Features; Specifications; Amplifiers - Gemini GPA-1000 Product Introduction

Gemini's GPA Series Power Amplifiers provide you with excellent value for a wide range of intermediate
power applications. With its bi-polar output stage technology and comprehensive protection circuitry to prevent
overheating, the GPA Series gives you the high end features you want in a product that is well within your budget.
• Comprehensive Protection Circuitry with Protect LED Indicator
• ¼" TRS & XLR Balanced/ Unbalanced Inputs
• 3 Modes of Operation- Stereo, Parallel Mono, and Mono Bridge
• Decibel (dB) Level Meter with Clip LEDs
• Aluminum Extrusion Heat Sink Design with Directly Mounted
Output Transistors for No-Fault Operation
• Subsonic and Ultrasonic Filters for Better Protection and More
Efficient Operation
• Protection: Short Circuit, DC, Thermal Cut-off, Sub/Ultrasonic
Frequency Filters, Turn-On Delay, Main Fuse, Secondary DC
Fuses
• Indicators: 1 Power LED, 1 Protect LED (except GPA-1000),
VU-Meter Per Channel
• Cooling: Fan, Front-to-Rear Forced Air
• Signal to Noise Ratio: 100 dB Below Rated Power at 8 Ohms
• Input Impedance Balanced: 20 kOhm
• Balanced/ Unbalanced Inputs: XLR & ¼" Jack

Amplifiers

Both Channels Driven at 8 Ohms
Both Channels Driven at 4 Ohms
Mono Bridge at 8 Ohms
Momentary Peak Output
Dynamic Headroom at 8 Ohms
Dynamic Headroom at 4 Ohms
Voltage Gain
Power Consumption, rated at 4 Ohms,
both channels driven
Weight
GCI Technologies Corp.
Gemini Sound Products, S.A.
GCI Technologies Corp. GmBH
GCI Technologies Corp., Ltd.
GCI Technologies Corp., S.A.R.L.
© GCI Technologies Corp. 2007 All Rights Reserved.
Professional Power Amplifiers

FEATURES

SPEciFicATionS

GPA-1000
70W RMS / 140W PEAK
90W RMS / 180W PEAK
180W RMS / 360W PEAK
1000 W
1.3 dB
1.8 dB
27 dB
400 W
13.6 lbs (6.2 kgs)
*Specifications subject to change without notification for improvement
1 Mayfield Avenue, Edison, NJ, USA 08837
Caspe 172 , 1A, 08013 Barcelona, Spain
Lerchenstrasse 14, Haus 3 – 1. Stock, 80995 München, Munich, Germany
Unit 44 Brambles Enterprise Center, Waterberry Drive, Waterlooville, PO7 7TH, UK
Parc de Levenement1, Alleed'Effiat, 91160 Longjumeau, France
(All models have same back panel connections)
• Speakon & ¼" Speaker Outputs
• 30 Hz to 50 kHz Frequency Response, <0.05% THD (0.02%
Typical)
• High Output Power to Drive Professional Loudspeakers without
Clipping
• Ground Lift Switch
• Air Guide with Front-to-Rear Airflow and Cooling Fan for
Thermal Stability and Reliability
• Dimensions: 19"W x 10.75"D x 3.5"H (483 x 273 x 89mm)
• Input Impedance Unbalanced: 10 kOhm
• Total Harmonic Distortion: > 0.05%, typical 0.02% at 1 kHz
• Output Power EIA: 1 kHz at 1% THD, WRMS
• Frequency Response: 30 Hz - 50 kHz • Slew Rate: 20 V/μS
• Damping Factor: Greater Than 200 at 8 Ohms
• Input Sensitivity (For Rated Power at 8 Ohms): 1 VRMS
• AC Power Requirements: 110-120V/ 60 Hz; 220-240V/ 50 Hz
• Speaker Outputs: Speakons & ¼" Jack
GPA-2000 GPA-3000
85W RMS / 170W PEAK 140W RMS / 280W PEAK
110W RMS / 220W PEAK 200W RMS / 400W PEAK
220W RMS / 440W PEAK 400W RMS / 800W PEAK
2000 W
1.4 dB
1.9 dB
28 dB
500 W
16.5 lbs (7.5 kgs) 18.3 lbs (8.3 kgs)
T: +1 732 346 0061
T: +34 93 436 37 00
T: +49 (0) 89 319 019 80
T: +44 (0) 87 087 00880
T: +33 (0) 1 69 79 97 70
GPA-4000
200W RMS / 400W PEAK
300W RMS / 600W PEAK
600W RMS / 1200W PEAK
3000 W 4000 W
1.5 dB 1.6 dB
2.0 dB 2.2 dB
30 dB 32 dB
800 W 1200 W
20.2 lbs (9.2 kgs)
