Fujitsu LifeBook C2110 Bios Manual

Lifebook c series
Hide thumbs Also See for LifeBook C2110:

Advertisement

Quick Links

Download this manual See also: Owner's Manual

Fujitsu LifeBook

C Series
BIOS Guide
LifeBook C Series Model:
C2110
Document Date: 04/05/02
Document Part Number: FPC58-0668-01
F U J I T S U P C C O R P O R A T I O N

Advertisement

loading

Related Manuals for Fujitsu LifeBook C2110

Summary of Contents for Fujitsu LifeBook C2110

  • Page 1: Fujitsu Lifebook

    Fujitsu LifeBook C Series BIOS Guide LifeBook C Series Model: C2110 Document Date: 04/05/02 Document Part Number: FPC58-0668-01 F U J I T S U P C C O R P O R A T I O N...

  • Page 2: Bios Setup Utility

    L i f e B o o k C S e r i e s B I O S C Series BIOS BIOS SETUP UTILITY The BIOS Setup Utility is a program that sets up the operating environment for your notebook. Your BIOS is set at the factory for normal operating condi- tions, therefore there is no need to set or change the BIOS environment to operate your notebook.
  • Page 3 3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key. 4. When the setup utility starts with a fault present, the system displays the following message: Warning! Error message [Continue] 5.
  • Page 4 L i f e B o o k C S e r i e s B I O S MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS The Main Menu allows you to set or view the current system parameters. Follow the instructions for Navi- gating Through The Setup Utility to make any changes.
  • Page 5 Table 1: Fields, Options and Defaults for the Main Menu Note that the parameters listed below may differ, as determined by your system configuration. Menu Options Field Floppy Disabled Disk A: [1.44/1.2 MB 3.5"] Primary Selects Primary Master: Master submenu Secondary Selects Master:...
  • Page 6 L i f e B o o k C S e r i e s B I O S Primary Master Submenu of the Main Menu The Primary Master submenu identifies what ATA devices are installed. Main Primary Master [TOSHIBA MK2018GAP -(PM)] Type: Total Sectors: Maximum Capacity:...
  • Page 7 Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu Menu Field Options Sectors: A number between 0 and 63 Maximum Display only Capacity: LBA Format (Logical Block Addressing) Total Sectors: –— Maximum –— Capacity Multi-Sector Disabled Transfers:...
  • Page 8 L i f e B o o k C S e r i e s B I O S C A U T I O N A bootable CD-ROM may have a floppy disk format or a hard drive format. When the bootable CD-ROM is used, the drive allocations change automatically without changing the BIOS setup.
  • Page 9 Secondary Master Submenu of the Main Menu The Secondary Master submenu is for the internal CD- ROM drive. The drive type is displayed on this menu as well as the Main menu. Your notebook auto-senses the characteristics of the internal CD-ROM Drive installed. Main Secondary Master [TOSHIBA DVD-ROM -SD-R2102 -(SM)] Type:...
  • Page 10 L i f e B o o k C S e r i e s B I O S Table 3: Fields, Options and Defaults for the Primary Slave Submenu of the Main Menu Menu Field Options Transfer Mode: Standard Fast PIO 1 Fast PIO 2 Fast PIO 3...
  • Page 11 ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: Set the I/O addresses for the ports. Set the communication mode for the parallel and infrared ports. Set the features of the keyboard/mouse. Select between the display panel and an external CRT display.
  • Page 12 L i f e B o o k C S e r i e s B I O S Table 4: Fields, Options and Defaults for the Advanced Menu Menu Field Options Serial/Parallel Port –— Configurations Keyboard/Mouse –— Features Video Features –—...
  • Page 13 Serial/Parallel Port Configuration Submenu of the Advanced Menu The Serial/Parallel Port Configuration submenu provides the ability to set the I/O addresses and inter- rupt levels for the parallel port of your notebook. C A U T I O N I/O addresses, DMA channels, and Interrupt levels can be entered in various ways, including via the BIOS setup utility, the control software for the I/O device, or the hardware.
  • Page 14 L i f e B o o k C S e r i e s B I O S Table 5: Fields, Options and Defaults for the Port Configuration Submenu of the Advanced Menu Menu Field Options Parallel Port: Disabled Enabled Auto Mode:...
  • Page 15 Keyboard/Mouse Features Submenu of the Advanced Menu The Keyboard/Mouse Features submenu is for selecting the power-on state for the Numlock key. Advanced Keyboard/Mouse Features Numlock: Help Exit Table 6: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu Menu Field Options Numlock:...
  • Page 16 L i f e B o o k C S e r i e s B I O S Video Features Submenu of the Advanced Menu The Video Features Submenu is for choosing the display. Main Advanced Video Features Display: Compensation: Help Select Item...
  • Page 17 Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configurations submenu allows the user to enable or disable IDE ports. Main Advanced Internal Device Configurations IDE Controller Help Exit Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu Menu Field Options IDE Controller:...
  • Page 18 L i f e B o o k C S e r i e s B I O S CPU Features Submenu of the Advanced Menu The CPU Features Submenu configures the system processor. Main Advanced SpeedStep(TM) Technology: On Battery: On AC: Help Exit...
  • Page 19 USB Features Submenu of the Advanced Menu The USB Features Submenu configures the system for use with a USB floppy drive. Main Advanced USB Features USB Floppy Disk: Help Exit Table 10: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu Menu Field Options USB Floppy Disk:...
  • Page 20 L i f e B o o k C S e r i e s B I O S Miscellaneous Configurations Submenu of the Advanced Menu The Miscellaneous Configurations Submenu configures the power button. Main Advanced Miscellaneous Configurations Power Button: Help Exit Table 11: Fields, Options and Defaults for the Miscellaneous Configuration Submenu of the Advanced Menu...
  • Page 21 Event Logging Submenu of the Advanced Menu The Event Logging Submenu configures event logging features for DMI events. Main Advanced Event Log Capacity: Event Log Validity: View Event Log: Event Logging: System Boot Event: Clear All Event Logs: Mark Events as Read: Help Exit Table 12: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu...
  • Page 22 L i f e B o o k C S e r i e s B I O S SECURITY MENU – SETTING THE SECURITY FEATURES The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration.
  • Page 23 Main Advanced Supervisor Password Is: User Password Is: Set Supervisor Password Set User Password Minimum User Password Length: Password on Boot: KB Lock on Resume: Boot from Removable Media: Hard Disk Security Owner Information Help Exit Table 13: Fields, Options and Defaults for the Security Menu Menu Field Options Supervisor...
  • Page 24 L i f e B o o k C S e r i e s B I O S Table 13: Fields, Options and Defaults for the Security Menu Menu Field Options Password on Boot: Disabled First Boot Every Boot KB Lock on Disabled Resume:...
  • Page 25 Hard Disk Security Submenu of the Security Menu The Hard Disk Security Submenu is for configuring hard disk security features. Main Advanced Primary Master: Secondary Master: Help Exit Table 14: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu Menu Field Options Primary Master:...

  • Page 26: Exiting From The Security Menu

    L i f e B o o k C S e r i e s B I O S Owner Information Submenu of the Security Menu The Owner Information Submenu is for setting owner information. Main Owner Information Is: Set Owner Information Foreground Color: Background Color: Help...
  • Page 27 BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE The Boot Menu is used to select the order in which the BIOS searches sources for the operating system. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through The Setup Utility on page 2 for more information.) Main Advanced...
  • Page 28 L i f e B o o k C S e r i e s B I O S The Boot Device Priority Submenu of the Boot Menu The Boot Device Priority Submenu is for setting the order of checking of sources for the operating system. Main Advanced Boot Device Priority...
  • Page 29 INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION The Info menu is a display only screen that provides the configuration information for your notebook. The following table shows the names of the menu fields for the Info menu and the information displayed in those fields.
  • Page 30 L i f e B o o k C S e r i e s B I O S EXIT MENU – LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes.
  • Page 31 Table 19: Fields, Options and Defaults for the Exit Menu Optional Keyboard Menu Field Shortcut Load Setup Press F9 key Defaults Discard Changes –— Save Changes –— Default Description –— Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message Load default configuration now? [Yes] [No].
