MAN-KEH-P5010R-GB_B.fm Page 1 Friday, October 6, 2000 2:22 PM
Multi-CD control High power cassette player with RDS tuner
Q

Advertisement

loading

Related Manuals for Pioneer KEH-P4010R

Summary of Contents for Pioneer KEH-P4010R

  • Page 1 MAN-KEH-P5010R-GB_B.fm Page 1 Friday, October 6, 2000 2:22 PM Multi-CD control High power cassette player with RDS tuner...
  • Page 2 MAN-KEH-P5010R-GB_B.fm Page 2 Friday, October 6, 2000 2:22 PM Installation with the rubber bush ....3 • Repeat Play Removing the Unit ........3 • Blank Skip • Radio Intercept • Repeat Play • Head Unit ..........6 • Random Play • Steering Remote Controller (CD-SR80) .6 •...
  • Page 3 MAN-KEH-P5010R-GB_B.fm Page 3 Friday, October 6, 2000 2:22 PM • Before finally installing the unit, connect the wiring temporarily, making sure it is all connected up properly, and the unit and the system work properly. • Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.
  • Page 4 MAN-KEH-P5010R-GB_B.fm Page 4 Friday, October 6, 2000 2:22 PM • When this product’s source is switched ON, a control signal is output through the blue/white • This unit is for vehicles with a 12-volt battery and negative grounding. Before installing it in lead.
  • Page 5 MAN-KEH-P5010R-GB_B.fm Page 5 Friday, October 6, 2000 2:22 PM This product conforms to new cord colors. This product Rear output Antenna jack Power amp Depending on the kind of vehicle, the function (sold separateley) of 3* and 5* may be different. In this case, be Connecting cords with RCA pin plugs sure to connect 2* to 5* and 4* to 3*.
  • Page 6 This lets you quickly lower volume level (by about 90%). • The Pioneer CarStereo-Pass is for use only in Germany. Press once more to return to the original • Keep this manual handy as a reference for operating procedures and precautions.
  • Page 7 • Stereo indicator “%” lights when a stereo station is selected. • External Unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this product. Only one External Unit can be controlled by this product.
  • Page 8 MAN-KEH-P5010R-GB_B.fm Page 8 Friday, October 6, 2000 2:22 PM This product can control a Multi-CD player (sold separately). FF (Fast Forward) ] F-MS (Forward-Music Search) ] Normal Playback Track Search 0.5 seconds or less REW (Rewind) ] R-MS (Rewind-Music Search) ] Normal Playback Fast Forward/Reverse Continue pressing •...
  • Page 9 MAN-KEH-P5010R-GB_B.fm Page 9 Friday, October 6, 2000 2:22 PM This function selects only stations with especially strong signals. RDS (Radio Data System) is a system for transmitting data along with FM programs. This data, which is inaudible, provides a variety of features such as: program service name, program type display, traffic announcement standby, automatic tuning and program type tuning, intended to aid radio listeners in tuning to a desired station.
  • Page 10 MAN-KEH-P5010R-GB_B.fm Page 10 Friday, October 6, 2000 2:22 PM The AF (Alternative Frequencies search) function is used to search for other The tuner searches for another frequency broadcasting the same programming. “PI frequencies in the same network as the currently tuned station. It automatically retunes SEEK”...
  • Page 11 MAN-KEH-P5010R-GB_B.fm Page 11 Friday, October 6, 2000 2:22 PM The TA (Traffic Announcement standby) function lets you receive traffic announcements automatically, no matter what source you are listening to. The TA function can be activated for either a TP station (a station that broadcasts traffic information) or an enhanced other network’s TP station (a station carrying information which cross-references TP stations).
  • Page 12 MAN-KEH-P5010R-GB_B.fm Page 12 Friday, October 6, 2000 2:22 PM The PTY function enables you to select stations by the type of programming they broadcast (PTY Search). It also provides automatic tuning to emergency broadcasts (PTY Alarm). • PTY code program types are as follows: 1.
  • Page 13 MAN-KEH-P5010R-GB_B.fm Page 13 Friday, October 6, 2000 2:22 PM The repeat mode lets you hear the same song over again. “ ” The tuner searches for a station broadcasting the desired PTY. This function fast-forwards to the next song automatically if there is a long period of •...
  • Page 14 MAN-KEH-P5010R-GB_B.fm Page 14 Friday, October 6, 2000 2:22 PM There are three repeat play ranges: One-track Repeat, Disc Repeat and Multi-CD In the Disc Repeat, the beginning of each track on the selected disc is scanned for player Repeat. Default repeat play range is Multi-CD player Repeat. about 10 seconds.
  • Page 15 MAN-KEH-P5010R-GB_B.fm Page 15 Friday, October 6, 2000 2:22 PM You can switch between Equalizer curves. The Audio Menu features the following functions. This function allows you to select a Fader/Balance setting that provides ideal listening conditions in all occupied seats. “Equalizer curve”...
  • Page 16 MAN-KEH-P5010R-GB_B.fm Page 16 Friday, October 6, 2000 2:22 PM The Loudness function compensates for deficiencies in the low and high sound ranges The SLA (Source Level Adjustment) function prevents radical leaps in volume level at low volume. You can select a desired Loudness level. when switching between sources.
  • Page 17 MAN-KEH-P5010R-GB_B.fm Page 17 Friday, October 6, 2000 2:22 PM The front panel of the main body is detachable to discourage theft. With this menu, you can perform initial settings for this product. Hold for 2 seconds Take care not to grip it tightly or drop it.
  • Page 18 MAN-KEH-P5010R-GB_B.fm Page 18 Friday, October 6, 2000 2:22 PM The Initial Setting Menu features the following functions. An IP-BUS-RCA Interconnector such as CD-RB20 or CD-RB10 (sold separately) enables you to connect this product to auxiliary equipment featuring an RCA output. For more details, refer to the IP-BUS-RCA Interconnector’s Owner’s Manual.
  • Page 19 (KEH-P5010R)........50 W x 4 Frequency range ........ 87.5 – 108 MHz * A tape with an extremely quiet passage in the music lasting for 4 seconds or (KEH-P4013R, KEH-P4010R, KEH-P4010RB) Usable sensitivity ..........9 dBf (0.8 µV/75 $, mono, S/N: 30 dB) longer.
  • Page 20 MAN-KEH-P5010R-GB_B.fm Page 20 Friday, October 6, 2000 2:22 PM MAN-KEH-P5010R-GB/B ‹ reserved. rights Corporation. Pioneer 2000 Copyright Belgium Printed Corporation. Pioneer Published 5-688-52-90 TEL: 03100 C.P. D.F. Mexico Valle, Col. Desp. piso 1009 Lorenzo C.V. S.A. MEXICO, ELECTRONICS PIONEER 479-4411...
