31-30246
10-08 JR
Installation
Instructions
Built-In Dishwashers
*Custom front panel models include a kit that
contains a template, hardware and panel
installation instructions. Refer to the kit
instructions when installing the custom panel.

Advertisement

Table of Contents
loading

Summary of Contents for GE Built-In Dishwashers

  • Page 1 31-30246 10-08 JR Installation Instructions Built-In Dishwashers *Custom front panel models include a kit that contains a template, hardware and panel installation instructions. Refer to the kit instructions when installing the custom panel.
  • Page 2: Table Of Contents

    1.800.561.3344. Step 8, Install 90° Elbow...9 Step 9, Position Water Line and Housing Wiring ...9 Step 10, Install Drain Hose to Dishwasher Drain Port...9 Step 11, Insert Drain Hose Through Cabinet...10 Step 12, Slide Dishwasher Three-Fourths of the Way Into Cabinet...10 Step 13, Slide Dishwasher Into Final Position ...10, 11...
  • Page 3: Installation Preparation

    PARTS SUPPLIED: • Two #8-18 x 5/8" Phillips special-head screws, to secure dishwasher to underside of countertop or sides of cabinets. • Junction box cover and #10-1/2" hex head screw • Side and top trim • Sound upgrade kit (some models) •...
  • Page 4: Advance Planning

    10 feet in length for proper drainage. • Provide at least 28-3/8" in front of the dishwasher to allow the dishwasher door to open fully (Figure B). • Make sure the floor is level inside the opening and even with the finished floor of the kitchen.
  • Page 5: Prepare Drain Plumbing

    Special consideration for a dishwasher installed on a elevated platform lf the dishwasher is installed on an elevated platform, a high drain loop of at least 32" above the platform must be provided in addition to the air gap or drain loop requirement determined above.
  • Page 6: Prepare Electrical Wiring

    NOTE: Power cords with plug must pass through a separate hole. Electrical Connection to Dishwasher Electrical connection is on the right front of dishwasher. • For cable direct connections the cable must be routed as shown in Figure E. Cable must extend a minimum of 24"...
  • Page 7: Installation Instructions

    • The water connection is on the bottom left side of the dishwasher. Install the hot water inlet line, using 3/8" or larger copper tubing. Route the line as shown in Figure F and extend forward at least 19" from rear wall.
  • Page 8: Step 3 Check Door Balance

    STEP 4 IMPORTANT Damage will occur. • Move the dishwasher close to the installation location and lay it on its back. • Remove the four leveling legs on the underside of the wood base with an adjustable wrench or 15/16" socket.
  • Page 9: Step 7 Install Power Cord

    Figure O • Do not overtighten 90° elbow, water valve bracket could bend or water valve fitting could break. • Position the end of the elbow to face the rear of the dishwasher. Installation Instructions STEP 9 • Position water supply line and house wiring on the floor of the enclosure to avoid interference with base of dishwasher and components under dishwasher.
  • Page 10: Step 11 Insert Drain Hose Through Cabinet

    DO NOT PUSH AGAINST — FRONT PANEL WITH KNEES. DAMAGE WILL OCCUR. • Grasp the dishwasher by its sides and slide it into the opening a few inches at a time. Do not push against front door panel with knee. Damage to the door panel will occur.
  • Page 11: Step 14 Level Dishwasher

    • If the dishwasher is not level, adjust the four leveling legs as illustrated in Figure X. • If adjustment to the right rear leveling leg is required, access it by loosening the junction box bracket screw (through the access hole) and rotate bracket clockwise.
  • Page 12: Step 15 Secure Dishwasher To Countertop Or Cabinet

    Figure Z Method 1—Secure dishwasher to wood countertop • Fasten the dishwasher to the underside of the countertop with 2 Phillips special-head screws provided. Method 2—Secure dishwasher with side-mounting brackets • Remove plug buttons (one on each side).
  • Page 13: Step 17 Connect Drain Line

    Insert the drain hose into the air gap as shown. Waste Tee Installation Method 2—High Drain Loop with the Waste Tee or Disposer Route the drain hose of the dishwasher to a minimum height of 32" from the floor with the supplied hanger as shown. Fasten to underside...
  • Page 14: Step 18 Connect Power Supply

    STEP 18 CONNECT POWER SUPPLY Skip this step if dishwasher is equipped with power cord. Verify that power is turned off at the source. • Locate junction box cover set aside in Step 1. • Secure house wiring to the back of the junction box with a strain relief.
  • Page 15: Step 20 Dishwasher Wet Test

    – Push RINSE ONLY pad. – Push START/RESET pad one time. – Close door. • Check to be sure that water enters the dishwasher. If water does not enter the dishwasher, check to be sure that water and power are turned on.
  • Page 16: Step 23 Install Toekick

    • Replace the toekick and make sure it is against the floor. • Insert and tighten the 2 toekick attachment screws. The toekick should stay in contact with the floor to ensure quiet dishwasher operation. STEP 24 LITERATURE • Be sure to leave complete literature package, Installation Instructions and product samples with the consumer.
  • Page 17 31-30246 10-08 JR Instructions d’installation Lave-vaisselle encastré *Les modèles avec panneau frontal sur commande viennent avec une trousse comprenant un gabarit, la quincaillerie et les instructions d'installation du panneau. Se reporter aux instructions de la trousse pour installer le panneau sur commande.
  • Page 18: Avant De Commencer

    AVANT DE COMMENCER Il faut lire soigneusement toutes ces instructions. IMPORTANT • — Conserver ces instructions afin que l’inspecteur local s’en serve. Il faut respecter tous les codes et règlements. Remarque pour l’installateur • de remettre ces instructions au consommateur. Remarque pour le consommateur •...
  • Page 19: Préparation Pour L'installation

    Préparation pour l’installation PIÈCES FOURNIES : • Deux vis cruciformes spéciales #8-18 x 5/8 po pour fixer le lave-vaisselle au dessous du plan de travail ou aux côtés des armoires. • Couvercle de boîte de jonction et vis hexagonale #10-1/2 po •...
  • Page 20: Planification Préalable

    Préparation pour l’installation PLANIFICATION PRÉALABLE • Ces lave-vaisselle sont conçus afin d’être polyvalents et de pouvoir s’adapter à pour ainsi dire n’importe quelle installation. • Tous les modèles ont une porte pleine longueur sans le panneau d’accès traditionnel. PRÉPARATION DE L’ENCEINTE DU LAVE-VAISSELLE Cette portion du mur ne doit pas avoir de tuyaux...
  • Page 21: Préparation De La Plomberie De Vidange

    Préparation pour l’installation PRÉPARATION DE LA PLOMBERIE DE VIDANGE Exigences relatives au circuit de vidange • Le tuyau de vidange ne doit pas dépasser 3 m (10 pi) de longueur. • Une boucle de vidange élevée ou un dispositif anti-siphon sont nécessaires. Voir ci-dessous. Détermination de la méthode de vidange Le type d’installation de la vidange dépend de la réponse aux questions suivantes :...
  • Page 22: Préparation Pour Le Branchement Électrique

    Préparation pour l’installation PRÉPARATION POUR LE BRANCHEMENT ÉLECTRIQUE AVERTISSEMENT SÉCURITÉ : Enlever le fusible du circuit ou déclencher le disjoncteur avant de commencer l’installation. Avec cet appareil, ne pas utiliser une rallonge ou un adaptateur de prise. Alimentation électrique • Cet appareil doit avoir une alimentation en 120 V, 60 Hz, et être branché...
  • Page 23: Préparation Du Tuyau D'eau Chaude

    Instructions d’installation PREPARATION DU TUYAU D’EAU CHAUDE Tuyau d'eau chaude • Le tuyau peut entrer d’un côté ou de l’autre, de l’arrière ou du sol, dans la zone hachurée montrée à la Figure F. • Le tuyau peut passer dans le même trou que le câble électrique et le tuyau de vidange.
  • Page 24: Étape 3 Vérification De L'équilibre De La Porte

    Instructions d’installation VÉRIFICATION DE L’ÉQUILIBRE ÉTAPE 3 DE LA PORTE • Avec le lave-vaisselle sur la palette de bois, ouvrir et fermer la porte pour vérifier son équilibre. • Si la porte tombe quand elle est relâchée, augmenter la tension du ressort. Si la porte monte quand elle est relâchée, diminuer la tension du ressort.
  • Page 25: Étape 7 Installation Du Cordon D'alimentation Électrique

    Instructions d'installation INSTALLATION DU CORDON ÉTAPE 7 D’ALIMENTATION ÉLECTRIQUE Sauter cette étape si le lave-vaisselle est raccordé directement au réseau électrique de la maison. Dans cette étape, vous aurez besoin du couvercle de boîte de jonction et d’une vis hexagonale #10 x 1/2 po de la trousse de quincaillerie mise de côté...
  • Page 26: Étape 11 Insertion Du Tuyau De Vidange À Travers L'armoire

    Instructions d'installation INSERTION DU TUYAU DE ÉTAPE 11 VIDANGE À TRAVERS L’ARMOIRE • Placer le lave-vaisselle devant l’ouverture d’armoire. Insérer le tuyau de vidange dans le trou sur le côté de l’armoire. Si un cordon d’alimentation est utilisé, en faire passer l’extrémité...
  • Page 27: Étape 14 Mise À Niveau Du Lave-Vaisselle

    Instructions d'installation GLISSEMENT DU LAVE- ÉTAPE 13 VAISSELLE À SA POSITION FINALE (suite) Considérations spéciales concernant la mise en place Les commandes sur ces modèles sont conçues pour être dissimulés sous le plan de travail. Aligner le lave-vaisselle comme illustré à la Figure U. Laisser un espace minimum de 1,3 cm (1/2 po) entre le dessous du plan de travail et le dessus de la porte du lave-vaisselle comme illustré...
  • Page 28: Étape 15 Fixation Du Lave-Vaisselle

    Instructions d’installation FIXATION DU LAVE-VAISSELLE ÉTAPE 15 AU AU PLAN DE TRAVAIL OU À L’ARMOIRE Dans cette étape, vous Supports de aurez besoin de 2 vis à montage latéraux tête cruciforme spéciale mises de côté à l’étape 1. Le lave-vaisselle doit être fixé...
  • Page 29: Étape 17 Raccordement Du Tuyau De Vidange

    Instructions d’installation RACCORDEMENT DU TUYAU ÉTAPE 17 DE VIDANGE L'extrémité moulée du tuyau de vidange s’adapte aux orifices d’entrée de 1,6 cm (5/8 po) à 2,5 cm (1 po) de diamètre sur un dispositif anti-siphon, un raccord en té d’égout ou un broyeur à déchets. •...
  • Page 30: Étape 18 Branchement À L'alimentation Électrique

    Instructions d'installation BRANCHEMENT À ÉTAPE 18 L’ALIMENTATION ÉLECTRIQUE Sauter cette étape si le lave-vaisselle est équipé d’un cordon électrique. S’assurer que l’alimentation électrique est allumée à la source. • Repérer le couvercle de boîte de jonction mis de côté à l'étape 1. •...
  • Page 31: Étape 20 Essai Du Lave-Vaisselle Avec De L'eau

    Instructions d’installation/Dimensions du panneau sur commande ESSAI DU LAVE-VAISSELLE ÉTAPE 20 AVEC DE L’EAU • Mettre le circuit sous tension (ou brancher le cordon d’alimentation dans la prise de courant, si installée). • Mettre le lave-vaisselle en marche pour vérifier qu’il n’y a pas de fuites.
  • Page 32 INSTALLATION DE LA ÉTAPE 23 PLINTHE • Repérer la plinthe et les vis mises de côté à l’étape 5. Plinthe Vis de fixation Figure JJ • Replacer la plinthe et s’assurer qu’elle s’appuie contre le plancher. • Insérer et serrer les deux vis de fixation de la plinthe. La plinthe doit rester en contact avec le plancher pour assurer le fonctionnement silencieux du lave-vaisselle.
