- Page 1 DIGITAL PICTURE FRAME WITH MP3 PLAYER 7” 4120 Ver1(01-06 ) User’ s Manual NEED HELP? FOR TECH SUPPORT CONTACT www.edgetechcorp.com/support...
-
Page 2: Table Of Contents
Table of Contents Repeat Mode..Error! Bookmark not defined. MAIN FEATURES..........3 References ....Error! Bookmark not defined. TV Type .....Error! Bookmark not defined. Video Output..Error! Bookmark not defined. PRECAUTIONS & MAINTE NANCE ....4 OSD LANG ..Error! Bookmark not defined. Default ....Error! Bookmark not defined. - Page 3 Introduction Thank you for purchasing the Digital Picture Frame by EDGE ™! We know you will enjoy this innovative display method of all your digital memories! Before operating the unit, please read this manual thoroughly and retain it for future reference.
-
Page 4: Main Features
Chapter 1 Main Features Displays digital pictures (JPEG) without a computer. Simply insert a compatible memory card into the digital frame to show photos, play MP3 music or supported video files (memory card not included). Compatible memory cards include SD Memory Cards, MultiMedia Card (MMC), Memory Stick, Memory Stick Pro, IBM Microdrive , &... -
Page 5: Precautions & Maintenance
Always use the eject buttons on the memory storage cards slots to remove the memory storage cards. l Do not open the case of the Digital Picture frame. There is a risk of electric shock, and there are no user serviceable parts inside. Opening the case will void your warranty. -
Page 6: Getting Started
Chapter 3 Getting Started 1. Adjust the Digital Picture Frame bracket on the back to the widest degree for propping stability then p lug the power adapter into an electrical outlet. Note: There are three stages for the Digital Picture Frame bracket, Please adjust it to at least first stage for propping stability before initial use 2. -
Page 7: Inserting Memory Cards
Note: The digital picture frame will ONLY recognize digital pictures stored in JPEG format. Digital pictures stored in other formats will be ignored by the device. If the card is inserted correctly and you have more than one supported media file on the card you will see the following screen. - Page 8 See “Advance Settings” section for more control settings. Caution If you connect the Digital Picture Frame to a European-standard TV, please switch the Digital Picture Frame to PAL mode by pressing MENU (7) and then NTSC/PAL key (19) on the remote control. Note: 1.
-
Page 9: Control Location
Control Locations Power on/off (13) Brightness Right (14) Mute Left (15) Next Enter (16) Previous Down (17) FF(Fast Forward) (18) FR(Fast Rewind) Menu (19) NTSC/PAL PIC+MP3 (20) Picture Rotate Setup (21) Zoom in/out (10) Volume up/down (22) Stop (11) Info (23) Play/pause (12) Repeat... -
Page 11: Listening To Mp3 Music
5. Press Next (15) or Previous (16) key to select a different music file. See “Advance Set tings” section for more control settings. Watching video The Digital Picture Frame supports the following video formats: Motion JPEG (avi): video format used by most digital cameras MPEG-I MPEG-II (stored on CF Card only. -
Page 12: Viewing File Structure
Enter button. TV Connection Use the supplied S-video out cable to connect the digital picture frame to a TV. Turn off both the frame and the TV before you make the connection. -
Page 13: Speaker Connection
Connect speakers to the earphone jack located on the right side of the picture frame. Mounting the Digital Picture Frame The 7mm mounting hole on the back of the Digital Picture Frame as shown below is used to m ount your Digital Picture Frame. When wall mounted, make sure the mounting hole aims at the #6 screw then mount the picture frame directly and slightly. -
Page 14: Advanced Settings
Chapter 4 Advanced Settings Display Pictures with MP3 music 1. On the main Menu, select the Photo folder. 2. Press PIC.+MP3 button (8) on the remote control to display photos and play music . 3. Press PIC.+MP3 button (8) again to stop playing. Setup Menu Press the SETUP button on the remote control to enter the Setup Menu. -
Page 15: Repeat Mode
Manual: Turns OFF the auto slideshow function. Select this option if you want to manually select the picture to display. Auto: The Digital Picture Frame will automatically enter the Slideshow mode when you select any picture. The default slideshow mode is “ Auto” . -
Page 16: Tv Type
Set the TV type to Multi System, NTSC or PAL. The default TV type is “NTSC”. OSD LANG Select On-screen Display Language. The default language is “English”. Default This option will reset all the settings to the original manufacturer’s default. Ver: xxxxx Show the firmware version of the Digital Picture Frame. -
Page 17: Troubleshooting
If you don’t see the lit screen, check if the power is connecte d to the Digital Picture Frame and make sure it is securely attached. No Start-up screen. - Page 18 Use the remote control to select the memory card. What is the maximum picture size The Digital Picture Frame is able to display pictures up to 12 the digital frame can display? Mega Pixels.
-
Page 19: Specifications
Specifications Display: 7” Active Matrix LCD. I/O: Earphone Jack Speakers (stereo) S-Video (NTSC/PAL) Remote Control: Remote Controller Power: AC Adapter; Input 100-240V; Output 12V, 1.5A Certification CE, FCC, UL Mechanical Dimension: 2 10 x 150 x 45mm (L x W x H) Weight: 600g Environmental Operating Ranges Operation: 0 ~ 35? , Humidity 0 ~ 85%...
