Summary of Contents for Chauvet COLORdash Batten
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual Chauvet, 5200 NW 108th Avenue Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. B ..................................1 EFORE EGIN ................................... 1 HAT IS INCLUDED ................................1 NPACKING NSTRUCTIONS ..................................1 ANUAL ONVENTIONS ......................................1 CONS ..................................2 AFETY NSTRUCTIONS LED E ................................. 2 XPECTED IFESPAN 2. I ..................................3 NTRODUCTION ....................................... 3 EATURES Additional Features ................................3 Options ....................................3... -
Page 3: Before You Begin
In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Manual Conventions CHAUVET manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Do not open the housing or attempt any repairs unless you are one of them. In the unlikely event that your unit may require service, please contact CHAUVET at (954) 929-1115. -
Page 5: Introduction
2. I NTRODUCTION Features · 3, 4, 10, or 12-channel DMX LED bank system (with ID addressing) · Operating modes 3-channel: RGB control 4-channel: RGB, dimmer 10-channel: RGB, ID, dim, macro, strobe, automatic, custom, module select 12-channel: RGB of 4 separate sections ·... -
Page 6: Dmx Channel Summary
DMX Channel Summary The COLORdash™ Batten has four DMX channel configurations, referred to as “Personalities” in this manual and in the fixture onboard control panel. The four personalities are: STAGE 1, BLOCK, ARC 1 and ARC 1 + D. Each of the different personalities can be accessed from the control panel. Please see section on “Control Panel Functions”... -
Page 7: Product Overview
Product Overview Bracket Adjustment Knob Bracket Adjustment knob Cooling Fan Power Out DMX Out Control Fuse holder Panel Power In DMX In COLORdash™ Batten User Manual – Rev 03 1/30/2012... -
Page 8: Product Dimensions
Product Dimensions COLORdash™ Batten User Manual – Rev 03 1/30/2012... -
Page 9: Setup
3. SETUP AC Power This fixture has an auto-switching power supply that can accommodate a wide range of input voltages (100 ~ 240 VAC, 50/60 Hz). Before powering on the unit, make sure the line voltage to which you are connecting it is within the range of accepted voltages. -
Page 10: Mounting
You can order “C” and “O” clamps from any CHAUVET dealer or distributor (CLP-15, CLP-06 recommended). There are two types of applications for this fixture: floor stand for up lighting, and overhead use for down lighting. - Page 11 Rigging (Cont.) Double yoke bracket/floor stand: The fixture ships with this configuration installed. It is recommended that two clamps be used when hanging the fixture in this configuration. Horizontal hang: The clamp is mounted directly to the fixture’s M10 threaded hole on the rear of the fixture, without any other bracket(s).
-
Page 12: Fixture Stacking
Fixture Stacking The fixtures may be stacked together horizontally to create a strip light or vertically for a blinder effect. This can be used for runway lighting or cycloramas. With the different methods of bracket mounting, this turns the COLORdash™ Batten into a very versatile lighting tool. It is recommended that a maximum of three fixtures be stacked together at a time. - Page 13 Hanging horizontal stacking (two units) with side safety loops and two “O” clamps. In a two-unit horizontal stacking arrangement, CHAUVET recommends using two clamps to prevent the arrangement from pivoting Horizontal Stacking (Floor Standing) Floor standing horizontal stacking (three units) with rear brackets and side floor stands (exploded view).
-
Page 14: Ssembly Installation /Replacement
Lens Assembly Installation/Replacement The COLORdash™ Batten ships with 15° lens assembly pre-installed from the factory. However, there is an optional lens kit (CL20X30) available as accessories, which will alter the beam angle to 30º. These lenses come in packages of 20 pieces each. Therefore, if you have a fixture that has more than 20 LEDs (such as the COLORdash™... -
Page 15: Fixture Linking
Maximum recommended number of fixtures on a serial data link: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable, please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 16: 3-Pin To 5-Pin Conversion Chart
3-Pin to 5-Pin Conversion Chart If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter. You may use the CHAUVET Model number DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 17: Slave Fixture Linking
Master/Slave Fixture Linking Connect the (male) 3-pin connector side of the DMX cable to the output (female) 3-pin connector of the first fixture. Connect the end of the cable coming from the first fixture, which will have a (female) 3-pin connector to the input connector of the next fixture consisting of a (male) 3-pin connector. -
Page 18: Operating Instructions
4. O PERATING NSTRUCTIONS Control Options The COLORdash™ Batten is addressable in the DMX range of 001 to 512. In its simplest control form, this allows for the control of up to 51 fixtures in the 10-channel STAGE 1 personality; however, a secondary ID address system exists for use in a limited DMX universe and architectural environments. -
Page 19: Dmx Addressing Example
DMX Addressing Example DMX Address: 001 DMX Address: 001 DMX Address: 001 DMX Address: 011 DMX Address: 011 DMX Address: 011 ID Address: 01 ID Address: 02 ID Address: 03 ID Address: 02 ID Address: 03 ID Address: 01 The figure above shows a simple DMX layout, which has used three units at each DMX address. -
Page 20: Configuring The Starting Address
Configuring the Starting Address Each fixture requires a starting address from 1 ~ 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the starting address. For example, a fixture that uses seven DMX channels and is addressed to start on DMX channel 100, will read data from channels: 100, 101, 102, 103, 104, 105 and 106. -
Page 21: Upload Customs
Upload Customs The custom programs in the COLORdash™ Batten may be copied from one fixture to another, thus giving the ability to have to only program them on a single fixture, and then duplicate them on several others. This function is accessed from the Control Panel by selecting Upload Customs. Follow the below steps for this process. -
Page 22: Menu Map
DMX controller (DMX), or 6. Run Mode (No sub function) DMX ~ Slave to receive signal from the DMX out of another COLORdash Batten (Slave) 7. ID Address (No sub function) 0 ~ 66 Assigns the ID address to a fixture... - Page 23 COLORdash™ Batten User Manual – Rev 03 1/30/2012...
-
Page 24: Hannel Values
DMX Channel Values The COLORdash™ Batten has four DMX channel configurations: STAGE 1, BLOCK, ARC 1, and ARC 1 + D. STAGE 1 HANNEL ALUE UNCTION Dimmer 000 ó 255 0 ó 100% (or STEP TIME when CUS 1 ~ 10 is activated) 000 ó... -
Page 25: Block
STAGE 1 (Cont.) ID A HANNEL DDRESSING ALUE ALUE ALUE 000 ó 009 All IDs ID 23 ID 46 010 ó 019 ID 1 ID 24 ID 47 020 ó 029 ID 2 ID 25 ID 48 030 ó 039 ID 3 ID 26 ID 49... -
Page 26: Arc 1
ARC 1 HANNEL ALUE UNCTION 000 ó 255 0 ó 100% Green 000 ó 255 0 ó 100% Blue 000 ó 255 0 ó 100% ARC 1 + D HANNEL ALUE UNCTION Dimmer 000 ó 255 0 ó 100% 000 ó 255 0 ó... -
Page 27: Peration Notes (Stage 1)
· This fixture is divided into four sections, referred to as blocks. Channel 10 determines your block selection. Contact Us Wor l d Wi de General Information Chauvet Lighting 5200 NW 108th Avenue Sunrise, FL 33351 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084... -
Page 28: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) General Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. -
Page 29: Returns Procedure
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 30: Photometric Data
Photometric Data COLORdash™ Batten User Manual – Rev 03 1/30/2012... -
Page 31: Colordash™ Batten Service Maintenance Guide
· Keep DMX cables separated from power cables or · Interference from AC wires black lights. If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on page 28. COLORdash™ Batten User Manual – Rev 03... -
Page 32: Exploded View
Exploded View ESCRIPTION UMBER LED Driver PCB P172-MBTDVR Display/Master PCB P170-MBATPC Electronic Transformer P140-M1ELTR Bracket/Floor stand P170-MBBRKT Bracket adjustment knob P111-MBTKNOB Power input/output connector P111-PWRCNC Side, plastic cover P111-BATBCVR LED metal-core PCB assembly P222-MBATDVR Cooling fan P130-40MM24V Front clear plastic LED cover P111-MBARCLR COLORdash™... -
Page 33: Wiring Diagram
Wiring Diagram COLORdash™ Batten User Manual – Rev 03 1/30/2012... -
Page 34: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ............................. 3.3 in (84 mm) Width ........................... 18.5 in (470 mm) Height............................ 7.5 in (191 mm) Weight ............................ 7.9 lbs (3.6 kg) POWER Auto-ranging internal power supply ................100 ~ 240 V, 50/60 Hz Power Consumption @ 120 V, 60 Hz .................. 58 W (0.8 A) max Power Consumption @ 240 V, 50 Hz ................
