Specifications
Operating mode
• Multiservice concurrent 802.11a/n + b/g/n
• Backward compatible with 802.11a/b/g and mixed mode
802.11a/b/g/n deployments
• Air Monitor, Remote AP, Spectrum Monitor, Secure enterprise mesh
Radios
• Multifunction, dual radio capable of 2.4-GHz and 5-GHz operation
• Both 802.11n radios implement 3x3 MIMO with up to three spatial
streams, providing up to 450Mbps data rate per radio
• Maximum ratio combining (MRC) for improved receiver performance
• Maximum transmit power per radio: 23dBm
Wireless radio specifications
• AP type: Dual-radio, dual-band 802.11n indoor
• Supported Frequency Bands (country-specific restrictions apply):
- 2.400 - 2.4835 GHz
- 5.150 - 5.250 GHz/5.250 - 5.350 GHz/5.470 - 5.725 GHz/5.725 -
-----5.850 GHz with Dynamic Frequency Selection (DFS) capability
• Available Channels: Controller-managed, dependent upon
configured regulatory domain Supported Radio Technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n: Orthogonal frequency division multiplexing (OFDM)
- 802.11n: 3x3 MIMO with up to three spatial streams
• Supported Modulation Types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
• Maximum Transmit Power (aggregated for three active transmit chains):
- 2.4 GHz: up to 23 dBm (limited by local regulatory requirements)
- 5 GHz: up to 23 dBm (limited by local regulatory requirements)
• Association Rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: MCS0—MCS23 (6.5 Mbps to 450 Mbps)
• 802.11n High-Throughput (HT) Support: HT 20/40
• 802.11n Packet Aggregation: A-MPDU, A-MSDU
Antenna
• IAP-134: Three RP-SMA antenna interfaces for external dual-band
antennas. External Antenna selection guide is available from Dell
representative or downloadable from Dell.com/Wireless
• IAP-135: Six internal downtilt omni-directional antennas; three
per frequency band
- 2.4 to 2.5 GHz/3.5 dBi
- 5.150 to 5.875 GHz/4.5 dBi
Power
• 48 V DC 802.3af PoE or 802.3at PoE+
• 12 V DC external AC supplied power (adapter sold separately)
• Maximum power consumption: 15 watts
Interfaces
• Network:
- 1 x 10/100/1000Base-T Ethernet (RJ45),auto-sensing, MDI/MDX
• Power:
- 1 x DC power connector
• Other:
- 1 x RJ45 console interfaceMounting
• Standard:
- Wall mounting using built-in mount features
- Recessed ceiling-tile rail mounting using one of two adapters
supplied with the AP (9/16" and 15/16" rails)
Mechanical
• Dimensions/Weight:
- 170 mm x 170 mm x 45 mm (6.69" x 6.69" x 1.77")
- Unit: 760 g (1.68lb)
Environmental
• Operating:
- Temp: 0° C to +50° C (+32° F to +122° F)
- Relative humidity: 5 to 95% non-condensing
• Storage and Transportation Temperature Range:
- Temp: -40° C to +70° C (-40° F to +158° F)
Certifications/Regulartory
• Wi-Fi certified: 802.11a/b/g/n
Product meets EMC, safety and wireless standards of over 50
countries inclusive of; USA (FCC), Canada, EU, Japan, Korea,
China. For more country-specific regulatory information, and
approvals, please see your Dell representative.
Minimum OS Version
6.1.2.3 - 2.0.0.3
Extended Life Warranty*
