Summary of Contents for AIPTEK PENCAM TRIO HD
-
Page 2: Safety Notice
Welcome: Dear user, thank you for purchasing this product. We hope that our commitment to delivering a reliable and well-engineered product will provide you with an excellent user experience and years of hassle-free use. Safety Notice: 1. Warranty will be voided if the camera is dropped, punctured or disassembled. 2. -
Page 3: Getting Started
Getting Started Product overview Microphone LED light/strobe Mirror (for self-portrait) Lens Clip Strap holder Mode switch: Camcorder ( MP3 player ( Camera ( Power button OLED display Directional button LED indicator Playback button OK (Record/Shutter) button Delete button HDMI output TV-out/Earphone connector USB port Tripod connector... -
Page 4: Product Operations
Product operations Product introduction This digital camcorder comes with the following features: • Ultra slim, pen-like compact design offers maximum mobility and freedom • 1280 x 720 (720P) HD high definition video resolution up to 30fps • Multi-functions: digital camcorder, digital still camera, MP3 player •... -
Page 5: Powering On/Off
Powering on/off Hold the Power button down for 1 second to turn on, or to turn off the unit. Note: If the camcorder fails to turn on after pressing the Power button, please recharge the battery first. If an AV cable or earphone connector is plugged in upon powering on, you will be prompted to select a connection option. - Page 6 Recording/Reviewing a video To record a video: Recordable time Power on the camcorder and switch to camcorder mode ( Press the OK (Record) button to start recording. Use the directional button up/down to zoom in/out. LED light To stop recording, press the OK (Record) button again. Zoom bar Note: Press the directional button to the right to enable the LED Light Battery life when operating in a dark environment. To review a video: In camcorder preview mode, press the Playback button and the last recorded video will play automatically.
-
Page 7: Deleting Files
Deleting files Press the Playback button while in preview mode. Use the directional button left/right to select the file you want to delete and press the Delete button. To delete the current file: Use the directional button left/right to select “Yes” and press the Playback button. To delete all files: Use the directional button left/right to select “All” and press the Playback button. Then select “Yes” and press the Playback button to confirm. Delete files To leave the deletion screen, press the Delete button. MP3 player To listen to music, you must copy MP3 files from your PC first. - Page 8 PC connection When the camcorder is powered on and connected to a PC via the accessory USB cable, the system enters USB Slave mode. The internal memory is then treated as a removable disk on the PC, allowing you to directly copy or delete files stored in the camcorder.
-
Page 9: Troubleshooting
Addendum Troubleshooting Problem Cause Solution The camcorder is frozen The camcorder Press and hold down the and unresponsive. has encountered a power button to force a software failure. manual shut down to reset the camcorder. Battery life indicator Icon Description Full battery life Moderate battery life Low battery life... -
Page 10: Battery Life
Battery life Still picture Video clip Number of shots Recording time (minutes) * shoot every 30 seconds * resolution set to HD 30f (1280x720 ) ** alternate flash (CIPA standard test method) *** resolution set to 5M (2592x1944) Note: This table is for reference purposes only and is approximate. Actual battery life may vary slightly due to numerous factors including recharge level. -
Page 11: Specifications
HDMI-out / Composite AV-out (NTSC/PAL system supported) Power Save Mode 3 min. Battery Built-in Li-Polymer battery (950mAh) * Model dependent. Note: Specifications are subject to change without notification. For additional information and the Video User’s Manual, please visit the PenCam HD website at: http://www.aiptek.com/PenCamHD... - Page 12 82-496-90020v1.0...
