American DJ
Thank you for purchasing this American DJ® product. Please read the manual before installing or
1
2
3
4
5
6
1. Identification Label
2. CHDR Warning Label
3. Projection Aperture
4. Aperture Label
5. non Interlocking Housing Label
6. Mini plug external Power supply
7. emmision Indicator Switch
8. Shutter Control Switch
SPECIFICATIONS: Diode: 4.9mW, Weight 1.5 lbs., Dimensions: 7" x 7.5" x 4"
Supply Voltage: AC 120V adapter AC, 240V adapter or DC (4 AA batteries)
Caution!
No user serviceable parts inside do not attempt repairs. In the event your unit should fail, contact American
.
To purchase parts online visit http://parts.americandj.com
DJ®
This Laser product complies with the CDRH/BRH Radiation Performance Standards. 21 CFR Subchapter J.
WARNING!
T h i s P r o d u c t m u s t n o t b e u s e d f o r a u d i e n c e s c a n n i n g . To p r e v e n t f i r e o r
shock hazard, do not expose this product to a high temperature or high humidity area.
®
7,8,9 10 1112 13 14 15
9. Power Switch
10. Battery Cover (bottom)
11. Auto Speed Control
12.Mode Select
13.Program select knob
14.Program gain knob
15.Certification Label
American DJ
using your new unit.
Laser Widow
WARNING: never Look Directly InTo Laser Beam
CAUTION: Use of controls, adjustments, or procedures other than
those specified herein may result in hazardous
non Interlocking Housing Label
®
LoS AngeLeS, CA. 90058
Owners Manual
radiation exposure.
DANGER
VISIBLE LASER RADIATION
AVOID DIRECT EYE EXPOSURE
LASER DIODE
WAVELENGTH : 635-650 nm
MAX. OUTPUT : < 5 mW
CLASS llla LASER PRODUCT
CHDR Warning Label
AVOID EXPOSURE
Laser light is emitted
from this aperture
Aperture Label
This Laser product complies with the
CDRH/BRH radiation performance
standards. 21 CFR Subchapter J.
Cetification Label
"DAngeR
- Laser radiation
when open. AVoID DIReCT eYe
eXPoSURe." For Class llla acces-
sible laser radiation with an irradiance
greater than 2.5 x 10
Wcm
-3
-2
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American DJ Laser Widow
Summary of Contents for American DJ Laser Widow
- Page 1 American DJ ® Owners Manual Thank you for purchasing this American DJ® product. Please read the manual before installing or using your new unit. Laser Widow ™ WARNING: never Look Directly InTo Laser Beam CAUTION: Use of controls, adjustments, or procedures other than those specified herein may result in hazardous radiation exposure.
- Page 2 ™ Product Description: The Laser Widow™ by American DJ® a new revolution in laser scanner effects! This portable, take anywhere 4.9 mW red laser has 16 pre-set geometric patterns, and gives the user option of battery operation or a UL 115V adapter. The Laser Widow™ has three modes of operation: Auto Speed, Music Mode, &...
- Page 3 LASER WARNINGS AND SAFETY CAUTION IMPORTANT! When installing this projector, make sure that it is mounted in a manner that prevents the audience from looking directly into the beam, and the beam from striking the audience. NON-INTERLOCKED HOUSING WARNING The Galaxian 3D contains high power laser devices internally. Do not open the laser housing, due to the potential exposure to unsafe levels of laser radiation.
- Page 4 fires, burn skin and will cause instant eye injury. Never leave this device running unattended. The operation of a class 3R laser show is only allowed if the show is controlled by a skilled and well- trained operator, familiar with the data included in this manual. The legal requirements for using laser entertainment products vary from country to country.
