Owner’s Instructions SWT13S2 Before operating the unit, please read this manual throughly, and retain for future reference. BEFORE USING THE WASHER CAUTIONS PRECAUTIONS WHEN OPERATING DESCRIPTION OF PARTS CONTROL PANEL WASHING PROCEDURE TO WASH SPIN DRY RINSING OVER FLOW RINSE ADDITIONAL RINSE INSTALLATION ENVIRONMENT...
BEFORE USING THE WASHER Remove the cap-hose from the drain In case of pump drained washer, hose. remove the cap-hose from the drain hole. CAUTIONS Be sure that the washer is grounded. Disconnect the power cord from the power supply when not in use. To avoid electrical shock,use a metal pipe for the ground connection.
CONTROL PANEL 1. WATER SELECTOR 4. CYCLE SELECTOR During washing, WATER SELECTOR KNOB This is used to set the Washing/Rinsing or Draining. should be selected to wash. During spin rinsing, WATER SELECTOR KNOB should be selected 5. SPIN DRY TIMER to spin.
WASHING PROCEDURE TO WASH 1. Before starting washing, check the 7. Set the WASH TIMER 1-35 minutes. following; Connect the water supply SOAK SOAK hose and open the water tap. • Set the WASH TIMER • Lay the drain hose down toward a to the point more sinkhole.
WASHING PROCEDURE SPIN DRY 1. Transfer the clothes into the spin basket 3. Close the spin dryer lid. and arrange the clothes evenly. 2. Be sure to attach the safety cover and 4. Set the SPIN DRY TIMER 1-5minutes. close the inner lid. inner lid safty cover RINSING...
OVER FLOW RINSE 1. Keep suppling water 3. As soon as the WASH TIMER shuts off, (adjust water pressure to ensure that turn off the water tap. the amount of water supplied does not exceed that water drained.) 2. Set the WASH TIMER 6~8minutes. 4.
INSTALLATION ENVIRONMENT Leave some space HOW TO CLEAN THE FILTER (In case drain pump) Space at last 15cm between the washer 1. Place a rag under the washer filter and the wall. not to wet the floor. 2. Rotate the filter counterclockwise Place the washer on a sturdy flat surface.
IF YOU NEED HELP. Do not hesitate to call your local samsung service center. They will be willing to help you. Be sure to give them your name,address,telephone number and the purpose of the call. SPECIFICATION DIMENSIONS (mm) W860mm x D525mm x H1040mm 0.05~0.78 MPa...
