Summary of Contents for Clevo D900T
- Page 3 Preface Notebook Computer D900T Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D900T series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
-
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: 1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface 4. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. 5. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified ser- vice personnel. - Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...
-
Page 11: Table Of Contents
External Locator - Front & Rear Views ..........1-6 LCD (D900T) ................A-5 External Locator - Right & Left Side Views ........1-7 Toshiba DVD-ROM Drive (D900T) ..........A-6 External Locator - Bottom View .............1-8 QSI Combo Drive (D900T) ............A-7 Mainboard Overview - Top (Key Parts) .........1-9 DVD Dual Drive (D900T) ............. - Page 12 Preface GLAN RTL110SBL ..............B-20 SATA RAID PDC20378 .............. B-21 LPC Super I/O NS87393 .............. B-22 LPT / COM Port CON / Thermistor ..........B-23 LPC H8 ..................B-24 CODEC ALC880 ................. B-25 Audio Jack & ADJ Power ............B-26 Audio DJ BBVL+ Controller ............
-
Page 13: Introduction
1: Introduction Overview This manual covers the information you need to service or upgrade the D900T series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer. -
Page 14: Specifications
Introduction Specifications Feature Specification Processor Types Intel® Pentium® 4 520/ 530/ 540/ 550/ 560 Processor with HT Technology LGA775 Package (775-pin) (90nm) 90 Nanometer Process Technology, 1024KB On-Die L2 Cache & 800MHz Front Side Bus - 2.8/ 3.0/ 3.2/ 3.4/ 3.6 GHz Core Logic Intel 915P + ICH6 Security... - Page 15 Introduction Feature Specification Storage Options One External USB 1.44Mb Floppy Disk Drive One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive One Changeable Secondary 2.5" 9.5mm (h) Hard Disk Drive RAID (Option) Supports Serial ATA HDD RAID 0, RAID 1, HDD Fault Tolerance System (Optional) One Changeable Primary Optical Device Bay - 12.7 mm (h) for Optical CD/DVD Device Drive Options (see“Optional”...
- Page 16 Introduction Feature Specification Communication Infrared Transceiver 802.11b/g Mini-PCI Wireless LAN Module (Optional) Infrared Transfer 1cm ~ 1M Operating Distance Bluetooth™ Class II V1.2 & 802.11b/g Wireless LAN 115.2K bps SIR Mini-PCI interface Combo Module (Optional) 4M bps FIR IrDA 1.1 Compliant 300K Pixel Video Camera Module (Optional) 10/100/1000 BASE-TX Fast Ethernet LAN on board Integrated V.90/56K Azalia Modem (V.92 Compliant)
-
Page 17: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 - 1 Top View with LCD Panel Open 1. Optional Built-In PC Camera 2. LCD 3. LED Power & Communication Indicators 4. Speakers 5. LED Status Indicators 6. Built-In Microphone 7. -
Page 18: External Locator - Front & Rear Views
Introduction External Locator - Front & Rear Views Figure 1 - 2 Front & Rear Views 1. LCD Latches 2. Audio DJ Player Controls 3. Consumer Infrared Transceiver 4. Speakers 5. Vent/Fan Intake 6. DC-In Jack 7. Serial Port 8. Parallel Port 9. -
Page 19: External Locator - Right & Left Side Views
Introduction External Locator - Right & Left Side Views Figure 1 - 3 Right & Left Side Views 1. S-Video-Out Jack 2. 4 * USB 2.0 Ports 3. 2 * Mini-IEEE 1394a Port 4. Line-In Jack 5. S/PDIF-Out Jack 6. Microphone-In Jack 7. -
Page 20: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 1 - 4 Bottom View 1. Battery 2. Vent/Fan Intake 3. Memory (RAM) Cover 4. Hard Disk Cover 5. Sub Woofer 6. CPU Cover 7. Video Card Cover 1 - 8 External Locator - Bottom View... -
Page 21: Mainboard Overview - Top (Key Parts)
Introduction Mainboard Overview - Top (Key Parts) Figure 1 - 5 Mainboard Top Key Parts 1. PC Card Assembly 2. SATA RAID Controller PDC20378 3. ICH6 I/O Controller Hub 4. Audio DJ BBVL Controller 5. SRS WOW Controller 6. Clock Generator 7. -
Page 22: Mainboard Overview - Bottom (Key Parts)
Introduction Mainboard Overview - Bottom (Key Parts) Figure 1 - 6 Mainboard Bottom Key Parts 1. LGA775 CPU Socket (no CPU installed) 2. Memory Slots (no memory installed) 3. Card Bus PCI-1410 4. LPC H8 5. Audio Codec 6. NS87393 LPC SIO 7. -
Page 23: Mainboard Overview - Top (Connectors)
Introduction Mainboard Overview - Top (Connectors) Figure 1 - 7 Mainboard Top Connectors 1. Speaker (JSPK5) 2. Card Reader(JCR1) 3. Audio DJ (J3) 4. Speaker (JSPK4) 5. Speaker (JSPK3) 6. Keyboard (JINTKB1) 7. Touchpad (JTP1) 8. Speaker (JSPK2) 9. Fan (JFAN2) 10. -
Page 24: Mainboard Overview - Bottom (Connectors)
Introduction Mainboard Overview - Bottom (Connectors) Figure 1 - 8 Mainboard Bottom Connectors 1. Optical Devices (JCD1) 2. Hard Disk (JHDD2) 3. PCI Express VGA (CON2) 4. PCI Express VGA (CON1) 5. PCI Express VGA Heat Sink Fan (JFAN4) 6. Memory Fan (JFAN3) 7. -
Page 25: Disassembly
2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D900T series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard & Shielding Plate: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws from the battery. 3. Lift the battery out of the computer. Figure 2 - 1 Battery Removal a. Remove the 3 screws. b. Lift the battery up. c. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives HDD System with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and Warning utilities (as outlined in Chapter 5 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 5. Release the cable and lift the hard disk assembly up out off the computer. 6. Remove screws in order to separate the bracket from the hard disk(s) & , and disconnect the cable Reverse the process to install a new hard disk(s) Figure 2 - 3 HDD Removal c.
-
Page 32: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) The computer has four memory sockets for 200 pin Small Outline Dual In-line (SO-DIMM) - DDR-II (DDR2) - type memory modules. The total memory size is automatically detected by the POST routine once you turn on your computer. 1. - Page 33 Disassembly Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 2 - The RAM module will pop-up, and you can remove it. Pull the latches to release the other modules if necessary. Insert a new module holding it at about a 30°...
-
Page 34: Removing The Optical Device
Disassembly Removing the Optical Device page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. Locate the hard disk bay cover and remove screws , and remove the bay cover Remove screw and use the screwdriver to push the optical device(s) out of the computer at point Figure 2 - 6... -
Page 35: Removing The Processor
Disassembly Removing the Processor page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the CPU bay cover 3. Carefully lift up the CPU bay cover 4. Remove screws from the heat sink, in the order indicated on the label (and the same screw order when replacing the heat sink) and disconnect cable... - Page 36 Disassembly 6. Unlock the processor by sliding out and raising lever in the direction indicated by the arrow. 7. Raise the CPU lock 8. Lift the CPU off the computer using a vacuum handling tool (as pictured Figure 2 - 8 Processor Removal (cont’d) a.
-
Page 37: Removing The Pci Express Video Card
Disassembly Removing the PCI Express Video Card page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws , and remove the bay cover Figure 2 - 9 3. Remove screws from the heat sink, in the order indicated on the label (and the same screw order PCI Express Video when replacing the heat sink) -
Page 38: Removing The Keyboard & Shielding Plate
Disassembly Removing the Keyboard & Shielding Plate 1. Turn off the computer and remove the battery (page 2 - 2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). 3. -
Page 39: Removing The Modem Module
Disassembly Removing the Modem Module page 2 - 5 page 2 - 13 1. Turn off the computer, remove the battery ( ) and the keyboard and shielding plate ( 2. Remove screws from the modem module 3. Carefully lift up the modem module and disconnect cable Remove the modem module Figure 2 - 11 Modem Module... -
Page 40: Removing The Wireless Lan/Wlan & Bluetooth Combo Module
Disassembly Removing the Wireless LAN/WLAN & Bluetooth Combo Module page 2 - 5 page 2 - 13 1. Turn off the computer, remove the battery ( ) and the keyboard and shielding plate ( 2. Carefully disconnect the antenna cable at point 3. -
Page 41: Removing The Tv Tuner
Disassembly Removing the TV Tuner page 2 - 5 page 2 - 13 1. Turn off the computer, remove the battery ( ) and the keyboard and shielding plate ( 2. Carefully disconnect the antenna cable at point 3. Gently pull the two release latches &... -
Page 42: Removing The Camera Module
Disassembly Removing the Camera Module page 2 - 5 1. Turn off the computer, remove the battery ( 2. Remove screws (and any rubber covers) from the front of the LCD assembly, then run your finger around the middle of the frame to carefully unsnap (and ease forward) the LCD front panel module from the LCD assem- bly. -
Page 43: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the D900T series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 44: Part List Illustration Location
Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part D470W Location page A - 3 page A - 4 Bottom page A - 5 page A - 6 Toshiba DVD-ROM Drive page A - 7... -
Page 45: Top (D900T
Part Lists Top (D900T) Figure A - 1 Top (D900T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top (D900T) A - 3... -
Page 46: Bottom (D900T
Part Lists Bottom (D900T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 2 無鉛 無鉛 Bottom (D900T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Bottom (D900T) -
Page 47: Lcd (D900T
Part Lists LCD (D900T) Figure A - 3 LCD (D900T) LCD (D900T) A - 5... -
Page 48: Toshiba Dvd-Rom Drive (D900T
Part Lists Toshiba DVD-ROM Drive (D900T) Figure A - 4 Toshiba DVD-ROM Drive (D900T) A - 6 Toshiba DVD-ROM Drive (D900T) -
Page 49: Qsi Combo Drive (D900T
Part Lists QSI Combo Drive (D900T) Figure A - 5 QSI Combo Drive (D900T) QSI Combo Drive (D900T) A - 7... -
Page 50: Dvd Dual Drive (D900T
Part Lists DVD Dual Drive (D900T) Figure A - 6 DVD Dual Drive (D900T) A - 8 DVD Dual Drive (D900T) -
Page 51: Hard Disk Drive (D900T
Part Lists Hard Disk Drive (D900T) Figure A - 7 HDD Drive (D900T) Hard Disk Drive (D900T) A - 9... - Page 52 Part Lists A - 10...
- Page 53 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D900T notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
-
Page 54: Schematic Diagrams
Schematic Diagrams System Block Diagram BLOCK DIAGRAM LGA775 Socket for DEVICE REQ/GNT IDSEL PCMCIA INT#C/D PREQ#0 AD16 10.1 CK-410 Prescott or Tejas CPU 1394 INT#E/C PREQ#1 AD17 INT#F/D PREQ#2 AD19 *VGA-Daughter Card* MINI PCI INT#G/D PREQ#3 AD20 MINI PCI INT#H/B PREQ#4 AD21 RAID... -
Page 55: Clock Generator
Schematic Diagrams Clock Generator CKVDD REFOUT R108 ICHCLK14 ICHCLK14 C537 10PF(R) +3VS ICHCLK1411 VDDCPU REFOUT HCB-2012K-121T30 R110 33(R) CODECCLK14 CODECCLK14 24 VDDSRC USBCLK48 C587 C562 C570 C578 C580 C566 C550 10PF(R) VDDSRC C588 0.1UF 0.1UF 0.01UF 0.01UF VDDSRC 0.1UF 10UF(0805) 1UF(0603) USBCLK R111... -
Page 56: Host/Power
Schematic Diagrams CPU-1 Host/Power U24A HA[3..16] HD[0..15] A03# D00# VCORE VCORE VCORE VCORE A04# D01# A05# D02# U24C U24D A06# D03# AH18 AM29 A07# D04# AH19 AM30 A08# D05# AC23 AH21 A09# D06# HA10 AC24 AH22 A10# D07# HA11 AC25 AH25 AN11 A11#... -
Page 57: Gtl+ / Gnd
Schematic Diagrams CPU-2 GTL+ / GND VCCA_VSSA_VCOREPLL Trace width donesn't less than 12 Mil FSBSEL0 R319 BSEL0 1000PF FSBSEL0 BSEL0 U24E U24F As close as possible to CPU socket VTT1.2VS FSBSEL1 BSEL1 CPUPWROK AG23 AN20 FSBSEL1 BSEL1 VTT_OL PROCHOT# 120(R) AG24 AN23 VTT_OR... -
Page 58: Gmch-1 Host/ Pci-E/ Dmi
Schematic Diagrams GMCH-1 Host/ PCI-E/ DMI PCIE_TXP[0..15] PCIE_TXP[0..15] PCIE_TXN[0..15] PCIE_TXN[0..15] PCIE_RXP[0..15] PCIE_RXP[0..15] PCIE_RXP0 PCIE_TXP0 HA[3..31] HD[0..63] EXPARXP0 EXPATXP0 PCIE_RXN[0..15] PCIE_RXN0 PCIE_TXN0 PCIE_RXN[0..15] HA3# HD0# EXPARXN0 EXPATXN0 PCIE_RXP1 PCIE_TXP1 HA4# HD1# EXPARXP1 EXPATXP1 PCIE_RXN1 PCIE_TXN1 HA5# HD2# EXPARXN1 EXPATXN1 PCIE_RXP2 PCIE_TXP2 HA6# HD3# EXPARXP2... -
Page 59: Gmch-2 Ddr2
Schematic Diagrams GMCH-2 DDR2 DDRVCC MAAA0 AP26 DQSA0 MAAB0 AM15 DQSB0 SMA_A0 SDQS_A0 SMA_B0 SDQS_B0 MAAA1 AR24 DQSA#0 MAAB1 AR15 DQSB#0 SMA_A1 SDQS_A0# SMA_B1 SDQS_B0# MAAA2 AL24 SDMA0 MAAB2 AN15 SDMB0 SMA_A2 SDM_A0 SMA_B2 SDM_B0 R452 MAAA3 AP23 MDA0 MAAB3 AL15 MDB0 SMA_A3... -
Page 60: Gmch-3 Pwr / Gnd
Schematic Diagrams GMCH-3 PWR / GND +1.5VS +1.5VS VTT1.2VS DDRVCC AJ15 AC11 AC25 AD10 VSS_201 VSS_301 VSS_1 VSS_101 VCCNCTF VSSNCTF AJ16 AB11 AB25 AR33 VSS_202 VSS_305 VSS_2 VSS_102 VCCNCTF VSSNCTF VCCSM AJ19 AA25 AR31 C569 C556 C123 C120 VSS_203 VSS_307 VSS_3 VSS_103 VCCNCTF... -
Page 61: Ddr2 Dimm-A
Schematic Diagrams DDR2 DIMM-A DDRVCC DDRVCC JDIM3 JDIM4 MAAA[0..13] 6,10 MAAA[0..13] MDA[0..63] 6 MAAA0 MDA0 MAAA0 MDA0 MAAA1 MDA1 MAAA1 MDA1 MAAA2 MDA2 MAAA2 MDA2 MAAA3 MDA3 MAAA3 MDA3 MAAA4 MDA4 MAAA4 MDA4 MAAA5 MDA5 MAAA5 MDA5 MAAA6 MDA6 MAAA6 MDA6 MAAA7 MDA7... -
Page 62: Ddr2 Dimm-B
Schematic Diagrams DDR2 DIMM-B DDRVCC DDRVCC JDIM2 JDIM1 MDB[0..63] 6 MAAB[0..13] 6,10 MAAB[0..13] MAAB0 MDB0 MAAB0 MDB0 MAAB1 MDB1 MAAB1 MDB1 MAAB2 MDB2 MAAB2 MDB2 MAAB3 MDB3 MAAB3 MDB3 MAAB4 MDB4 MAAB4 MDB4 MAAB5 MDB5 MAAB5 MDB5 MAAB6 MDB6 MAAB6 MDB6 MAAB7 MDB7... -
Page 63: Ddr2 Terminator
Schematic Diagrams DDR2 Terminator DDR2 TERMINATION CHANNEL A CHANNEL B DDRVCC DDRVCC DDRVREF GEN. & DECOUPLING DDRVREF GEN. & DECOUPLING R139 C150 C156 C154 C100 C465 C471 Trace Width 12 Mil Trace Width 12 Mil Space 20 Mil Space 20 Mil 75_1% 0.1UF 0.01UF... -
Page 64: Ich6-1
Schematic Diagrams ICH6-1 R538 8.2K R539 8.2K 16,18,19,20,28 AD[0..31] U11B U11A R540 8.2K +3VS GPI6 AD19 LPC_AD0 AD_0 16,18,19,20,28 GPI6 (+3VS) LAD_0/FB0 LPC_AD0 21,23 GPI7 LPC_AD1 DEVSEL# AE19 AD_1 DEVSEL# DEVSEL# 16,18,19,20,28 GPI7 (+3VS) LAD_1/FB1 LPC_AD1 21,23 EXTSMI# LPC_AD2 PCLKICH AD_2 PCICLK PCLKICH 2... -
Page 65: Ich6-2 Pwr / Gnd
Schematic Diagrams ICH6-2 PWR / GND RB751V +3VS +3VS R487 1K(R) +5VS U11D C219 1U(0603) C870 0.1U R129 R467 +3VS RB751V(R) 10K(R) +3VS PWROKICH U11C R126 11,29 VCORE_PWRGD PWROKICH 5,11 RESET# +1.5VS AA22 +2.5VS +1.5VS V5REF VCC1_5 AA18 AA23 R463 6.8K 1% +1.5VS V5REF... -
Page 66: Vga Daughter Connector
Schematic Diagrams VGA Daughter Connector CON1 TXN0 TXCN CON2 TXN0 TXCN TXP0 TXCP TXP0 TXCP TXN1 DAC1_HSYNC DAC1_HSYNC C287 TXN1 TXP1 DAC1_VSYNC C286 C285 0.1UF/50V(0603) DAC1_VSYNC TXP1 0.1UF/50V(0603) 0.1UF/50V(0603) TXN2 DAC1_R TXN2 DAC1_R TXP2 DAC1_G TXP2 DAC1_G DAC1_B +3VS +5VS DAC1_B TV-COMP TV-COMP... -
Page 67: Dvi / Tv-Out / Video-In Con
Schematic Diagrams DVI / TV-Out / Video-In Con PORT +5VS +5VS Close to DVI PORT +3VS BK2125HS121 +5VS 10P(R) DA221(R) DA221(R) 2N7002 10P(R) CASE CASE HSYNC TXN2 R244 DAC1_HSYNC TXN2 TMDS DATA 2- TXP2 R245 TXP2 TMDS DATA 2+ 10P(R) TMDS 2/4 Shield R252 VSYNC... -
Page 68: Panel Con / Led Indicator
Schematic Diagrams Panel Con / LED Indicator GND_LVDS JTV1 +3VS +3VCDROM LVDS_LN0 TXOUT-LIN0 R635 0(0402)(R) LCDVCC LCDVCC LVDS_LP0 TXOUT-LIP0 R636 0(0402)(R) FCM2012V-121 FCM2012V-121 R637 R638 C307 LVDS_LN1 TXOUT-LIN1 R639 0(0402)(R) JLCD1 LVDS_LP1 TXOUT-LIP1 0(1206) 0(1206)(R) R640 0(0402)(R) 0.1UF 0.1UF LCDVCC 60 mil 4800 LVDS_LN2... -
Page 69: Pcmcia Ti1410
Schematic Diagrams PCMCIA TI1410 B_VCC JPCM1 B_VCC B_CD0 B_CD1 C714 C746 C743 C755 C760 C759 C713 C753 C749 C738 C229 C709 B_CD2 B_CD3 C733 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V B_CD4 B_CD5 0.1UF B_CD6 B_CD7 B_VPP B_CD8... -
Page 70: Pcmcia Power / Fan Con
Schematic Diagrams PCMCIA Power / Fan Con VDD5 +12V R107 4.7K BVCC B_VCC C234 R390 R112 1K(1206) BVCC C236 C233 4.7K(R) NDS352AP 2SB1198K(R) CPU FAN1 BVCC 0.1UF 1SS355 0.1UF 4.7U(0805) JFAN1 40MIL CPUFAN_ON 40MIL CPUFAN_ON CPUF1_SEN# R388 2N7002 C126 10MIL CPUF1_SEN# B_VPP BVPP... -
Page 71: Pci 1394A Ti Tsb43Ab22
Schematic Diagrams PCI 1394a TI TSB43AB22 60 mil 60 mil R690 0(R)(1206) 1394VCC 1394VCC R691 0(1206) +3VS R594 4.7K 1394VCC R595 C871 C872 C873 R596 4.7K R597 4.7K 10U(0805) 0.01U 0.1U R598 4.7K C874 C875 C876 C877 C878 C879 10U(0805) 0.1U 0.1U 0.01U... -
Page 72: Glan Rtl110Sbl
Schematic Diagrams GLAN RTL110SBL LAN_DVDD LANVDD3 100 mil 40 mil BK2125HS121 BK2125HS121 LANVCC1.3 JLAN1 C377 C385 C356 C333 C331 C374 C387 C386 0.1U RING 10U(0805) 0.1U 10U/10V(0805) FCM1608K121 RING 10U(0805) 0.1U 0.1U 0.1U 0.1U FCM1608K121 MDC 2P V_DAC LAN_AVDDL MDI0+ TCT1 MCT1 TD1+... -
Page 73: Sata Raid Pdc20378
Schematic Diagrams SATA RAID PDC20378 RAID3.3V JHDD2 R_PHDRVRST# R_PPHD8 R_PPHD7 C771 C793 C253 C785 C245 C227 C789 C788 C228 C273 R_PPHD9 R_PPHD6 0.01U 0.01U 0.01U 0.1U 0.1U 0.1U 0.1U 4.7U(0805) 4.7U(0805) 4.7U(0805) R_PPHD10 R_PPHD5 R211 R_PPHD11 R_PPHD4 R_PPHD12 R_PPHD3 BK2125HS121(R) BK2125HS121(R) L100 R_PPHD13... -
Page 74: Lpc Super I/O Ns87393
Schematic Diagrams LPC Super I/O NS87393 +3VS C643 C639 C662 0.1UF 0.1UF 0.1UF PD[0..7] LPC_AD[0..3] PD[0..7] 22 11,23 LPC_AD[0..3] +3VS SA10 SA11 LPC_AD0 LPC_AD1 LAD0 PD0/INDEX# SA12 LPC_AD2 LAD1 PD1/TRK0# SA13 +5VS SA14 +5VS LPC_AD3 LAD2 PD2/WP# R440 LAD3 PD3/RDATA# SA15 PD4/DSKCHG# SA16... -
Page 75: Lpt / Com Port Con / Thermistor
Schematic Diagrams LPT / COM Port CON / Thermistor design value ---> R716 470K R717 C951 R718 depends on the temperature 1.91K 1% 0.1U 100K 1% R719 R720 U47A Normal : 0 Active : 1 Shutdown_stb_power 31 LM358 R721 C952 F01J2E Thermistor --->... -
Page 76: Lpc H8
Schematic Diagrams LPC H8 Trace width 40 mil C589 0.1UF VDD3 VDD5 3VH8 C720 0.1UF R425 10K(R) 10UF/10V(0805) H8BEEP 3VH8 +5VS HCB3216K-800T30 H8_BEEP R424 10K(R) VDD3 C742 C221 C745 C747 C721 10UF/10V(0805) 1100 mA JTP1 0.1UF 0.1UF 0.1UF C288 270PF 0.1UF TP_DATA TC7SZ08... -
Page 77: Codec Alc880
Schematic Diagrams CODEC ALC880 L106 BK2125HS121(0805) BK2125HS121(0805)(R) +3VS VDDAC +5VCDROM C901 C902 C903 C904 C905 C906 U31 78L05(SO8) CODECCLK14 R666 0(R) 40MIL 40MIL CODECCLK14 10U/10V(0805) 0.1U 0.1U 0.1U 10U/10V(0805) VDDAC +12V R667 1M(R) 10U/10V(0805) ACZ_RST# R468 10K(R) C623 C634 C620 AGND AGND C907... -
Page 78: Audio Jack & Adj Power
Schematic Diagrams Audio Jack & ADJ Power BK2125HS121(0805) +3VCDROM VDDAC VDD3 VDD3 C668 C667 C625 C626 C645 C642 XTL_IN R694 R776 10U/10V(0805) 0.1U 0.1U 0.1U 10U/10V(0805) R464 10U/10V(0805) TVPWR_ON# ADJ_ON# AGND AGND C666 24.576MHz C665 ADJ_ON 2N7002 TVPWR_ON 2N7002 23,31 ADJ_ON 15,23,31 TVPWR_ON... -
Page 79: Audio Dj Bbvl+ Controller
Schematic Diagrams Audio DJ BBVL+ Controller +5VCDROM TO CD ROM +5VCDROM 80MIL +5VCDROM 30 mil +3VCDROM VCC5 JCD1 RP86 30 mil VCC5 CD_R CD_L CINTRQ 24,25 CD_R CD_L 24,25 CDGND CCD1 CCD3 CDGND 24,25 CCD8 CRESET C254 C277 C241 C262 C238 C266 CCD2... -
Page 80: Usb / Cr / Ccd Con / Srs
Schematic Diagrams USB / CR / CCD Con / SRS AUDIO PROCESSOR HCB2012K-500T40 60MIL USBVCC0 R281 150K C364 C352 R283 270K 0.1U 0.1UF 100UF R734 0(R) JUSB1 LOUT-L C959 1U R735 0(R) OC#0 24,25 LOUT-L LOUT-R C960 1U 24,25 LOUT-R VCC0 GND1 USBP2_C... -
Page 81: Mini-Pci / Nc / Mdc / Bt Con
Schematic Diagrams Mini-PCI / NC / MDC / BT Con CIR_RX CIR_RX_M 15,23,26 CIR_RX R770 AD[0..31] WLESS_EN_LED R288 2.7K WLESS_ENA AD[0..31] +3VS AD[0..31] 11,16,18,19,20 15,23 WLESS_EN_LED AD[0..31] 11,16,18,19,20 Svideo_C 1SS355 R700 5.1K Svideo_C Svideo_Y Svideo_Y +3VS +3VS +3VS +3VS JMINIPCI2 JMINIPCI1 CIR_RX_M C464... -
Page 82: Vcore
Schematic Diagrams VCORE SYS5V SYS3V CSCOMP 2N3906 PC85 VCC5_DRV PQ85 15uF/25V PR98 PR94 RB751V VDD5 100K PR171 PC83 PC86 PC186 PC187 PC188 15uF/25V(R) PC170 PC171 FS1J3 PC89 PC15 0.1U 0.1U 0.1U 0.1U VR_ON 0.1UF PR172 390K 470PF TEST_C 4.7uF(0805) 0.1uF PC172 PR71 PR173... -
Page 83: Ddr Power
Schematic Diagrams DDR Power VIN_A VIN1 PD44 1SS355 PC161 10U/10V(1206) PC158 PC48 PC154 0.1U PC155 PD17 10U/35V(1210) PC156 10U/35V(1210) RB751V 10U/35V(1210) PQ36 PC50 AO4422 PD16 PC49 PQ34 BOOST1 INTVCC IRF7821 DDRVTT RB751V PR133 BOOST2 DDRVCC PR134 PQ35 10m(2010) 4.7uH AO4422 PC140 PC145 PD40... -
Page 84: System Power
Schematic Diagrams System Power PQ39 2SC4672 150mA 12VIN VDD5 3VH8 VIN1 PU13 CM2831SIM25 PR144 PR132 PR41 PD45 PC162 PD13 1SS355 11FS2 10U(1206) PQ40 PR145 PC60 PC143 10U(1206) PC147 PC142 2.2U(0805) 2SD1782 PC30 PC33 PC55 PR143 0.01U PC31 10U/35V(1210) 10U/10V(1206) 0.1u 10K_1% PD15 PC46... -
Page 85: Charger
Schematic Diagrams Charger PD11 SCD34 PQ22 PQ24 AO4407 AO4407 PD10 2.5A CDRH-1205-470 2.5A PR17 100m(2512) PC129 PC29 PC126 PC128 PD33 SCD34 PQ23 PC132 PC133 PD35 0.1U 10U/35V(1210) 10U/35V(1210) 0.1U PR116 SCD34 PC123 AO4407 1SS355 PC127 PC125 0.1U(0805)/25V 0.1U(1206) 100K 10U/35V(1210) 10U/35V(1210) 0.1U(1206) PR123... -
Page 86: Audio Board
Schematic Diagrams Audio Board IEEE1394a 1394A2 /TPA1+_1 /TPA1-_1 TPA-_B_C /TPA1-_1 /TPA1+_1 TPA+_B_C TPB-_B_C TPB- /TPB1+_1 TPB+_B_C TPB+ /TPB1-_1 /TPB1+_1 TPB+_B_C TPA-_B_C TPA- TPA+_B_C TPA+ /TPA0+_1 /TPB1-_1 TPB-_B_C /TPA0-_1 CM-4M3216-181JT 1394a_CON /TPB0+_1 GND_A /TPB0-_1 1394A1 ACES-85204-1200 /TPB0-_1 TPB-_A_C GND_A /TPB0+_1 TPB+_A_C TPB-_A_C TPB- TPB+_A_C... -
Page 87: Audio Dj Board
Schematic Diagrams Audio DJ Board RD_1 FF_1 T512 0(R)(0805) LED1 SG1/KS1 +3VCDROM_B PLAY_PAUSE_1 T513 SG2/KS2 STOP_EJECT_1 LCD_RD_1 BR10 BR11 0(0805) +5VCDROM_B DOUT SG3/KS3 COM2 VOLUM_DOWN_1 LCD_DATA_1 BR12 SG4/KS4 COM1 VOLUM_UP_1 LCD_WR_1 BR13 SG5/KS5 DIG7 REPEAT_1 LCD_CS_1 BR14 SG6/KS6 DIG6 ADJ_PWRS_1 SG7/KS7 DIG5 BR15... -
Page 88: Cd-Rom Board
Schematic Diagrams CD-ROM Board +5VCDROM_D MASTER DJCD1 INT_CD_R_1 0.01UF 0.01UF INT_CD_L_1 TZ1701_1 CD_GND_1 CDD[8]_1 CRESETN_1 CDD[9]_1 CDD[7]_1 CDD[10]_1 CDD[6]_1 CDD[11]_1 CDD[5]_1 CDD[12]_1 CDD[4]_1 CDD[13]_1 CDD[3]_1 CDD[14]_1 CDD[2]_1 CDD[15]_1 CDD[1]_1 CDMARQ_1 CDD[0]_1 CDIORN_1 CDIOWN_1 CDMACKN_1 CIORDY_1 T149 CINTRQ_1 Z1709_1 CDA[1]_1 CDA[2]_1 CDA[0]_1 CCS[1]_1 CCS[0]_1... -
Page 89: Click Board
Schematic Diagrams Click Board VCC5_T VCC5_T VCN2 VCN1 10MIL 10MIL TPADDATA TPADDATA TPADCLK TPADCLK ACES-85202-0405 10MIL 0.1U SW_L 0(R) 120P 120P 120P SW_R Sheet 36 of 37 ACES-87152-1207 GND_T plan Click Board GND_T VCC5_T VCC5_T VSWEB1 VSWEB2 SW_R SW_L HCH STS-05-A HCH STS-05-A GND_T GND_T... -
Page 90: Switch Board
Schematic Diagrams Switch Board VIN_E SCROLLOCK_1 220(0805) EJSW1 SML_010MT_G CAPSLOCK_1 PWRS_1 220(0805) LID_SW#_1 WEB0#_1 SML_010MT_G WEB1#_1 NUMLOCK_1 WEB2#_1 220(0805) +3V_E +3VS_E SML_010MT_G SCROLLOCK_1 CR_LED_1 CAPSLOCK_1 220(0805) NUMLOCK_1 HDD_LED_1 SML_010MT_G CR_LED_1 +3VS_E TV_DVD_ON_1 220(0805) 20MIL RY_SP150DNB74_P1 CON15R Sheet 37 of 37 GND_E GND_E Switch Board...
