  • Page 1 Model No. 831.24976.1 Serial No. USER’’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.nordictrackservice.com/ registration. CUSTOMER CARE For service at any time, go to www.nordictrackservice.com.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. NORDICTRACK is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    20. To purchase a surge suppressor, see your local 4. The treadmill is intended for home use only. NORDICTRACK dealer, call the telephone Do not use the treadmill in any commercial, number on the front cover of this manual, or rental, or institutional setting.
  • Page 4 20. The heart rate monitor is not a medical 24. Never insert any object into any opening on device. Various factors, including the user’’s the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.
  • Page 6 STANDARD SERVICE PLANS...

  • Page 7: Before You Begin

    Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK C 600 treadmill. The C 600 treadmill manual. To help us assist you, please note the product ® offers an impressive selection of features designed model number and serial number before contacting us.

  • Page 8: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
  • Page 9 ASSEMBLY •• Assembly requires two persons. •• To identify small parts, see page 8. •• Place all parts in a cleared area and remove the •• Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex key materials until you ...
  • Page 10 2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (94). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94). See the inset drawing. Tie the wire tie in the Right Upright (90) securely around the end of the Upright Wire (81).
  • Page 11 4. Make sure there is a Wheel Spacer (63) inside each Front Wheel (62). Hold a Front Wheel (62) inside the bottom of the Right Upright (90), and insert a 3/8" x 4" Screw (7) with a 3/8" Star Washer (13) into the Right Upright and the Front Wheel.
  • Page 12 6. Identify the Left and Right Base Covers (82, 83). Slide the Left Base Cover onto the Left Upright (89), and slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet. 7.
  • Page 13 8. Attach the left handrail assembly (C) to the Left Upright (89) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); do not fully tighten the Screws yet. 9. Set the Console Base (64) face down on a soft surface to avoid scratching the Console Base.
  • Page 14 10. Identify the Right and Left Trays (27, 36). Attach the Trays (27, 36) to the Console Base (64) with eight #8 x 1/2" Screws (1). Tip: It may be easier to start the two inside Screws and then slide the Trays into place before tighten- ing the other six Screws.
  • Page 15 12. With the help of a second person, hold the con- sole assembly near the Handrails (86) (only one Console side is shown). Assembly Connect the ground wire from the console assembly to the Console Ground Wire (58) on the Pulse Crossbar (93). Connect the Upright Wire (81) to the console Console Ground...
  • Page 16 14. Attach the Pulse Crossbar (93) to the console assembly with six #8 x 1/2" Screws (1). Start all Console six Screws, and then tighten them. Assembly Firmly tighten the four 5/16" x 3/4" Screws (4). 15. Check the gaps between the handrail assem- blies (B, C) and the console assembly.
  • Page 17 16. Tighten a #8 x 1" Screw (102) with a Handrail Plate (104) and a #10 Washer (103) into the Left Outside Upright Cover (87) and into the bottom of the left handrail assembly (C). Be sure to orient the Plate as shown. Make sure not to overtighten the Screws.
  • Page 18 18. Note: If it is assembled on a smooth surface, the treadmill may roll forward during this step. Raise the Frame (56) to the upright position. Brackets Have a second person hold the Frame until step 20 is completed. Orient the Latch Crossbar (38) as shown. Make sure that the ““This side toward belt””...
  • Page 19 20. Attach the upper end of the Storage Latch (53) to the bracket on the Latch Crossbar (38) with a 5/16" x 2 1/4" Bolt (3) and a 5/16" Nut (12). Lower the Frame (56) (see HOW TO LOWER THE TREADMILL FOR USE on page 29). 21.

  • Page 20: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s...
  • Page 21 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- tive and enjoyable.
  • Page 22 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 23 5. Follow your progress with the displays. As you exercise, the workout intensity level bar will indicate the approximate intensity level of your As you walk or run on the treadmill, the display can exercise. show the following workout information: ••...
  • Page 24 7. Turn on the fan if desired. HOW TO USE AN ONBOARD WORKOUT The fan features multiple 1. Insert the key into the console. speed settings and an auto mode. When the auto mode See HOW TO TURN ON THE POWER on page 22. is selected, the speed of the fan will automatically 2.
  • Page 25 The workout will continue in this way until the last HOW TO USE A SET-A-GOAL WORKOUT segment of the pro le  ashes in the display and the last segment ends. The walking belt will then slow 1. Insert the key into the console. to a stop.
  • Page 26 HOW TO USE AN IFIT WORKOUT For more information about the iFit workouts, please see www.iFit.com. Note: To use an iFit workout, you must have an optional iFit module. To purchase an iFit module at When you select an iFit workout, the display will any time, go to www.iFit.com or call the telephone show the name, duration, maximum speed setting, number on the front cover of this manual.
  • Page 27 7. Measure your heart rate if desired. THE SETTINGS MODE See step 6 on page 23. The console features a settings mode that keeps track of treadmill information and allows you to personalize 8. Turn on the fan if desired. console settings.
  • Page 28 DEMO——The console features a display demo HOW TO ADJUST THE CUSHIONING SYSTEM mode, designed to be used if the treadmill is dis- played in a store. While the demo mode is turned The treadmill features a cushioning system that on, the console will function normally when you reduces the impact as you walk or run on the treadmill.

  • Page 29: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 30: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following c. Remove the key from the console, and then the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d.
  • Page 31 Locate the Reed Switch (52) and the Magnet (50) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (49). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
  • Page 32 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on,  rst when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center,  rst remove the screws clockwise, 1/4 of a turn.

  • Page 33: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 34: Part List

    PART LIST Model No. 831.24976.1 R0913A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Drive Roller/Pulley #8 x 3/4" Screw Magnet 5/16" x 2 1/4" Bolt Reed Switch Clip 5/16" x 3/4" Screw Reed Switch #10 Star Washer Storage Latch 5/16"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Wheel #8 x 1" Screw Key/Clip #10 Star Washer Cable Tie Handrail Plate 1/4" x 1 1/2" Screw –– User’’s Manual Drive Roller Washer Note: Speci cations are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. 831.24976.1 R0913A...
  • Page 37 EXPLODED DRAWING B Model No. 831.24976.1 R0913A...
  • Page 38 EXPLODED DRAWING C Model No. 831.24976.1 R0913A...
  • Page 39 EXPLODED DRAWING D Model No. 831.24976.1 R0913A...
  • Page 40 ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...

This manual is also suitable for:
