High Definition &

06-2011

Easy Graphical User Interface

16Ch/8Ch H.264 Real-time DVR

16CH/8CH H.264 Digital Video Recorder

SRD - 1650/850DC

•

16ch real-time DVR

•

Video (H.264) / Audio (ADPCM)

Up to 480 (NTSC) / 400 (PAL)ips recording rate

•

Up to 16ch audio inputs and 1ch audio outputs

•

Combined BNC and VGA/HDMI video output for main display

•

SRD-1650 : Max 6 internal HDD (HDD x 6)

SRD-1650D : Max 5 internal HDD (HDD x 5)

•

HDD & DVD SATA interface , DDNS

•

Built-in web viewer, DVD-RW (SRD-1650D)

•

PTZ control via Coaxial cable (SRD-1650DC)

www.samsung-security.com

Page 1 Up to 16ch audio inputs and 1ch audio outputs • • Combined BNC and VGA/HDMI video output for main display • SRD-1650 : Max 6 internal HDD (HDD x 6) SRD-1650D : Max 5 internal HDD (HDD x 5) • HDD & DVD SATA interface , DDNS •...
Page 2: Specifications
Application Support Mouse, Remote controller Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD, Protocol Support DIAMOND, ERNA, KALATEL, VCL TP, Vicon PTZ control via coaxial cable [Samsung CCVC, Pelco-C (Coaxitron)] GENERAL Input Voltage / Current 100 ~ 240V AC ±10%, 50/60Hz, Autoranging Electrical Power Consumption Max.

Srd-850dc
