Furuno FR-8062 Specifications

SPECIFICATIONS OF FR-8062/8122/8252
ANTENNA RADIATOR
Type Slotted waveguide array open radiator
Length 4 ft (XN12A) or 6 ft (XN13A)
Rotation Speed 24/36/48 rpm
Wind Load 70 kt relative wind
Beamwidth
4 ft (XN12A): Hor. 1.9°, Vert. 22°
6 ft (XN13A): Hor. 1.35°, Vert. 22°
RF TRANSCEIVER
Frequency 9410 ± 30 MHz (X-band)
Output Power
FR-8062: 6 kW
FR-8122: 12 kW
FR-8252: 25 kW
DISPLAY
Screen Size 12.1" color LCD
Effective Viewing Area 184 (H) x 246 (V) mm
Pixel Number 600 (H) x 800 (V), SVGA
Effective Diameter 184 mm
Echo Colors 32 levels
Echo Trail Gradation 7 levels
Display Modes Head-up, Course-up**, North-up**, True motion***
** Heading data required
*** Heading and speed data required
Range Units nm, sm, km
Range Scales and Range Ring Intervals (nm)
Range: 1/8, 1/4, 1/2, 3/4, 1, 1.5, 2, 3, 4, 6, 8, 12, 16, 24, 36,
48, 64, 72, 96*
*96nm available for the FR-8252 only
Rings: 1/16, 1/8, 1/4, 1/2, 1, 2, 3, 4, 6, 12, 16, 18, 24
Minimum Range 25 m on 0.25 nm range
Range Discrimination 20 m or better
Echo Trails
Type True or relative trails
Trail Length: 15, 30 sec., 1, 3, 6, 15, 30 min., 12, 24 hour., or
continuous Trail
Trail Width: Narrow, Normal
Plotting Facilities (Required optional board ARP-11)
Acquisition: Auto, Manual
Number of targets: 10 targets in 0.1-32 nm
AIS Functions (Data input from AIS is required)
Symbols: Sleeping, Activated, Dangerous, Selected, Lost targets
Number of targets: 100 targets max.
INTERCONNECTION DIAGRAM
Antenna Unit
for FR-8252 for FR-8062/8122
Remote
Controler
RW-9771
10/15/20/30 m
Remote
Power Supply
RW-9807
Unit PSU-008
10/15/20/30 m
RW-9807
5 m
MJ-A10SPF0007-050
MJ-A7SPF0007-050C
External Alarm Buzzer
MJ-A7SPF0007-050C GPS Navigator,
Display Unit
Sounding Equipment
MJ-A7SPF0007-050C
ARP-11
AIS FA-150
AIS Interface Unit
Analog RGB AIS FA-100
IF-1500AIS
Video Output Kit
Satellite Compass
MJ-A6SPF0007-050
SC-50/110,
Rectifier Heading Sensor
Gyro
RU-1746-B2
PG-500
Converter
Rectifier
Gyrocompass
AD-100
RU-3423
3.5 m
Option or
Shipyard Supply
12-24 VDC 100/110/115/220/230 VAC
FURUNO U.S.A., INC. FURUNO ESPAÑA S.A. FURUNO SVERIGE AB
Camas, Washington, U.S.A. Madrid, Spain Västra Frölunda, Sweden
Phone: +1 360-834-9300 Phone: +34 91-725-90-88 Phone: +46 31-7098940
Fax: +1 360-834-9400 Fax: +34 91-725-98-97 Fax: +46 31-497093
FURUNO (UK) LIMITED FURUNO DANMARK AS FURUNO FINLAND OY
Havant, Hampshire, U.K. Hvidovre, Denmark Espoo, Finland
Phone: +44 2392-441000 Phone: +45 36 77 45 00 Phone: +358 9 4355 670
Fax: +44 2392-484316 Fax: +45 36 77 45 01 Fax: +358 9 4355 6710
FURUNO FRANCE S.A. FURUNO NORGE A/S FURUNO POLSKA Sp. Z o.o.
Bordeaux-Mérignac, France Ålesund, Norway Gdynia, Poland
Phone: +33 5 56 13 48 00 Phone: +47 70 102950 Phone: +48 58 669 02 20
Fax: +33 5 56 13 48 01 Fax: +47 70 127021 Fax: +48 58 669 02 21
INTERFACE
Input IEC 61162 NMEA0183 Ver. 1.5/2.0
Output IEC 61162 NMEA0183, Analog RGB video(option)
ENVIRONMENT
Temperature
Antenna Unit: -25°C to +70°C (-13°F to +158°F)
Display Unit: -15°C to +55°C (5°F to +131°F)
Waterproofing
Antenna Unit: IEC60529 IPX6
Display Unit: IEC60529 IPX5 (front panel)
POWER SUPPLY
FR-8062: 10.8-31.2 VDC, 3.2A*
FR-8122: 10.8-31.2 VDC, 3.8A*
FR-8252: 10.8-31.2 VDC, 5.0A*
*24VDC (windless)
EQUIPMENT LIST
Standard
1. Display Unit
2. Antenna Unit (Specify when ordering)
3. Antenna Cable 10, 15, 20 or 30 m
4. Power Cable 3.5 m
5. Power Supply Unit for FR-8252
6. Installation materials and spare parts
Option
1. Rectifier RU-3423
2. Interface Cable MJ-A7SPF0007-050C, 5 m
MJ-A6SPF0007-100, 10 m
3. External Alarm Buzzer OP03-136
4. Auto Plotter ARP-11 (built in display unit)
5. Gyro Converter AD-100
6. AIS Interface Unit IF-1500AIS
7. Analog RGB Video Output Kit for remote display (built in display unit)
8. Remote Control RCU-019-E
Display Unit
186 7.3"
6.9 kg 15.2 lb
172 6.8"
331 13"
320 12.6" 54 2.1"
Table-top mount
Antenna Unit
XN12A
: 25 kg 55.1 lb
XN13A
: 27 kg 59.5 lb
XN12A: 1255 49.4"
XN13A: 1795 70.7"
Display
250 9.8"
250 9.8"
213 8.4"
340 13.4"
357 14.1" 438 17.2"
333 13.1"
Power Supply Unit
13 0.5" 307 12.1"
22.5 0.9"
288 11.3"
PSU-008 (for FR-8252)
2.7 kg 6 lb
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
FURUNO DEUTSCHLAND GmbH
0603XU Printed in Japan
Rellingen, Germany
Phone: +49 4101 838 0
Fax: +49 4101 838 111
LLC FURUNO EURUS
Petersburg, Russia
Phone: +7 812 767 15 92
Fax: +7 812 766 55 52
12.1" Multi-Color LCD RADAR
FR - 8062/8122/8252
1 unit
1 unit Optimized detection with variable antenna rotation speed
1 pc.
1 pc.
1 unit
s12.1" SVGA color TFT LCD with echo colors
1 set
of 32 levels
sSuperior short range target detection
capability
sAdvanced auto modes to automatically
adjust gain, tuning and AC rain/sea for
delivering the best available picture
s48 rpm antenna for high-speed craft as well
as for river use
4- 5
282 11.1"
303 11.9"
Fixing holes
Flush mount
Fixing holes
Bow
Cable entry
4- 15
25
200 7.9''
2-R3
2- 6
Fixing hole
[ 6 kW ] [ 12 kW ]
sTrue motion echo trail
sUp to three programmable radar settings can
be selected to give the best radar performance
in different sea conditions
sAuto plotter ARP-11 for automatic
acquisition and tracking of 10 targets
sDisplays up to 100 AIS targets on the screen
(with optional AIS interface.)
The future today with FURUNO's electronics technology.
9-52 Ashihara-cho, Nishinomiya City, Japan Phone: +81 (0)798 65-2111
Fax: +81 (0)798 65-4200, 66-4622 URL: www.furuno.co.jp
[ 25 kW ]
(option)
Catalogue No. R-190
