Ontario
Thane Direct UK Limited Admail ADM3996 London W1T 1ZU
www.thane.com
www.thanefitness.com
Making Fitness Fun!
®
(9/02)
OWNER'S
MANUAL
Safety Notice..............2
Assembly & Usage 3-7
Exploded View ..........8
Parts List ..............9-10
Exercise Computer ..11
IMPORTANT!
Please read all instructions
carefully before using this
product. Retain this manual
for future reference.
TYPE:BK2080
Thane International, Inc.
La Quinta, CA 92253
Thane Direct Canada, Inc.
Toronto, Ontario
Thane Direct UK Limited
Admail ADM3996 London W1T 1ZU
www.thane.com
