Sharp HT-SB60 Operation Manual

ENGLISH
MODEL
HT-SB60
SOUND BAR HOME THEATER SYSTEM
OPERATION MANUAL
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating your SHARP product.
HT-SB60 Sound Bar Home Theater system consisting of HT-SB60 (sound bar system) and CP-SW60 (active
subwoofer system).
TREBLE
BASS
Note:
This product is recommended for flat panel TV (LED, LCD and plasma).
Accessories
The following accessories are included.
Remote Control Subwoofer Stand x 2 Audio Cable x 1 HDMI Cable x 1
(RRMCGA297AWSA) (GITAUA022AW01) (QCNWGA080AWPZ) (QCNWGA077AWPZ)
Wall Mount Angle x 2 Pattern Paper
(LANGKA167AW01)
(TCAUHA031AWZZ)
Printed in Malaysia
TINSZB335AWZZ
12G R AS 1
Precautions
●
In case of an electrical storm, unplug the unit for safety.
General
● Hold the AC power plug by the head when removing it
from the AC outlet, as pulling the cord can damage
● Please ensure that the equipment is positioned in a
internal wires.
well-ventilated area and ensure that there is at least ●
The AC power plug is used as a disconnect device and
4" (10 cm) of free space along the sides, top and back shall always remain readily operable.
● Do not remove the outer cover, as this may result
of the equipment.
in electric shock. Refer internal service to your
4" (10 cm) local SHARP service facility.
4" (10 cm) ● This unit should only be used within the range of 41°F -
4" (10 cm)
95°F (5°C - 35°C).
● SHARP is not responsible for damage due to improper
use. Refer all servicing to a SHARP authorised service
center.
4" (10 cm)
4" (10 cm) 4" (10 cm)
Warnings:
● The voltage used must be the same as that specified on
this unit. Using this product with a higher voltage other
than that which is specified is dangerous and may
result in a fire or other type of accident causing
4" (10 cm)
damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage
other than that which is specified.
● In case of repairing, please bring the entire system set
to the service center.
● Use the unit on a firm, level surface free from vibration.
Volume control
● Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
The sound level at a given volume setting depends on
electronic/electrical equipment (home computers,
speaker efficiency, location and various other factors. It is
facsimiles, etc.) which generate electrical noise.
● advisable to avoid exposure to high volume levels, which
Do not place anything on top of the unit.
● occurs while turning the unit on with the volume control
Do not expose the unit to moisture, to temperatures
setting up high, or while continually listening at high
higher than 140°F (60°C) or to extremely low
volumes.
temperatures.
●
If your system does not work properly, disconnect the
AC power cord from the AC outlet and replug.
Controls and indicators
1 2
3 4 5 6 7 8 9 10
Sound Bar Front Panel
Reference page
1. Left Channel Speakers
6. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2. Right Channel Speakers
7. Demo Indicator . . . . . . . . . . . . . . . . . . . . . . . .11, 15
3. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . 11, 14 8. Sound Mode Button . . . . . . . . . . . . . . . . . . . .12, 14
4. SOURCE Button . . . . . . . . . . . . . . . . . . . . . 9, 10, 13 9. Volume Down Button . . . . . . . . . . . . . . . . . . . . . .12
5. Pairing Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . .12
E-4
Placing the system
Notes:
Installation image:
●
As the sound from the system is omni-directional, you can
place the sound bar anywhere you like. However, it is
recommended to place it as close to the TV as possible.
● The front panel of the sound bar is not removable.
TV
Caution:
● Do not change the installation direction when the sound
bar is turned on.
●
Do not stand or sit on the sound bar and subwoofer as
you may be injured.
Placing the stand
Place the stand as shown.
Sound Bar
DVD player
VCR Subwoofer
Place the system as shown.
Remove the protective film covering the sound bar and
subwoofer before turn on the system.
Stand
System connections
Make sure to unplug the AC power cord before making any connections.
Subwoofer
AC outlet
AC outlet
PAIRING AC 120 V ~ 60 Hz
AC 120 V ~ 60 Hz
AC INPUT
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Sound bar and Subwoofer connection
Caution
●
Do not allow any objects to fall into or to be placed in the bass reflex duct.
● Do not stand or sit on the sound bar/subwoofer. You may be injured.
E-8
General control (continued)
● When pairing is successful:
Muting
On sound bar: "PAIRING" disappears.
The volume is muted temporarily when pressing the
On subwoofer: indicator turns blue.
button on the remote control. Press again to restore the volume.
Note:
When the sound bar is turned off and back on again,
Subwoofer
muting is canceled.
Sound Bar
Sound Mode
Sound bar operation:
PAIRING
To change to a different mode, press the SOUND MODE
button repeatedly until the desired sound mode is
Notes: displayed.
Remote control operation:
● If a device such as microwave oven, wireless LAN card,
Press the desired sound mode button on the remote
Bluetooth device or any other device that uses the
same 2.4GHz frequency near the system, some sound control.
interruption may be heard due to interference.
CINEMA (for cinema sound effect)
● The transmission distance of the wireless signal
MUSIC (for standard sound effect)
between the subwoofer and sound bar is about 32 feet
(10m), but may vary depending on your operating
GAME (for game sound effect)
environment. If a steel-concrete or metallic wall is
SPORT (for sport broadcasting)
between the subwoofer and the sound bar, the system
may not operate at all, because the wireless signal
NEWS (for news)
cannot penetrate metal.
NIGHT (for night)
Caution:
BYPASS (for flat sound effect)
●
Keep the subwoofer away from water and moisture.
● To get the optimum listening performance, make sure
Bass and Treble Control
the area around the sound bar and subwoofer is clear
of any obstacles.
Bass and Treble control is applicable during BYPASS
mode only.
Display brightness control
Bass Control
Press the DIMMER button to adjust the brightness of the 1. Press the BASS button.
display.
2. Within 5 seconds, press the VOL (+ or –) button to adjust
the bass.
Dimmer 1 (Display is dim)
Treble Control
Dimmer 2 (Display gets dimmer)
1. Press the TREBLE button.
2. Within 5 seconds, press the VOL (+ or –) button to adjust
Dimmer Off (Display is bright)
the bass.
Subwoofer level control
Volume auto fade-in
If you turn off and on the sound bar with the volume set to The subwoofer level can be
adjusted.
80 or higher, the volume starts at 40 and fades in to the last
To increase
the level,
set level.
–5 –4
press the SW LEVEL
Volume control button.
To decrease the level, press the SW LEVEL
Sound bar operation: Notes:
Press the VOLUME + ●
When sound from the speaker is distorted, decrease
button to increase the the subwoofer level.
volume and the VOLUME –
..... ● When changing the subwoofer level, the output level of
Min 1 2 99 Max
button for decreasing.
the subwoofer is also changed.
Remote control operation:
Press the VOL + button to increase the volume and the
VOL – button to decrease the volume.
E-12
HT-SB60 EN (A1).indd 1 HT-SB60 EN (A1).indd 1
Special Notes
