Bluetooth module

NOTE: This section applies only to computer models equipped with an Intel processor.
Description
EDR v.4.0 Bluetooth module
NOTE: The Bluetooth module spare part kit does not include the Bluetooth module cable. The Bluetooth module cable is
available using spare part number 665303-001.
Before removing the Bluetooth module and cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Optical drive (see
●
Hard drive (see
●
Keyboard (see
●
Top cover (see
Remove the Bluetooth module and cable:
1. Disconnect the Bluetooth module cable (1) from the system board.
2. Release the Bluetooth module cable from the clips (2) and the routing channel built into the front
speaker assembly.
72 Chapter 4 Removal and replacement procedures
Battery on page 51), and then remove the following components:
Optical drive on page
Hard drive on page 54)
Keyboard on page 62)
Top cover on page 66)
52)
Spare part number
655792-001
