Denon DRA-F107 Owner's Manual
Am-fm stereo receiver
Hide thumbs
Also See for DRA-F107:
- Bedienungsanleitung (30 pages) ,
- Service manual (84 pages) ,
- User manual
Related Manuals for Denon DRA-F107
Summary of Contents for Denon DRA-F107
- Page 1 AM-FM STEREO RECEIVER DRA-F107 Owner’s Manual Bedienungsanleitung Manuel de l’Utilisateur Manuale delle istruzioni Manual del usuario Gebruiksaanwijzing Bruksanvisning...
- Page 2 ENGLISH DEUTSCH FRANCAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA IMPOTANT SAFETY SAFETY PRECAUTIONS CAUTION: INSTRUCTIONS To completely disconnect this product from the mains, disconnect CAUTION the plug from the wall socket outlet. Read these instructions. The mains plug is used to completely interrupt the power supply to RISK OF ELECTRIC SHOCK Keep these instructions.
- Page 3 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANCAIS DEUTSCH ENGLISH NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO / NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA ANGÅENDE ANVÄNDNINGEN CAUTION: • The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, tablecloths, curtains, etc.
- Page 4 Het inpakmateriaal van dit product is recycleerbaar en kan opnieuw gebruikt worden. Er wordt verzocht om zich van elk afvalmateriaal te ontdoen volgens de plaatselijke voorschriften. DENON EUROPE Volg voor het wegdoen van de speler de voorschriften voor de verwijdering van wit- en bruingoed op.
-
Page 5: Table Of Contents
ENGLISH n Contents Playback About System Functions Preparations ················································································12 Device supporting system connections (sold separately)·······22 Getting Started Turning the Power On ································································12 What you can do with the system functions····························22 Operations During Playback ······················································12 Making system connections ······················································22 Accessories ····················································································2 Adjusting the Master Volume ·····················································12 System Functions ·······································································23 Cautions on Handling ···································································2... -
Page 6: Accessories
ENGLISH Getting Started Thank you for purchasing this DENON product. To ensure proper Cautions on Handling Cautions on Installation operation, please read this owner’s manual carefully before using the product. • Before turning the power switch on Note: After reading them, be sure to keep them for future reference. -
Page 7: About The Remote Control Unit
When the DCD-F107 CD player (sold separately) is connected to the DRA-F107 by system cable, the remote control signals re- ceived by the DRA-F107 are transmitted to the DCD-F107 to oper- ate the DCD-F107. For instructions on system connections, see “About System Functions”... -
Page 8: Part Names
ENGLISH Part Names For buttons not explained here, see the page indicated in parentheses ( ). Display Front Panel Tone indicators ··········································· (13) Information display SDB: Lights when the super dynamic bass Various information is displayed here. function is set to “ON” . Remote control signal reception indicator TONE: Lights when the tone (bass/treble) is Timer operation indicator... -
Page 9: Remote Control Unit
ENGLISH Part Names Remote Control Unit Buttons for operating the receiver Buttons for operating Control Dock for iPod (ASD-11R or ASD- 3N/3W, sold separately) Amplifier operations Control Dock for iPod operations The buttons below can be operated regardless of the currently set function. The buttons below can be operated when the function is set to “iPod”... - Page 10 USB port on the DCD-F107 which is Number buttons (0 ~ 9, +10) in turn connected by system cable to the PROG/DIRECT button DRA-F107 can be operated with the buttons RANDOM button below. CD play/pause button (CD Number buttons (0 ~ 9, +10) Folder mode select button ...
-
Page 11: Connections
ENGLISH Connections Preparations DAB (for UK Model Only) Antenna terminals For details about system connections, also see “About System Functions” ( v page 22). n Installing the DAB indoor antenna AM/FM DAB station reception (vpage 17). NOTE The AM and FM reception sensitivity depends on the place the antenna •... -
Page 12: Cables Used For Connections
Carefully check the left (L) and right (R) channels and + (red) and – Audio cables (black) polarities on the speakers being connected to the DRA-F107 , and be sure to interconnect the channels and polarities correctly. Analog connections (stereo) -
Page 13: Connecting A Subwoofer
( v page 22 “About System Functions”) • Playback with an MC cartridge is not possible with the DRA-F107 . When using an MC cartridge, use a commercially available head amplifier or booster transformer. -
Page 14: Ipod
Components Wait until all connections have been completed before connecting the power cord. Use a DENON control dock for iPod (ASD-11R or ASD-3N/3W, sold separately) to connect the iPod to the DRA-F107 . Tape deck n For Continental model only... -
Page 15: Once Connections Are Completed
Symbols used to indicate buttons in this manual Do not unplug the power cord before the power indicator turns off (24-Hour Display) and the DRA-F107 enters Standby mode. Button located on both the main unit and the remote control • Only use the supplied power cord. -
Page 16: Preparations
ENGLISH Playback Preparations Operations During Playback Symbols used to indicate buttons in this manual Button located on both the main unit and the remote control BUTTON unit Turning the Power On Adjusting the Master Volume <BUTTON> Button only on the main unit [BUTTON] Button only on the remote control unit ON/STANDBY... -
Page 17: Adjusting The Tone
ENGLISH Operations During Playback TUNER Playback Turning the Sound Off Temporarily Adjusting the Tone Tuning in Broadcast Stations (Muting) SDB/TONE to select the tone parameter to be Connect the antenna beforehand (vpage 7). adjusted. [MUTE] Press TUNER Press to select the reception band. The “MUTE ON”... -
Page 18: Automatically Presetting Fm Stations (Auto Preset)
ENGLISH TUNER Playback About the FM Broadcast Reception Status Display Symbols used to indicate buttons in this manual When the reception band mode is set to “FM AUTO”, the “ST” Broadcast stations whose antenna signal are weak cannot be preset Button located on both the main unit and the remote control indicator lights when a stereo broadcast is tuned in. -
Page 19: Presetting Fm/Am Stations Manually
ENGLISH TUNER Playback Operating using the PRESET/TUNING RDS Search Presetting FM/AM Stations Manually buttons on the main unit Use this function to automatically tune to FM stations that provide Up to 40 stations (total for FM and AM) can be preset. the RDS service. -
Page 20: Tp Search
RDS broadcasts. Press TUNER Clock Time (CT) Select “TP SEARCH” using , then press Use this to correct the time of the clock on the DRA-F107 . [MENU] q During CT reception, press [ENTER/MEMO] The “AUTO Adj mm:ss” is displayed. [ENTER/MEMO] to set. -
Page 21: Listening To Dab/Dab+ (For Uk Model Only)
Up to 40 stations can be preset (in addition to FM/AM stations). • codec used. DAB: MPEG2 DAB+: MAEG4 (AAC) Auto Scannig Broadcast Stations • The DRA-F107 can receive both DAB and DAB+ broadcasts. Connect the antenna beforehand. [MENU] Press during DAB reception. Select “TUNER SETUP” using , then... -
Page 22: Switching The Reception Information For The Currently Tuned In Dab Station
ENGLISH Listening to DAB/DAB+ (For UK Model Only) Switching the Reception Information for Making the DAB Settings Symbols used to indicate buttons in this manual the Currently Tuned in DAB Station [DAB/RDS] Button located on both the main unit and the remote control Press during DAB reception. -
Page 23: Ipod ® Playback
® Playback With the DRA-F107 , you can listen to music on an iPod. It is also possible to operate the iPod from the main unit or remote control unit. When using a Control Dock for iPod (ASD-11R, ASD-3N or... -
Page 24: Recording
Button only on the main unit First connect the device from which you want to record to the [BUTTON] Button only on the remote control unit DRA-F107 (vpage 9, 10). The everyday timer, once timer and sleep timer can be set. <SOURCE> [SOURCE]... -
Page 25: Setting The Sleep Timer
[ENTER/MEMO] [ p ] [ENTER/MEMO] timer, then press Pause the track you want to play, and keep the power on for DENON “ ” S O U R C E S E L E C T S O U R C E S E L E C T •... -
Page 26: Other Functions
This stores the settings as they were directly before the standby NOTE mode was set. Be sure to plug the DRA-F107’s power cord into a wall power outlet. When the power is turned back on, the settings are restored to as they were directly before the standby mode was set. -
Page 27: System Functions
When the power • Connection of the power cord is • Check that the power plugs are devices turns on and the DRA-F107’s function switches is turned on, the faulty. securely inserted into the DRA- power indicator F107’s AC inlet and the wall... -
Page 28: Specifications
ENGLISH GRemote Control UnitH Specifications Symptom Cause Countermeasure Page Set does not work • Batteries are worn. • Replace with new batteries. properly when • You are operating outside of the • Operate within the specified Receiver section remote control specified range. - Page 29 D&M Holdings Inc. Printed in China 5411 10282 101D...
