_ Model : CLIO CUP _ Serial number : xxx The manufacturer plate “RENAULT SPORT” is located on the rear transversal tube The roll cage is homologated by the Automobile Sport French Federation : FFSA (Federation Française du Sport Automobile) B.1.2 CHASSIS NUMBER...
An engraving is proof that the part is genuine, but does not confirm that it complies with regulations. absence engraving(s) regarded as technical non-compliance and event organizers may require that the Renault Sport engraving : part(s) in question be replaced.
98CUP_2013 Release B.5 HANDLING B.5.1 LIFTING The vehicle has to be raised at the front and rear using a jack. The jack must be positioned beneath the pad provided (in Yellow on the following picture) B.5.2 TOWING The vehicle may be towed from the front or the rear using the strap provided : REAR FRONT When not used, the strap is tucked in the bumper...
98CUP_2013 Release B.6.2 STEERING WHEEL SWITCH PANEL : XAP_STER98 Button Action Short press Long press 1st Long press : light goes ON Light management LIGHT Head light flasher (Front headlight and rear) 2nd long press : light goes OFF 1st Long press : permanent wiper on only 1 go/back wiper, return to one constant speed (maximum speed) WIPER...
98CUP_2013 Release Area “MAP” “DRY” or “WET” depending on the engine MAP selected on the Facia switch panel Area “GEAR” Corresponds to Gearbox ratio engaged (R, N, 1, 2, 3, 4, 5, 6) Area “RPM” Current engine speed in RPM (“xxxx RPM”) Area “RAIN LIGHT”...
98CUP_2013 Release B.6.3.1.3 RIVER PAGE CIRCUIT MAP PAGE Refer to chapter G-Softwares to upload a circuit map (.bmp) NOTE: This map is just for information and is not dynamic B.6.3.1.4 1 : E IAGNOTIC PAGE NGINE DIAGNOSTIC Areas “Events”, “Default” and “rain light”, remains the same as DRIVERS PAGE. NOTE: When an alarm appears in the area “default”, the corresponding value by default is displayed in blue, red or orange.
Page 15
98CUP_2013 Release Engine diagnostic parameters : (see also chapter C-Engine) Values expected Engine Values expected when Engine is Signification when engine is parameters running - Idle > 1200rpm - WaterT<50°c : RPM limiter = 4500rpm Engine revs - 50°c<Water T<100°C, RPM limiter = 6500rpm - WaterT >...
Page 16
98CUP_2013 Release B.6.3.1.5 2 : G IAGNOSTIC EARBOX DIAGNOSTIC (see also chapter D-Transmissions) Areas “Events”, “Default” and “rain light”, remains the same as DRIVERS PAGE. Values expected Gearbox Values expected when Engine is Signification when engine is parameters running - Idle > 1200rpm - WaterT<50°c : RPM limiter = 4500rpm Engine revs - 50°c<Water T<100°C, RPM limiter =...
Page 17
98CUP_2013 Release B.6.3.1.6 3 : B IAGNOSTIC RAKE CHASSIS DIAGNOSTIC Brake/ Values expected Values expected when Engine is chassis Signification when engine is running parameters Front BP Font brake pressure From 0 to more than 100b Rear BP Rear Brake pressure From 0 to 40b (depends on rear brake pressure limiter setup) % of brake pressure Balance...
Page 18
98CUP_2013 Release B.6.3.1.8 5 : CBNT 1/2 : S IAGNOSTIC DIAGNOSTIC PAGE TATES Every indication corresponds to the XAP CBNT pinout and shows the state (ON/OFF) of each Pin. Please refer to chapter F- wiring for more details. When XAP Master relay is ON : - All values from the first column must be “ON”...
98CUP_2013 Release B.6.3.2 Changing pages The pages of the display may be changed by pressing on the push button ‘PAGE” of the steering wheel Pressing briefly on this button (one second) moves the display in the 3 driver pages Pressing this button for longer (more than 2 seconds) moves the display from driver pages to diagnostic pages Pressing briefly on the button moves the display in the 5 diagnostic pages You can return to the driver pages by pressing the button for a longer period (more than...
98CUP_2013 Release B.6.3.4 Alarms displayed on the dashboard Alarms are generated by the ICD depending on engine / gearbox sensors values sent by the ECU for display. The alarm/default message disappears only when the problem is solved. Even if the problem is solved, till the power supply is ON : The top left and/or right LEds alarms remain ON The letter in the area “event”...
Page 21
98CUP_2013 Release B.6.3.4.2 ECONDARY ALARMS ATEGORY All non Cat A alarms are classified in the category B. They are clearly displayed to the driver, but he is still able to drive normally (the dashboard information remains normally readable). A message is displayed in the Area “Default” In addition with the message displayed, the corresponding alarm LED becomes ORANGE: - 1 Right HS column (gearbox diagnostic) - 1 Left HS column (engine diagnostic)
98CUP_2013 Release " Manifold P - def" 1 Left Electrical fault on manifold sensor + value in Blue "Oil P - def" 1 Left Electrical fault on oil pressure sensor + value in Blue "Water T - def" 1 Left Electrical fault on water temperature sensor + value in Blue “Throt FBW * def”...
98CUP_2013 Release B.6.4.3 Turning off the engine Flick the “IGNITION” switch to the down (OFF) position NOTE : The vehicle’s electrics remain switched on Except in the event of an emergency stop, it’s strictly not advised to turn off the engine using the power supply switch (OFF button).
98CUP_2013 Release If the pit limiter is activated while the current speed is > 60kph, all the Shiftlights flashes together till the vehicle reach 60kph (at this particular moment, all shiftlights remains ON but without flashing) NOTE: The speed limiter does not control the brakes. Consequently, the vehicle speed will only slow rapidly to 60kph if the driver applies the brakes.
98CUP_2013 Release B.6.4.8 Resetting the chassis sensors This procedure allows to reset the following sensors: - Front Brake pressure sensor - Rear brake pressure sensor - Steering angle sensor It is necessary to make a reset if one of the following sensor has been changed or if the brake circuit has been bleeded.
98CUP_2013 Release B.6.5 ADJUSTING THE DRIVING POSITION B.6.5.1 Adjusting the steering wheel To optimize the driving position, the height and deepness of the steering wheel may be adjusted by unlocking the steering column lever (1) NOTE : After having steering column position, adjustment lever must...
98CUP_2013 Release B.6.6 VENTILATION The vehicle has 4 air vents: 1 in the middle of the facia : activated by the “heat” switch on facia switch panel 2 on the roof: air coming though the roof hatch Ventilation on the facia upper surface: View from below: The air comes from the electric ventilator and is directed by the lower duct to the facia Electric...
98CUP_2013 Release Roof ventilation: Roof hatch Inside aerator B.7 SAFETY EQUIPMENT B.7.1 FIRE EXTINGUISHER Each vehicle is equipped with an extinguishing system targeting the driver compartment and the engine compartment. The fire extinguisher is located behind the driver’s seat. 2 mandatory screwed clamps Control unit (3 positions)
Page 29
98CUP_2013 Release The system consists of 3 jets: In the driver compartment right hand side of the steering wheel 2 in the engine compartment 1 pointing on the Turbo : 1 pointing on the air intake : Use: The extinguishing system can be triggered in 2 different ways: The driver presses on the button “Fire Ext”...
Page 30
98CUP_2013 Release You must fit the wiring of the white connector directly on the plastic windscreen lower grid using a tyrap® as indicated below: The fire extinguisher is controlled by a deported control unit fitted on the central tunnel. A specific fire extinguisher loom allows to link this control unit + fire extinguisher to the chassis loom.
98CUP_2013 Release Checks - Extinguisher cylinder compliance check: The following information must be clearly visible on the cylinder: Serial number. Capacity and weight or volume of extinguisher product. Activation date or date of last system check. Date of next service. Homologation number.
98CUP_2013 Release B.7.4 PASSENGER SEAT A passenger seat may be installed on Clio Cup using the supports with part ref 8201380465 and 8201380466 The seats references remain the same as for driver side. Fasteners: Seat supports on the chassis: Screws CHC10-25 77 11 156 901 Contact washer Ø10X22 77 11 156 926...
B.9.1 LIST OF MARKED PARTS All parts that are specific to Clio Cup are engraved. The following genuine Renault parts are identified either by a “Renault Sport” laser engraving or by a hologram (its presence is compulsory with NO PAINT)
Page 34
98CUP_2013 Release FL Mudguard 98CUP00075 FR door 98CUP00076 FL dooe 98CUP00077 Front cover 98CUP00080 Rear cover 98CUP00081 Fuel pump / gauge 98CUP00093 RR door 98CUP00078 RL door 98CUP00079 Gearbox command rod 809mm 8201418758 Gearbox command rod 784mm 8201418759 Rear camber/alignment shim 10’ 8201369770 Rear camber/alignment shim 20’...
Should any component become faulty or its condition deteriorate before reaching the stated mileage, please contact Renault Sport Technologies. NOTE : This list may not under any circumstances be considered to be part of the manufacturer’s warranty.
