Page 1: User Manual
Deluxe Model: S-889NR USER MANUAL Please ensure that this manual is read and understood before using the scooter. Nov 2011... -
Page 2: Table Of Contents
Contents Page Introduction Intended Use Technical Specification Feature Guide Safety Advice Adjustments Tiller angle Seat swivel / removal Arm width adjustment Arm angle adjustment Seat height adjustment Tiller Controls Brake Release / Freewheel Operation Starting to Drive ... -
Page 3: Introduction
Congratulations on your purchase of the SHOPRIDER Deluxe scooter. This scooter incorporates comfort and style with the latest in technology. The SHOPRIDER Deluxe can be used in confined spaces both indoors and out. Direct drive rear transaxles and electromagnetic brakes give a safe and efficient ride. -
Page 4: Feature Guide
Feature Guide Deluxe 1. Tiller control head 2. Detachable padded swivel seat with fold down back 3. Head light 4. Tiller angle adjustment lever (5 position) 5. Chrome front bumper 6. Pneumatic wheels with non-marking tyres 7. Anti-tip wheels... -
Page 5: Safety Advice
Safety Advice Read this manual carefully before using your scooter Turn the power off when transferring to and from the scooter Select a slow speed when going down gradients (max 8°) or over uneven ground Keep your feet on the scooter whilst driving ... -
Page 6: Adjustments
Adjustments Fig 1 Tiller Angle Adjustment (Fig. 1) On the left hand side at the base of the tiller is a red adjustment lever. Push the lever in to release the pin and select the required tiller angle. Release the lever to re-locate the pin into one of the five angle positions. -
Page 7: Arm Angle Adjustment
Continued….. Armrest Angle Adjustment (Fig. 3) Flip up the armrests to allow access to the adjustment screw and locknut. Unscrew the locknut and screw the bolt in or out to achieve the desired angle and re-tighten the locknut. The scooter will be delivered with the arms parallel to the floor. -
Page 8: Tiller Controls
Tiller Controls (Fig. 5) Fig 5 Speed Control Charging Socket Battery Level Indicator On/Off Key Switch Horn Button Light Switch Thumb Lever Controls Thumb Lever Controls The thumb lever controls the reverse and forward motion of the scooter. Pressing the right lever will drive the scooter forward, pushing the left lever will reverse the scooter. -
Page 9: Brake Release / Freewheel Operation
Continued….. On/Off Key Switch Insert the key supplied with the scooter and turn clockwise. The battery gauge needle will move. There may be a slight delay before the thumb levers operate as the controller checks the scooters circuits. Never leave the key in the switch unattended to prevent unauthorised use. -
Page 10: Starting To Drive
Continued….. Caution! Never leave the scooter unattended whilst in freewheel mode as it will roll away down an incline. ‘Freewheel’ mode should only be used in an emergency to move the scooter due to power failure. NEVER move the scooter in this mode whilst it is occupied. Starting to Drive Getting Started Note: You must fully charge the batteries prior to first use (see ‘Batteries... -
Page 11: Ramps / Slopes
Your scooter will perform well over many surfaces. However, avoid long grass, loose gravel, sand and mud and ice. Transport and Storage The SHOPRIDER Deluxe is designed to be quickly and easily disassembled without tools into sections for transportation and storage: Guidelines for Disassembly... -
Page 12: Batteries And Battery Charger
Continued….. The SHOPRIDER Deluxe is now separated into components for easy transportation or storage. Assembly is the reverse of the procedure. Batteries and Battery Chargers Batteries The Deluxe is supplied with two maintenance free, sealed lead acid AGM batteries. These are fitted under the seat on the scooter. -
Page 13: Maintenance 13
DO NOT put the scooter through an automated car wash or similar. Routine Maintenance We recommend that the following checks be carried out on a periodical basis by a qualified person: SHOPRIDER Scooters Maintenance and Inspection ... -
Page 14: Troubleshooting
Continued….. Wheels and Tyres The wheels of your scooter have split rims. This allows any punctures to be repaired easily. To change the wheels, remove the centre bolt and slide the wheel off its axle. Ensure that when refitting the wheel the retaining nut is fitted with a locking washer or the screw threads are treated with ‘Loc-tite’... -
Page 15: Check List
Note: Should your scooter fail to operate after checking these possible problems, consult your local SHOPRIDER dealer immediately. Further Information Safety Information Regarding Electromagnetic Interference (EMI) Scooters and powerchairs are designed to operate under certain conditions. - Page 16 Continued….. Product Stability Scooters and powered wheelchairs are designed to allow the user flexibility of movement in restricted areas. Driving at maximum speed and attempting sharp turns can create a situation where the product becomes unstable. Therefore it is essential that the user pay attention the guidance set out in this manual.
- Page 17 Continued….. Emergency Procedures Should your scooter behave erratically or become unresponsive whilst driving, release the wig-wag lever so it may return to it’s neutral position and switch off the power at the key / switch. These procedures will stop the scooter and activate the braking system, preventing any further uncontrolled manoeuvres.
- Page 18 Notes...
- Page 19 Notes...
- Page 20 York Road, Bridgend Industrial Estate, Bridgend CF31 3TB Tel: 01656 674488 Fax: 01656 674499 Email: sales@romamedical.co.uk www.romamedical.co.uk Shoprider reserve the right to change specifications without prior notice Manufactured by: Phisiang Machinery MFG. CO. LTD No. 108 Hsin-He Rd, Hsin-Feng Hsiang, Hsinchu County, Taiwan...
