Page 1: Air Conditioner
OWNER'S MANUAL AIR CONDITIONER ONE-TWIN SPLIT TYPE Thank you very much for purchasing our air conditioner, please read this owner's manual carefully before using your air conditioner, save this manual in a safe place for future reference. -
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INFORMATION............. HINTS FOR ECONOMICAL OPERATION............PARTS NAMES....................NAMES AND FUNCTIONS OF INDOOR UNIT CONTROLS......ADJUSTING AIR FLOW DIRECTION..............HOW THE AIR CONDITIONER WORKS............TEMPORARY OPERATIONS................MAINTENANCE....................AIR CONDITIONER OPERATIONS AND PERFORMANCE......INSTALLATION....................TROUBLES AND CAUSES................TROUBLES AND CAUSES (CONCERNING REMOTE CONTROLLER).. -
Page 3: Important Safety Information
WARNING Ventilate the room occasionally while the air conditioner is in use, especially if there is also a gas appliance in use in this room. Failure to follow these directions may result in a loss of oxygen in the room. -
Page 4: Hints For Economical Operation
IMPORTANT SAFETY INFORMATION NOTE For proper performance, operate the unit under the usable operating temperature and humidity conditions indicated in this owner's manual. If the unit is operated beyond these conditions, it may cause malfunctions of the unit or dew dripping from the unit. -
Page 5: Parts Names
PARTS NAMES Indoor unit Indoor unit 1 Room temperature sensor 2 Front panel 3 Air inlet 4 Air filter 5 Air outlet 6 Vertical air flow louver Indoor unit 7 Horizontal air flow grille 8 Display panel 9 Infrared signal receiver 10 Remote Controller 11 Control panel Outdoor unit... -
Page 6: Names And Functions Of Indoor Unit Controls
NAMES AND FUNCTIONS OF INDOOR UNIT CONTROLS Control panel Lift the front panel to perform control panel settings. Opening the front panel Pull up from two ends of the front panel. Open the panel and lift the panel up to an angle where it remains fixed. -
Page 7: Adjusting Air Flow Direction
ADJUSTING AIR FLOW DIRECTION To automatically swing the air flow direction Perform this function while the air conditioner is in operation. Push the SWING button on the remote controller. To stop the function, push the SWING button again. To change the swing direction, push the AIR DIRECTION button. -
Page 8: How The Air Conditioner Works
HOW THE AIR CONDITIONER WORKS AUTOMATIC OPERATION The air conditioner selects and operates in one of the Operation suppression zone operating modes of cooling, heating (cooling only type without) or fan only, depending on the room ¡£ temperature. ¡ £... -
Page 9: Maintenance
Check that the air filter is installed. Check that the outdoor unit air outlet or inlet is not blocked. Before you clean the air conditioner be sure to disconnect the power supply plug. Cleaning the air filter 1. Pull up from two ends of panel. Open the panel and lift the panel up to an angle where it remains fixed. - Page 10 MAINTENANCE 3. Take hold of the handles and pull the air filter downward. 4. Remove the AIR FILTER from the indoor unit. Clean the AIR FILTER once two weeks. Clean the AIR FILTER with a vacuum clearer or water, then dry it up in cool place. 5.
-
Page 11: Air Conditioner Operations And Performance
This will protect the machine. (cooling only type without) Heating characteristics preheating operation The air conditioner will not deliver warm air immediately after it is started. Warm air flows out after approximately 5 minutes when the indoor heat exchanger warms up. -
Page 12: Installation
INSTALLATION Location: In cooling operation, the air conditioner will dry the room air, so please fix a pipe to drain all the water away in the air conditioner. Please let the indoor unit away from the TV set and the radio more than one meter in order to avoid the picture and noise interference. -
Page 13: Troubles And Causes
The temperature setting is too high or too low. Room air is smelly. Too hot A bad odor comes from the air conditioner. Smells impregnated in the wall, carpet, furniture, clothing, or furs, are coming out. A white mist of chilled air or water is generated from the outdoor unit. -
Page 14: Troubles And Causes (Concerning Remote Controller)
When the time set to start the The TIMER indicators go off Check whether the timer air conditioner is reached, the after a lapse of certain time. operation is started when air conditioner will automatically... - Page 15 CS242-U 2200019824...
