- Page 1 English Lenovo Mobile Phone User Manual Model: Lenovo A706 Read this manual carefully before operating the handset...
-
Page 2: Technical Parameters
Technical Parameters Product WCDMA digital mobile phone Model Lenovo A706 System Android 4.1.2 Approximately 136.3 mm × 69.3 mm × 10.4mm Size Weight Approximately 138g (including battery) Standby Time Max 120 hours* Battery Capacity 2000 mAh NOTES:*May vary depending on local signal strength. -
Page 3: Initial Setup Procedure
Initial Setup Procedure Removing and mounting battery cover To remove the cover, perform the following procedure as shown in the figure. Find the recess in the lower-left corner. Hold the top of your mobile phone. Lift up from the recess. Open the cover. - Page 4 Charging the phone Inserting the SIM card...
- Page 5 Inserting the memory card...
-
Page 6: Port Assignment And Button Layout
Port Assignment and Button Layout Description HOME KEY Can return to the idle interface. Can enter the commonly used, the MENU KEY characteristic and more menus. BACK KEY Can return to the superior menu. According to the volume switch increase VOLUME KEY or decrease volume. -
Page 7: Applications Overview
Applications Overview Icon Name Note Browses websites. The web browser in this unit Browser can access the Internet via the WIFI network for business and personal use. Receives/Sends and views mails by linking Email directly to your mailbox. Browses and edits images. In an image full-screen page it supports slideshow functions Gallery and such operations as, Share, Set as, and... -
Page 8: Gravity Sensor
Gravity sensor Auto rotate screen according to the rotation of the device. To unlock the screen direction: Menu > Settings > Display > Auto-rotate screen. After launching one application, you can rotate the screen to your preferred direction. -
Page 9: Maintenance
Only Lenovo approved batteries, chargers and accessories may be used. Lenovo is not responsible for any consequences due to the use of accessories from a third party. Do not disassemble your mobile phone. - Page 10 special areas, use your mobile phone in accordance with the site’s regulations. Mechanically vibrating or shaking the mobile phone may cause damage. Do not knock your phone screen with a sharp item. Using a cell-phone case or plastic case may damage the surface of your phone.
- Page 11 contact with your body, even through clothing, could cause discomfort or even a skin burn. Avoid keeping your hands, your lap, or any other part of your body in contact with a hot section of the Mobile phone for any extended time.
- Page 12 enters your eye. Should this occur, immediately use clean water to rinse the eye (do not rub the eye), and seek medical treatment. Prevent the battery from being squeezed, compressed, vibrated or shaken. Always try to prevent the battery from short circuit, as this may cause damage to the battery or components connected to it.
- Page 13 Dispose of the battery in accordance with regulations (such as recycling regulations). To prevent explosion or pollution, never dispose of batteries as domestic waste. This battery can only be charged by its dedicated charger. Do not charge out range of 32 °F to 113 °F (0 °C to 45 °C). Charging must not exceed 12 hours.
- Page 14 When using headphones (which you may need to purchase separately), please abide by the following. When using headphones, to avoid hearing damage, remember to adjust the volume to an appropriate level. To avoid breakage, do not pull or drag headphone cables. Using headphones in a high temperature and high humidity environment for a long time can easily damage the headphones or reduce their service life.
- Page 15 maximum wide band true RMS output voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band characteristic voltage of 75 mV. Using headphones that do not comply with EN 50332-2 can be dangerous due to excessive sound pressure levels.
- Page 16 Important Notices – Medical Device Any radio equipment (including this mobile phone) may interfere with the function of medical devices if insufficient measures are taken. Consult the medical personnel or the manufacturer of the medical device if you have any question or you are not sure whether the medical device can shield all RF output.
- Page 17 Polyvinyl Chloride (PVC) cable and cord notice WARNING: Handling the cord on this product or cords associated with accessories sold with this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm.
-
Page 18: Electronic Emission Notices
Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to operate the equipment. - Page 19 Responsible Party: Lenovo (United States) Incorporated 1009 Think Place - Building One Morrisville, NC 27560 Telephone: 1-919-294-5900 FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance void the user’s authority to operate the equipment.
- Page 20 FCC, IC, and the Council of the European Union for each model. The highest SAR value for your Lenovo device when tested for use at the head and body is outlined as follows:...
- Page 21 power of your mobile devices is automatically decreased when full power is not needed for the call. The lower the power output of the device, the lower its SAR value. To meet RF exposure guidelines during body-worn operation, the device must be positioned at least 1.5cm away from your body.
-
Page 22: Recycling And Environmental Information
General recycling statement Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. For information on recycling Lenovo products, go to: http://www.lenovo.com/recycling. - Page 23 WEEE and to minimize any potential effects of EEE on the environment and human health due to the presence of hazardous substances. For additional WEEE information go to: http://www.lenovo.com/recycling. China recycling information for Waste Electrical and Electronic Equipment (WEEE)
- Page 24 Customer participation is important to minimize any potential effects of batteries and accumulators on the environment and human health due to the potential presence of hazardous substances. For proper collection and treatment, go to: http://www.lenovo.com/recycling.
- Page 25 Restriction of Hazardous Substances Directive (RoHS) European Union RoHS Lenovo products sold in the European Union, on or after 3 January 2013 meet the requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment (“RoHS recast”...
- Page 26 China RoHS The information in the following table is applicable for products manufactured on or after March 1, 2007 for sale in the People’s Republic of China.
- Page 27 Turkish RoHS The Lenovo product meets the requirements of the Republic of Turkey Directive on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (EEE). Ukraine RoHS India RoHS RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
