Panasonic PT-LB30NT Specifications
Panasonic PT-LB30NT Specifications

Panasonic PT-LB30NT Specifications

Micro-portable wireless lcd projector

Advertisement

Quick Links

PRODUCT NO.: PT-LB30NT
PRODUCT NAME: Micro-Portable Wireless LCD Projector
M A J O R F E A T U R E S
• High power and portability
- The world's lightest 3,000-lumen
projector*
1
- Ultra-lightweight: 2.6 kg/5.7 lbs.
• Daylight View technology
- A 150% improvement in image
performance*
2
- Vivid colors in a bright room
- Auto operation with ambient light
sensor
*1 As of March 2005
*2 Measurements taken at the five main patches of the
GretagMacbeth color chart, under typical meeting room
light conditions of 400 lux with a screen size of 80 inches.
*3 Supports ASF, WMV, AVI, MPEG4 and MPEG1/2 movie
formats. Copyright protection measures prevent wireless
projection of DVD sources.
S P E C
F I L E
• Easy wireless projection
- Wireless PC motion/sound
streaming*
- High-speed data transfer
- Flexible 16-window index style
- Simple, user-friendly settings
• Quick operation
- 2-second speed start
- One-touch auto setup with digital
keystone correction
- Direct power off
- 1 -
T E N T A T I V E
XGA
3000 lm
3

Advertisement

loading

Summary of Contents for Panasonic PT-LB30NT

  • Page 1 S P E C F I L E T E N T A T I V E PRODUCT NO.: PT-LB30NT PRODUCT NAME: Micro-Portable Wireless LCD Projector 3000 lm M A J O R F E A T U R E S •...
  • Page 2: Specifications

    S P E C F I L E PT-LB30NT Micro-Portable Wireless LCD Projector Specifications Power supply 100 – 240 V AC, 50/60 Hz Power consumption 300 W (approx. 3 W in standby mode with fan stopped) Amps 3.5 A–1.8 A...
  • Page 3 S P E C F I L E PT-LB30NT Micro-Portable Wireless LCD Projector Power cord length 2 m/6.6´ Cabinet material Moulded plastic (ABS/PC) Dimensions (W x H x D) 327 x 75.8 x 233 mm (12-27/32. x 2-31/32. x 9-5/32˝) Weight 2.6 kg (5.7 lbs.)
  • Page 4 S P E C F I L E PT-LB30NT Micro-Portable Wireless LCD Projector Dimensions (3-25/32˝) (8-1/32˝) (12-27/32˝) unit: mm (inch) Note: This illustration is not drawn to scale. Terminals Serial RGB 1 input RGB 2 input/RGB 1 output S-Video input...
  • Page 5: Standard Setting-Up Positions

    S P E C F I L E PT-LB30NT Micro-Portable Wireless LCD Projector Standard setting-up positions unit: mm (inch) ø49 (1-15/16˝) ø43 Upper edge of projected image (1-11/16˝) 116.35 Projected image (4-19/32˝) A: Distance to screen E: Height from the edge of screen to...
