Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
FJR1300A
1MC-28199-E0

Advertisement

Table of Contents
loading

Related Manuals for Yamaha FJR1300A

Summary of Contents for Yamaha FJR1300A

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FJR1300A 1MC-28199-E0...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product: Kind of equipment: IMMOBILIZER...
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your FJR1300A. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10133 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 FJR1300A OWNER’S MANUAL ©2012 by Yamaha Motor Co., Ltd. 1st edition, June 2012 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Accessory box ......3-36 General maintenance and Adjusting the headlight beams ..3-37 lubrication chart ......6-4 DESCRIPTION ........2-1 Handlebar position ....... 3-37 Removing and installing panels ..6-8 Left view ..........2-1 Opening and closing the cowling Checking the spark plugs ....
  • Page 7 TABLE OF CONTENTS Checking and lubricating the brake and clutch levers .....6-27 Checking and lubricating the centerstand and sidestand ..6-28 Lubricating the rear suspension ...6-29 Lubricating the swingarm pivots ...6-29 Checking the front fork ....6-29 Checking the steering ....6-30 Checking the wheel bearings ..6-30 Battery ..........6-31 Replacing the fuses ......6-32 Headlight bulb ......6-34...

  • Page 8: Safety Information

    SAFETY INFORMATION ● EAU1028A Never operate a motorcycle with- yourself conspicuous appears to out proper training or instruction. be very effective in reducing the Take a training course. Beginners chance of this type of accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are respon- tified instructor.
  • Page 9 SAFETY INFORMATION ● Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- accidents do not even have a cur- ●...
  • Page 10 SAFETY INFORMATION ● Avoid Carbon Monoxide Poisoning Do not run engine outdoors where When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind: monoxide, a deadly gas. Breathing car- a building through openings such ●...
  • Page 11 Yamaha accessories, which are avail- formed to your vehicle that change any lightweight as possible and able only from a Yamaha dealer, have of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...

  • Page 12: Specifications

    SAFETY INFORMATION ● tor and may limit control ability, Check that the fuel cock (if therefore, such accessories are equipped) is in the “OFF” position not recommended. and that there are no fuel leaks. ● Use caution when adding electri- ●...

  • Page 13: Description

    DESCRIPTION EAU10410 Left view 1. Coolant reservoir (page 6-16) 9. Shift pedal (page 3-25) 2. Accessory box (page 3-36) 10.Engine oil filler cap (page 6-12) 3. Front fork spring preload adjusting bolt (page 3-39) 11.Engine oil filter cartridge (page 6-12) 4.

  • Page 14: Right View

    DESCRIPTION EAU10420 Right view 1. Storage compartment (page 3-35) 9. Brake pedal (page 3-26) 2. Fuel tank cap (page 3-29) 10.Shock absorber assembly rebound damping force adjusting knob (page 3-41) 3. Front fork spring preload adjusting bolt (page 3-39) 11.Rear brake fluid reservoir (page 6-24) 4.

  • Page 15: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 10,11 1. Clutch lever (page 3-25) 9. Brake lever (page 3-26) 2. Rear view mirror (page 3-39) 10.Throttle grip (page 6-19) 3. Left handlebar switches (page 3-23) 11.Grip warmer (page 3-12) 4. Clutch fluid reservoir (page 6-24) 12.Headlight beam adjusting knob (page 3-37) 5.

  • Page 16: Instrument And Control Functions

    ● the vehicle along with all three keys to Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red ● Do not place any key close to bow for driving.

  • Page 17: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS ● Keep other immobilizer system EAU10472 EAU26811 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillights, li- ference. cense plate light and auxiliary lights come on, and the engine can be start- ed.
  • Page 18 INSTRUMENT AND CONTROL FUNCTIONS To lock the steering To unlock the steering ECA11020 NOTICE Do not use the parking position for an extended length of time, other- wise the battery may discharge. 1. Push. 1. Push. 2. Turn. 2. Turn. 1.

  • Page 19: Indicator Lights And Warning Lights

    ” circuit monitoring the engine. If this oc- 5. Neutral indicator light “ ” EAU11123 curs, have a Yamaha dealer check the 6. High beam indicator light “ ” Oil level warning light “ ” self-diagnosis system. (See page 3-21 7.
  • Page 20 “ON”, or if the or if the warning light remains on, have ther of the above occurs, or if the light remains on, have a Yamaha deal- a Yamaha dealer check the electrical warning light does not come on at er check the electrical circuit.

  • Page 21: Cruise Control System

    50 km/h (31 TIME TR or if the indicator light remains on, have mi/h) and 180 km/h (112 mi/h). a Yamaha dealer check the electrical EWA16340 WARNING circuit. When the key is turned to “OFF” and 30 ●...
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Activating and setting the cruise You can also manually increase your control system traveling speed using the throttle. After 1. Push the cruise control power you have accelerated, you can set a switch “ ” located on the left han- new cruising speed by pushing the dlebar.
  • Page 23 INSTRUMENT AND CONTROL FUNCTIONS speed will return to the previously set Automatic deactivation of the cruise stalls, or the sidestand is lowered, then cruising speed. The “SET” indicator control system the “ ” indicator light will go off (the light will come on. The cruise control system for this mod- “SET”...

  • Page 24: Multi-Function Meter Unit

    12 3 9 10 working correctly, the “ ” indicator light will flash. If this occurs, turn the cruise control system off and have a Self-diagnosis device GEAR Yamaha dealer check it. A.TEMP ˚C C.TEMP ˚C ECA11590 GEAR TIME TRIP...
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS ● settings while riding can distract the a drive mode display (which shows Tachometer operator and increase the risk of an the selected drive mode) accident. ● a function display (which shows the selected function) ● an information display (which The select switch “...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS ● Fuel meter segments start flashing. If this occurs, Select the transmission gear that have a Yamaha dealer check the elec- is appropriate for the vehicle trical circuit. speed. Eco indicator Transmission gear display GEAR A.TEMP GEAR C.TEMP...
  • Page 27 INSTRUMENT AND CONTROL FUNCTIONS Drive mode display Function display Adjusting the grip warmer This vehicle is equipped with grip warmers, which can only be used when the engine is running. There are 4 grip warmer settings. GEAR A.TEMP ˚C Setting Display GEAR C.TEMP...
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS ● ● If the handlebar grip or throttle an estimated traveling range dis- “TRIP-1” and “TRIP-2” show the dis- grip becomes worn or damaged, play tance traveled since they were last set stop using the grip warmers and ●...
  • Page 29 INSTRUMENT AND CONTROL FUNCTIONS TRIP-F → Display–1 → Display–2 → Elapsed time display: Display–3 → TRIP-F ● –9 °C will be displayed even if the TIME TRIP ambient temperature falls below 0:06 To reset a tripmeter, use the select –9 °C. switch to select the information display ●...
  • Page 30 If there is a malfunction, “– –.–” will average amount of fuel necessary be continuously displayed. Have a to travel 100 km. Yamaha dealer check the vehicle. ● For the UK only: The “MPG” dis- The selected information display can-...
  • Page 31 Have a tion allows you to switch “Unit” the display units between Yamaha dealer check the vehicle. push and hold the menu switch kilometers and miles. “MENU” again for at least 2 seconds. When kilometers are se-...
  • Page 32 INSTRUMENT AND CONTROL FUNCTIONS 4. Use the select switch to highlight This function allows you to “All Reset” reset all items, except the “Middle” or “Low”, and then Grip Warmer odometer and the clock. change the setting using the same Hi g h procedure that was used for the Adjusting the temperature levels of the...
  • Page 33 INSTRUMENT AND CONTROL FUNCTIONS Checking and resetting “TIME–2” and 3. While the selected item is flashing, “TIME–3” push the “RESET” button for at MENU 1. Use the select switch to highlight least 2 seconds. Grip Warmer “Time Trip”. 4. Push the menu switch “MENU” to Maintenance Time Trip return to the setting mode menu.
  • Page 34 INSTRUMENT AND CONTROL FUNCTIONS Unit Unit Unit Km or mile Km or mile Km or mile km/L or L/100km km/L or L/100km km/L or L/100km km/L km/L km/L Selecting the display items ● For the UK: Continue with the fol- When “km”...
  • Page 35 INSTRUMENT AND CONTROL FUNCTIONS Adjusting the meter panel brightness 1. Use the select switch to highlight Display Display-1 “Brightness”. Display-1 Display-2 MENU Grip Warmer Display-3 C.TEMP Maintenance Time Trip TIME TRIP Unit Display Brightness 3. Use the select switch to highlight 5.
  • Page 36 INSTRUMENT AND CONTROL FUNCTIONS Setting the clock 5. Use the select switch to set the 1. Use the select switch to highlight minutes. All Reset “Clock”. 6. Push the menu switch “MENU” to return to the setting mode menu. MENU Resetting all of the display items Grip Warmer 1.

  • Page 37: D-Mode (Drive Mode)

    (See page error codes, note the code number, and from starting. 3-24 for an explanation of the drive then have a Yamaha dealer check the mode switch.) vehicle. 2. If the engine starts, turn it off, and...

  • Page 38: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS This mode allows the rider to enjoy EAU1234B Right Handlebar switches smooth drivability from the low-speed range to the high-speed range. Left Sports mode “S” This mode offers a sportier engine re- sponse in the low- to mid-speed range compared to the touring mode.
  • Page 39 INSTRUMENT AND CONTROL FUNCTIONS position. To cancel the turn signal EAU12733 EAU54220 Hazard switch “ ” Select switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- This switch is used to perform selec- turned to the center position.

  • Page 40: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12830 Make sure that the appropriate setting EAU12871 Clutch lever Shift pedal on the adjusting dial is aligned with the arrow mark on the clutch lever. The clutch lever is equipped with a clutch switch, which is part of the igni- tion circuit cut-off system.

  • Page 41: Brake Lever

    EAU54530 Brake lever Brake pedal The brake lever is located on the right The Yamaha ABS (Anti-lock Brake side of the handlebar. To apply the front System) features a dual electronic con- brake, pull the lever toward the throttle trol system, which acts on the front and grip.

  • Page 42: Traction Control System

    ABS is oper- ating. However, special tools are EWA15431 WARNING required, so please consult your Yamaha dealer when performing The traction control system is not a this test. substitute for riding appropriately for the conditions. Traction control...
  • Page 43 INSTRUMENT AND CONTROL FUNCTIONS proach surfaces that Turning on/off the traction control slippery with caution and avoid es- system pecially slippery surfaces. EWA15440 WARNING When the key is turned to “ON”, the Be sure to stop the vehicle before traction control system automatically making any setting changes to the turns on.

  • Page 44: Fuel Tank Cap

    Leaking fuel is a fire hazard. on after resetting, the motorcycle may still be ridden; however, have a 1. Unlock. Yamaha dealer check the motorcycle 2. Fuel tank cap lock cover as soon as possible. To open the fuel tank cap...

  • Page 45: Fuel

    EWA15151 refueling, be sure to insert the WARNING Your Yamaha engine has been de- pump nozzle into the fuel tank filler Gasoline is poisonous and can signed to use regular unleaded gaso- hole. Stop filling when the fuel cause injury or death.

  • Page 46: Fuel Tank Breather/Overflow Hose

    INSTRUMENT AND CONTROL FUNCTIONS EAUB1300 EAU13445 ECA10701 Fuel tank breather/overflow Catalytic converters NOTICE hose This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING converter.

  • Page 47: Seats

    INSTRUMENT AND CONTROL FUNCTIONS EAU39495 Seats Passenger seat To remove the passenger seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 1. Rider seat lock lever 2. Seat holder 2. Rider seat 2. Remove the key. To install the rider seat 1.

  • Page 48: Adjusting The Rider Seat Height

    INSTRUMENT AND CONTROL FUNCTIONS 2. Install the passenger seat. EAU39632 Adjusting the rider seat height The rider seat height can be adjusted to ● Make sure that the seats are prop- one of two positions to suit the rider’s erly secured before riding. preference.
  • Page 49 INSTRUMENT AND CONTROL FUNCTIONS 6. Align the projection on the bottom of the rider seat with the “H” posi- tion slot, and then push the rear of the seat down to lock it in place as shown. 1. Rider seat height position adjuster 1.

  • Page 50: Storage Compartments

    This storage compartment is designed 7. Install the passenger seat. Storage compartment A is located un- to hold an optional genuine Yamaha der the rider seat. (See page 3-32.) CYCLELOK. (Other locks may not fit.) Make sure that the seats are properly When storing the Owner’s Manual or...

  • Page 51: Accessory Box

    INSTRUMENT AND CONTROL FUNCTIONS EWA14420 EAU39480 2. Remove the key. Accessory box WARNING ECA11800 The accessory box is located beside NOTICE ● Do not exceed the load limit of 1 the meter panel. kg (2 lb) for storage compart- Do not place heat-sensitive items in ment A.

  • Page 52: Adjusting The Headlight Beams

    The headlight beam adjusting knobs The cowling vents can be opened 20 erence. Have a Yamaha dealer adjust are used to raise or lower the height of mm (0.79 in) for added ventilation to the position of the handlebars.
  • Page 53 INSTRUMENT AND CONTROL FUNCTIONS 4. Install the quick fastener. To close a cowling vent 1. Remove the quick fastener. 2. Slide the cowling vent panel for- ward to unhook its projections from the upper slots, and then pull the panel off. 1.

  • Page 54: Rear View Mirrors

    INSTRUMENT AND CONTROL FUNCTIONS EAU39671 EAU54140 Rear view mirrors Adjusting the front fork The rear view mirrors of this vehicle can EWA14670 WARNING be folded forward or backward for park- ing in narrow spaces. Fold the mirrors Always adjust the spring preload on back to their original position before both fork legs equally, otherwise riding.
  • Page 55 INSTRUMENT AND CONTROL FUNCTIONS Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 15.0 mm (0.59 in) 16 click(s) in direction (b)* Standard: Standard: Distance A = 10.0 mm (0.39 in) 12 click(s) in direction (b)* Maximum (hard): Maximum (hard): Distance A = 0.0 mm (0.00 in)

  • Page 56: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS ber of clicks of each damping force ad- EAU14916 Adjusting the shock absorber justing mechanism and to modify the assembly specifications as necessary. This shock absorber assembly is equipped with a spring preload adjust- ing lever and a rebound damping force adjusting knob.

  • Page 57: Sidestand

    Take the shock To obtain a precise adjustment, it is ad- in a possible loss of control. absorber assembly to a Yamaha visable to check the actual total number Yamaha’s ignition circuit cut-off dealer for any service.

  • Page 58: Ignition Circuit Cut-Off System

    INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU54490 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system (com- function properly. prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 59 ”. stand during this inspection. • 3. Turn the key on. If a malfunction is noted, have a Yamaha 4. Shift the transmission into the neutral position. dealer check the system before riding. 5. Push the “ ” side of the start/engine stop switch.

  • Page 60: Auxiliary Dc Jack

    INSTRUMENT AND CONTROL FUNCTIONS EAU39655 Auxiliary DC jack EWA14360 WARNING To prevent electrical shock or short- circuiting, make sure that the cap is installed when the auxiliary DC jack is not being used. ECA15431 NOTICE 1. Auxiliary DC jack cap The accessory connected to the 4.

  • Page 61: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-16 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 62 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 6-19, 6-26 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-26 •...
  • Page 63 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-42 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 64: Operation And Important Riding Points

    ● a lean angle sensor to stop the en- understand, ask your Yamaha dealer. ● The transmission is in the neutral gine in case of a turnover. In this EWA10271 position.

  • Page 65: Shifting

    If not, ask a repeatedly until it reaches the end of its Yamaha dealer to check the elec- travel, and then slightly raise it. trical circuit. 3. Start the engine by pushing the “...

  • Page 66: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS ECA10260 EAU16810 EAU16841 Tips for reducing fuel con- Engine break-in NOTICE sumption There is never a more important period ● Even with the transmission in in the life of your engine than the period Fuel consumption depends largely on the neutral position, do not between 0 and 1600 km (1000 mi).

  • Page 67: Parking

    Do not park on a slope or on soft cur during the engine break-in ground, otherwise the vehicle period, immediately have a may overturn, increasing the Yamaha dealer check the vehi- risk of a fuel leak and fire. cle. ● Do not park near grass or other...

  • Page 68: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 1-3 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 69: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 70: Periodic Maintenance Chart For The Emission Control System

    ● From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). ● Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU46910 Periodic maintenance chart for the emission control system...

  • Page 71: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770F General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √...
  • Page 72 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for exces- √ √...
  • Page 73 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √ √ √ Rear suspension re- •...
  • Page 74 PERIODIC MAINTENANCE AND ADJUSTMENT EAU17670 ● The air filter needs more frequent service if you are riding in unusually wet or dusty areas. ● Hydraulic brake and clutch service • Regularly check and, if necessary, correct the brake and clutch fluid levels. •...

  • Page 75: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 EAU54130 Removing and installing pan- Panel A The panels shown need to be removed to perform some of the maintenance To remove the panel jobs described in this chapter. Refer to 1. Remove each headlight beam ad- this section each time a panel needs to justing knob by removing the be removed and installed.
  • Page 76 PERIODIC MAINTENANCE AND ADJUSTMENT To install the panel 1. Place the panel in its original posi- tion, and then install the bolt, screw and quick fastener. 1. Front cowling 4. Remove the bolt, screw and quick 2. Bolt fastener, and then take the panel 3.
  • Page 77 PERIODIC MAINTENANCE AND ADJUSTMENT 3. Pull the bottom of the panel out- ward, pull the front of the panel downward, and then slide the pan- el forward to release it in the rear as shown. 1. Panel B 1. Panel B 2.

  • Page 78: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 13 Nm (1.3 m·kgf, 9.4 ft·lbf)

  • Page 79: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU19886 4. Remove the engine oil filler cap, Engine oil and oil filter car- the engine oil drain bolt and its tridge gasket to drain the oil from the The engine oil level should be checked crankcase.
  • Page 80 An oil filter wrench is available at a seated. cap. Yamaha dealer. 7. Install the new oil filter cartridge, 6. Apply a thin coat of clean engine and then tighten it to the specified...

  • Page 81: Final Gear Oil

    If any page (since the engine oil also or remains on even if the oil level is leakage is found, have a Yamaha deal- lubricates the clutch), do not correct, immediately turn the engine er check and repair the vehicle.
  • Page 82 1. Place the vehicle on a level sur- face. Recommended final gear oil: 2. Place an oil pan under the final Yamaha genuine shaft drive gear oil gear case to collect the used oil. SAE 80 API GL-5 Oil quantity: 3.

  • Page 83: Coolant

    ● Make sure that the vehicle is posi- coolant, have a Yamaha dealer tioned straight up when checking check the antifreeze content of the coolant level. A slight tilt to the the coolant as soon as possible, side can result in a false reading.

  • Page 84: Cleaning The Air Filter Element

    Have a the periodic maintenance and lubrica- Yamaha dealer change the coolant. tion chart. Clean or, if necessary, re- WARNING! Never attempt to remove place the air filter element more...

  • Page 85: Checking The Engine Idling Speed

    If the air filter element is damaged, speed replace it. Check the engine idling speed and, if necessary, have it corrected by a Yamaha dealer. Engine idling speed: 1000–1100 r/min 1. Fuel tank breather/overflow hose 8. Install the intake air shroud by in- stalling the screw and the quick 6.

  • Page 86: Checking The Throttle Grip Free Play

    Therefore, it must be adjusted by a Yamaha dealer is essential to maintain the tires in good at the intervals specified in the periodic condition at all times and replace them maintenance and lubrication chart.
  • Page 87 250 kPa (2.50 kgf/cm², 36 psi) glass fragments in it, or if the sidewall is surface must first be “broken Rear: cracked, have a Yamaha dealer re- in” for it to develop its optimal 290 kPa (2.90 kgf/cm², 42 psi) place the tire immediately.
  • Page 88 WARNING ed below have been approved for this Tires age, even if they have not been model by Yamaha Motor Co., Ltd. This motorcycle is fitted with super- used or have only been used occasion- high-speed tires. Note the following ally.

  • Page 89: Cast Wheels

    Always adjust the tire air pres- er damage before each ride. If any 6-24.) If the clutch lever free play does sure according to the operating damage is found, have a Yamaha become excessive, and shifting be- conditions. dealer replace the wheel. Do not...

  • Page 90: Checking The Brake Lever Free Play

    Since the brake light switches are components of the cruise control sys- tem, they must be adjusted by a Yamaha dealer, who has the neces- sary professional knowledge and expe- rience. 1. No brake lever free play There should be no free play at the brake lever end.

  • Page 91: Checking The Front And Rear Brake Pads

    EAU22392 cator groove has almost disappeared, EAU40271 Checking the front and rear Checking the brake and clutch have a Yamaha dealer replace the brake pads fluid levels brake pads as a set. The front and rear brake pads must be...
  • Page 92 If the brake behind panel C. (See page 6-8.) or clutch fluid level goes down sudden- ing. Water will significantly low- ly, have a Yamaha dealer check the er the boiling point of the fluid cause before further riding. 6-25...

  • Page 93: Changing The Brake And Clutch Fluids

    Checking and lubricating the clutch fluids cables throttle grip and cable Have a Yamaha dealer change the The operation of all control cables and The operation of the throttle grip should brake and clutch fluids at the intervals the condition of the cables should be be checked before each ride.

  • Page 94: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU44273 EAU43601 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...

  • Page 95: Checking And Lubricating The Centerstand And Sidestand

    EWA10741 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 96: Lubricating The Rear Suspension

    The swingarm pivots must be lubricat- face and hold it in an upright posi- sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, dealer at the intervals specified in the...

  • Page 97: Checking The Steering

    Yamaha dealer check or re- tion chart. If there is play in the wheel ward and backward. If any free pair it.

  • Page 98: Battery

    To charge the battery once a month and fully charge it if ● Electrolyte is poisonous and Have a Yamaha dealer charge the bat- necessary. dangerous since it contains sul- tery as soon as possible if it seems to 3. Fully charge the battery before in- furic acid, which causes severe have discharged.

  • Page 99: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT is turned to “OFF”, then con- EAU54510 Replacing the fuses 12 13 nect the positive lead before The fuse boxes and individual fuses are connecting the negative lead. located under panel A. (See page 6-8.) [ECA16840] 4.
  • Page 100 Main fuse 2: use a fuse of a higher amperage 4. If the fuse immediately blows 30.0 A rating than recommended to again, have a Yamaha dealer Headlight fuse: avoid causing extensive dam- check the electrical system. 25.0 A age to the electrical system and Brake light fuse: 1.0 A...

  • Page 101: Headlight Bulb

    If a front turn signal light does not come 1. Remove the passenger seat. (See on, have a Yamaha dealer check it. ECA16580 page 3-32.) NOTICE 2. Remove the turn signal light bulb...

  • Page 102: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 5. Install the socket (together with the EAU24313 Replacing the license plate bulb) by turning it clockwise. light bulb 6. Install the passenger seat. 1. Remove the license plate light unit by removing the screws. 1. License plate light bulb 2.

  • Page 103: Auxiliary Light

    1. Auxiliary light self. However, should your motorcycle This model is equipped with LED-type require any repair, take it to a Yamaha auxiliary lights. dealer, whose skilled technicians have If an auxiliary light does not come on, the necessary tools, experience, and have a Yamaha dealer check it.

  • Page 104: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 105 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 106: Motorcycle Care And Storage

    Cleaning ble. Rust and corrosion can develop matte colored finished parts. Be ECA10772 sure to consult a Yamaha dealer for even if high-quality components are NOTICE advice on what products to use be- used. A rusty exhaust pipe may go un- ●...
  • Page 107 For motorcycles equipped with thoroughly wash it off with water. For combination with water, carry out the additional cleaning, use Yamaha Wind- a windshield: Do not use strong following steps after each ride in the shield Cleaner or other quality cleaner.
  • Page 108 Before using them, make a EWA11131 WARNING test by polishing an area which does ● Consult a Yamaha dealer for ad- not affect your visibility. Contaminants on the brakes or tires vice on what products to use. can cause loss of control.

  • Page 109: Storage

    MOTORCYCLE CARE AND STORAGE EAU26243 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps Storage stabilizer (if available) to prevent from the spark plugs, and then the fuel tank from rusting and the install the spark plugs and the Short-term fuel from deteriorating.
  • Page 110 MOTORCYCLE CARE AND STORAGE Make any necessary repairs before storing the motorcycle.

  • Page 111: Specifications

    Clutch: Final gear oil: 79.0 × 66.2 mm (3.11 × 2.61 in) Clutch type: Type: Compression ratio: Wet, multiple-disc Yamaha genuine shaft drive gear oil SAE 10.80 : 1 Transmission: 80 API GL-5 Starting system: Primary reduction ratio: Quantity: Electric starter 1.563 (75/48)
  • Page 112 SPECIFICATIONS Secondary reduction ratio: Rear tire: Front wheel: 2.698 (35/37 x 21/27 x 33/9) Type: Wheel type: Transmission type: Tubeless Cast wheel Constant mesh 5-speed Size: Rim size: Operation: 180/55 ZR17M/C (73W) 17M/C x MT3.50 Left foot operation Manufacturer/model: Rear wheel: Gear ratio: BRIDGESTONE/BT023R F Wheel type:...
  • Page 113 SPECIFICATIONS Rear suspension: Meter lighting: Ignition fuse: 20.0 A Type: Neutral indicator light: Radiator fan fuse: Swingarm (link suspension) 10.0 A × 2 Spring/shock absorber type: High beam indicator light: Hazard fuse: Coil spring/gas-oil damper 7.5 A Wheel travel: Oil level warning light: Fuel injection system fuse: 125.0 mm (4.92 in) 15.0 A...

  • Page 114: Consumer Information

    Record the vehicle identification num- ber and model label information in the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehicle is stolen. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1.
  • Page 115 INDEX D-mode (drive mode) ......3-22 ABS ............3-26 Main switch/steering lock......3-2 ABS warning light ........3-5 Engine break-in ........5-3 Maintenance and lubrication, periodic ..6-4 Accessory box ........3-36 Engine idling speed, checking....6-18 Maintenance, emission control system ... 6-3 Air filter element, cleaning ....
  • Page 116 INDEX Storage compartments......3-35 Swingarm pivots, lubricating ....6-29 Throttle grip and cable, checking and lubricating ........... 6-26 Throttle grip free play, checking.... 6-19 Tires ............6-19 Tool kit ............ 6-2 Traction control system......3-27 Traction control system indicator/ warning light ......... 3-5 Troubleshooting ........
  • Page 118 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2012.07-0.3×1 CR...
