CE770RQ (Remote Unit)

LED
B
(Blue)
Link / G
(Orange/Green)
Remote / R
(Red)
Lights to indicate that the BLUE color will be selected to adjust the
delay time of the BLUE color.
Flashes to indicate that the BLUE color is selected and the
pushbutton can be used to adjust the delay time of the BLUE color.
Lights Orange to indicate that the connection to the Local unit is ok.
Flashes Orange when there is a problem with the connection to the
Local unit and the "Remote LED (Red)" is off.
Lights Green to indicate that the GREEN color will be selected to
adjust the delay time of the GREEN color.
Flashes Green to indicate that the GREEN color is selected and the
pushbutton can be used to adjust the delay time of GREEN color.
Lights Red to indicate that the remote console is active.
Turns off when the local console is active.
Remote LED (Red) flashes when Auto Mode.
Lights Red to indicate that the RED color will be selected to adjust
the delay time of the RED color.
Flashes Red to indicate that the RED color is selected and the
pushbutton can be used to adjust the delay time of RED color.
Both Red and Green light to indicate that the Video Compensation
will be selected to adjust.
Both Red and Green flash to indicate that the Video Compensation
is selected and the pushbutton can be used to adjust the Video
Compensation.
Chapter 3. Operation
Indication
21
