REPLACEMENT PARTS DIAGRAM
HEATER CORE ASSEMBLY (PLEASE SPECIFY 480 VOLTS ON ANY ORDERS)
FOR ED039
FOR ED048
FOR ED054
FOR ED063
THERMOSTATIC
PCB
PART# EX100CV-480V
SLAVE PART #
EX100S-480V
PART# EX3491
PART# EX2880
PART# EX2560
PART# EX2194
10
35.5 Ohms
28.8 Ohms
25.6 Ohms
21.9 Ohms
TRIAC
PART# EX18
L1
Contactor part #
EX08002-01
(480 volts)
