Settings On The Front Panel; Software Printer Setting - Sharp AL-1000 Series Operation Manual

PRINTING FROM AN MS-DOS APPLICATION
Click the Start button.
1
Select Settings and then click Printers.
2
Right-click the AL-1000 Series icon in the printer dialog box and click Properties.
3
2
Click the Details tab in the Properties dialog box.
4
Click the Port Settings button.
5
Check that "Spool MS-DOS print jobs" is checked in the port setting dialog box.
6

Settings on the front panel

Paper size, tray selection, and other options are set from the front panel. Use the following
procedure to start the front panel.
Windows 95/Windows 98/Windows NT 4.0:
Click Start, Program, SHARP AL-1000 Series, and DOS Emulation Setup.
1
Windows 3.1x:
Double-click the DOS Emulation Setup icon in the SHARP AL-1000 Printer Group in
1
Program Manager.

Software printer setting

Set your MS-DOS application to use the following model printer.
HP LaserJet Series II (PCL4)
If this printer is not listed on the application's printer setup, choose a PCL4 compatible printer.
22
For this description, it is assumed that the mouse is configured for right hand
operation.
