Errata
We apologize for the following errors in the V-Synth XT Owner's Manual.
Please make the corrections listed below.
P.41 Step 6
(Incorrect)
To save your patch, use the procedure described in "Saving Patches
(PATCH Write)"(p. 53).
(Correct)
To save your patch, use the procedure described in "Saving Patches
(PATCH Write)"(p. 53) and "Saving Project on Disk (Save
Project)"(p. 132) .
P.78 right column Step 6
(Incorrect)
Save your patch as described in "Saving Patches (PATCH Write)" (p. 75).
(Correct)
Save your patch as described in "Saving Patches (PATCH Write)" (p. 75)
and "Saving Project on Disk (Save Project)"(p. 132) .
P.125 left column "Clock Source"
(Incorrect)
Value
INTERNAL:
The Patch Tempo will be used.
EXTERNAL:
Synchronize to the clock of an external sequencer.
(Correct)
Value
INT:
The Patch Tempo will be used.
MIDI:
Synchronize to the clock of an external MIDI.
USB MIDI:
Synchronize to the clock of an external USB MIDI.
6
V V V V - - - - S S S S y y y y n n n n t t t t h h h h X X X X T T T T
LEAFLET
P.129 right column "KBD Output"
(Incorrect)
KBD Output
(V-LINK Keyboard Output Fade Switch)
Specifies whether the video output from the video device will be stopped
(ON) or will not be stopped (OFF) when you are not holding down a key.
Value:
OFF, ON
(Correct)
Delete
P.156 "Common Group" table
MIDI/USB –Clock Source
(Incorrect)
Parameter
Clock Source
(Correct)
Parameter
Clock Source
For the latest information about MIDI Implementation, please visit
http://www.roland.com/
http://www.roland.co.jp/
Value
INTERNAL, EXTERNAL
Value
INT, MIDI, USB MIDI
40670834
1PD
