TM
PSI23MGP – GE Profile Arctica
Case Dimensions (in inches/cm.)
28-5/16
C
26-3/4
D
23-7/8
E
69-1/4
F
Side View
Specification Created 2/03
22.7 Cu. Ft. CustomStyle
™
69-1/4
A
68-3/4
B
Front View
Total volume and shelf
area are calculated by the
Association of Home
Appliance Manufacturers'
standards.
Side-by-Side Refrigerator with Dispenser
™
1''
(2.54 cm.)
Listed by
Underwriters
Laboratories
R
37-5/16
J
35-3/4
G
45-9/16
Top View
For answers to your Monogram,
®
GE Profile
GE appliance questions, visit our website at
R
GEAppliances.com or call
GE Answer Center
®
service, 800.626.2000.
I
™
or
Advertisement
Related Manuals for GE GE Profile Arctica PSI23MGPBB
Summary of Contents for GE GE Profile Arctica PSI23MGPBB
- Page 1 Association of Home Appliance Manufacturers’ standards. (2.54 cm.) 37-5/16 35-3/4 Top View For answers to your Monogram, Listed by GE appliance questions, visit our website at Underwriters GEAppliances.com or call Laboratories GE Answer Center 45-9/16 ® GE Profile ™ ®...
-
Page 2: Rough-In Dimensions
(or the underside of the overhead cabinets). For Models with Trim Kit: If frameless style cabinets are planned for above the refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to height of opening to allow additional clearance between cabinet doors and top of refrigerator trim when cabinet doors are in open position. - Page 3 (or the underside of the overhead cabinets). For Models with Trim Kit: If frameless style cabinets are planned for above the refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to height of opening to allow additional clearance between cabinet doors and top of refrigerator trim when cabinet doors are in open position.
-
Page 4: Door Panel Dimensions
Top View IMPORTANT: Before finalizing specifications for your GE Profile CustomStyle Refrigerator, please NOTE: • A minimum of 36" is required for refrigerator installation • Be sure to allow for 1/2" or 3/4" side panels in addition to the 36" minimum Specification Created 2/03 22.7 Cu. -
Page 5: Features And Benefits
PSI23MGP – GE Profile Arctica CUBED QUICK ICE WATER CRUSHED LIGHT RESET WATER FILTER LOCK CONTROL DOOR ALARM HOLD 3 SECS HOLD 3 SECS Specification Created 2/03 22.7 Cu. Ft. CustomStyle Side-by-Side Refrigerator with Dispenser ™ ™ Features and Benefits •...
