E
5800/120Lg
XPRESS
()
S e r v i c e G u i d e

Advertisement

Table of Contents
loading

Related Manuals for NEC Express 5800/120Lg

Summary of Contents for NEC Express 5800/120Lg

  • Page 1 5800/120Lg XPRESS S e r v i c e G u i d e...
  • Page 3 NEC Solutions (America), Inc. To allow for design and specification improvements, the information in this document is subject to change at any time, without notice.

  • Page 5: Table Of Contents

    Contents Proprietary Notice Using This Guide Text Conventions ........................x Related Documents ......................xi Safety Notices ........................xii Safety Notices for Users Outside of the U.S.A. and Canada ........xiii Care and Handling......................xiv 1. System Overview Overview ..........................1-2 System Features .........................
  • Page 6 Powering On Your System....................2-7 Powering Off the Server System ...................2-8 Forcing a Power Shutdown ...................2-8 3. Configuring Your System Configuring Your System....................3-2 BIOS Setup Utility......................3-3 Using the BIOS Setup Utility..................3-3 BIOS Setup Configuration Settings................3-4 Main Menu ........................3-5 Primary and Secondary Master and Slave IDE Submenus........3-6 Processor Settings Submenu..................3-6 Advanced Menu ......................3-7 PCI Configuration Menu ..................3-8...
  • Page 7 Modifying the System Board ................... 4-10 Replacing the Real-time Clock Battery............... 4-10 Removing and Installing a Processor................4-13 CPU Installation ....................4-14 CPU Removal...................... 4-19 DIMMs........................4-20 Installing DIMMs....................4-21 Removing DIMMs ....................4-23 Hard Disk Drives......................4-25 Installation........................4-25 Removal ........................
  • Page 8 Preparing the System for Diagnosing Problems ............5-8 Monitoring POST ....................5-9 Verifying Proper Operation of Key System Indicators ........5-10 Confirming Loading of the Operating System ............5-10 Specific Problems and Corrective Actions ...............5-11 Power LED Does Not Light ..................5-11 Incorrect or No Beep Code..................5-11 No Characters Appear on Screen ................5-12 Characters are Distorted or Incorrect ................5-12 System Cooling Fans Do Not Rotate................5-12...
  • Page 9 Cable List ........................6-7 A. Specifications System Specifications ....................... A-2 ® B. Installing and Configuring Windows 2000 Overview ........................... B-2 Device Drivers ........................B-2 Installation Assumption ....................B-3 Installation Preparation ..................... B-4 ® Installing Microsoft Windows 2000 Operating System ..........B-5 Installation Notes ......................

  • Page 11: Using This Guide

    Using This Guide Welcome to the E 5800/120Lg Service Guide. This service guide has all the XPRESS information found in the System User’s Guide, including disassembly and reassembly instructions for all field replaceable units (FRUs). This service guide also contains technical specifications, and a complete parts list, including an exploded view of the system.

  • Page 12: Text Conventions

    Text Conventions This guide uses the following text conventions. Warnings, cautions, and notes have the following meanings: WARNING Warnings alert you to situations that could result in serious personal injury or loss of life. ! CAUTION Cautions indicate situations that can damage the system hardware or software. Note: Notes give important information about the material being described.

  • Page 13: Related Documents

    Related Documents In addition to this guide, the following system documentation is included with your server either as electronic files on E or as paper copy shipped with your server. XPRESS UILDER System Release Notes Release Notes provide you with the latest information about your system. This information was not available to be included in your user's guide at the time it was developed and released.

  • Page 14: Safety Notices

    Safety Notices Caution: To reduce the risk of electric shock which could cause personal injury, follow all safety notices. The symbols shown are used in your documentation and on your equipment to indicate safety hazards. Warning: Lithium batteries can be dangerous. Improper handling of lithium batteries may result in an explosion.

  • Page 15: Safety Notices For Users Outside Of The U.s.a. And Canada

    Safety Notices for Users Outside of the U.S.A. and Canada PELV (Protected Extra-Low Voltage) Integrity: To ensure the extra-low voltage integrity of the equipment, connect only equipment with mains-protected electrically- compatible circuits to the external ports. Remote Earths: To prevent electrical shock, connect all local (individual office) computers and computer support equipment to the same electrical circuit of the building wiring.

  • Page 16: Care And Handling

    Care and Handling Use the following guidelines to properly handle and care for your system. Protect the system from extremely low or high temperatures. Let the system warm (or cool) to room temperature before using it. Keep the system away from magnetic forces. Keep the system dry.

  • Page 17: System Overview

    System Overview Overview System Features System Chassis Features Standard Features Power Supplies Peripheral Bays System Functions Security...
  • Page 18 Overview Your server is a modular, multiprocessing server based on the Intel® Xeon microprocessor family. It is a solid performer and offers the latest technology. The combination of compute performance, memory capacity, and integrated I/O provides a high performance environment for many server market applications. These range from large corporations supporting remote offices to small companies looking to obtain basic connectivity capability such a file and print services, e-mail, web access, web site server, etc.
  • Page 19 System Features Your system features the following major components: Single or dual high-performance Intel™ Xeon™ 1.80GHz or 2.66GHz processors. 256 MB to 4 GB of ECC SDRAM two way interleaved memory, using up to four DIMMs. Six PCI expansion slots for add-in boards (four 64-bit/100MHz PCI slots and two 32-bit/33MHz PCI slots).

  • Page 20: Front View

    System Chassis Features Figure 1-2 shows the system front view features seen with the front door closed. Front View Front door Open this door to access the POWER switch, 5.25-inch devices, the CD-ROM drive, or the floppy disk drive, or to install/remove hard disks to 3.5-inch bays. You can lock the front door using the provided security key.

  • Page 21: Front View (Door Opened)

    Front View (Door Opened) Figure 1-3 shows the system front view features seen with the front door opened. CD-ROM Drive Floppy Disk Drive Figure 1-3. Front View (Door opened) System Overview 1-5...
  • Page 22 5.25-inch device bay Backup tape drives may be installed in the 5.25-inch device bay. CD-ROM drive The CD-ROM drive reads data from the inserted CD-ROM. Headphone jack Volume control Access lamp (lights in amber while being accessed) CD-ROM slot Emergency hole Open/Close button Disk lamp (green/amber) The disk lamp is lit green if a hard disk installed in the server is accessed.

  • Page 23: Rear View

    Rear View Figure 1-4 shows the system rear view features. 16-1 17-1 16-2 17-2 System Overview 1-7...
  • Page 24 Power supply The power unit supplies DC powers to the server. AC inlet The AC inlet is connected with the power cord. DC power lamp The AC power lamp blinks green if the power supply receives the AC power through the power cord.

  • Page 25: Internal View

    Internal View Figure 1-5 shows an internal view of your system with the air duct covers removed. Power supply DIMMs (factory-installed in slots #1A and #1B.) (factory-installed) CPU1 CPU2 5.25-inch device bays (4 slots) A standard CD-ROM drive is installed in slot #3. The device bay can include a maximum of two optional file devices.

  • Page 26: System Board Features

    System Board Features Figure 1-6 shows details of the system board. 1-10 System Overview...
  • Page 27 Power signal connector Power connector DIMM sockets (slots #1A, #1B, #2A, and #2B from top to bottom) CPU1 socket CPU2 socket Floppy disk drive connector Cooling fan connector (Fan 5) Cooling fan connector (not used) Power connector HSBP (B) connector (not used) HSBP (A) connector (not used) USB connector IDE connector (for CD-ROM drive)

  • Page 28: Standard Features

    Standard Features High performance Expandability ! Wide variety of optional I/O slots ! Intel Xeon Processor Four 64-bit, 100 MHz PCI slots N8100-865F: 1.8GHz Two 32-bit, 33 MHz PCI slots N8100-866F: 2.66GHz ! Large memory of up to 4 GB ! High-speed 1000BASE-T/100BASE-TX/ ! Six SCSI hard disk drive bays (hot- 10BASE-T interface...

  • Page 29: Xeon™ Processors

    Xeon™ Processors Depending on system configuration, each system includes one or two Intel Xeon 1.80GHz or 2.66GHz processors. Each processor plugs into a INT3/FCPGA socket package. The processor includes a 512K cache. When two processors are installed, both processors must be of identical bus and core speed. The processor external interface operates at a maximum of 400MHz.

  • Page 30: Keyboard And Mouse

    The Network controller supports the following features: 64-bit, 100 MHz PCI-X interface Integrated IEEE 802.3 10Base-T, 100Base-TX, and 1000Base-T compatible IEEE 820.3u auto-negotiation support Chained memory structure similar to the 82557, 82558, 82559 and 82596 Full duplex support at 10 Mbps, 100 Mbps, and 1000 Mbps operation Low power +3.3 V devices.

  • Page 31: System Board Management Controller (Bmc)

    s1: Processor sleep state. No context will be lost in this state and the processor caches will maintain coherency. s4: Hibernate or Save to Disk. The memory and machine state are saved to disk. Pressing the power button or other wakeup event restores the system state from the disk and resumes normal operation.

  • Page 32: Power Supplies

    Controls secure mode, including video blanking, diskette write-protect monitoring, and front panel lock/unlock initiation Controls Wake On LAN via Magic Packet support. Power Supplies The system contains one auto-sensing 450-watt power supply at an operating frequency of 50/60 Hz. A second optional power supply may be added as part of a fault-tolerant hot-swap design.

  • Page 33: System Functions

    System Functions The following subsections describe select system functions. Degradation Feature The degradation feature automatically isolates a failed DIMM or processor to assure continuous operation of the server when the POST (Power On Self-Test, self-diagnosis program after power on) detects such a DIMM or processor. Failed DIMMs and processors may be identified on the screen that the POST displays, or with the BIOS setup utility, "SETUP."...

  • Page 34: Security

    Security To help prevent unauthorized entry or use of the system, the system includes a full lockable front panel and Server Management software that monitors the system intrusion switches. Security with Mechanical Locks and Monitoring The front door of the server contains a mechanical lock to prevent access to the front of the computer chassis.

  • Page 35: Setting Up The System

    Setting Up the System Overview Selecting a Site Unpacking the System Making Connections Connecting the Power Cord Using the System...
  • Page 36 Overview This chapter describes how to select a site, unpack the system, make cable connections, and power on the system units. Information on front and rear panel features, switches and LEDs are also included in this chapter. Selecting a Site The system operates reliably in a typical office environment.
  • Page 37 Unpacking the System WARNING The non-hot-swap system can weigh up to 40 pounds (18 kg) and the hot-swap system can weigh up to 77 pounds (35 kg). If the system contains numerous optional boards and peripheral devices, it will weigh more. To avoid personal injury, make sure you have someone help you lift or move the system.
  • Page 38 Before connecting a third-party peripheral device or interface cable to the server, consult with your sales agent. Some third-party devices may not be used with the server. The total length of a cable (including the connection cable within a SCSI device) is limited by the SCSI standard.
  • Page 39 Connecting the Power Cord Plug the female end of each AC power cord shipped with your system into the input receptacle on the rear of each power supply shipped with your system. Plug the male end of the power cord into NEMA 5-15R outlet for 100-120 VAC or NEMA 6-15R outlet for 200-240 VAC.

  • Page 40: Opening The Front Door Of The Tower Cabinet

    Verify that the access lamp on the diskette drive is unlit before turning off the server or ejecting the floppy disk. Turning off the server or ejecting the floppy disk while the access lamp is lit may damage data being stored on the floppy disk.

  • Page 41: Powering On Your System

    Powering On Your System Power on your system as follows. 1. Make sure all external devices, such as a video display, keyboard, and mouse (optional) have been connected, and the power cords are connected. 2. Power on the video display and any other external devices. Note: If the server power cord(s) is connected to a power control unit such as an UPS (Uninterruptible Power...

  • Page 42: Powering Off The Server System

    Powering Off the Server System When server system power is on, pressing the power on/off switch on the front panel of the server turns the power off. To turn the server system power off: 1. Shutdown the operating system (OS). 2.

  • Page 43: Configuring Your System

    Configuring Your System Configuring Your System BIOS Setup Utility SCSISelect Utility Configuring the RAID Controller Configuring System Board Jumpers...

  • Page 44: Configuring Your System

    Configuring Your System Configuration and setup utilities are used to change your system configuration. You can configure your system, as well as option boards you may add to your system, using the BIOS Setup Utility. Several unique system parameters are configured using the BIOS Setup, which is stored in the system FLASH memory.

  • Page 45: Bios Setup Utility

    BIOS Setup Utility The BIOS Setup Utility is used to change system configuration parameters. The utility is resident in the system FLASH memory and does not require a diskette or an operating system present to run. Using the BIOS Setup Utility You access the BIOS Setup utility when you turn on or reboot your system.

  • Page 46: Bios Setup Configuration Settings

    Function in Setup Menu F1 or Alt-H Get Help about an item. Exit the current menu and return to the previous menu. Left or right arrow keys Move between menus. Up or down arrow keys Move cursor up and down. The cursor moves only to the settings that you can change.

  • Page 47: Main Menu

    Main Menu Choices or Feature Display Only Description Your Setting System Time HH:MM:SS Set the System Time. System Date MM/DD/YYYY Set the System Date. Floppy A Disabled Hidden if not detected. 1.44/1.25 Mb 3½” 720Kb 3.5” 2.88MB 3.5” Floppy B Disabled Hidden if not detected.

  • Page 48: Primary And Secondary Master And Slave Ide Submenus

    Primary and Secondary Master and Slave IDE Submenus Choices or Feature Display Only Description Your Setting Auto Type Select Auto if a device is None attached to the IDE channel. Multi-Sector Transfer Disabled Specifies the number of 2 Sectors sectors that are transferred 4 Sectors per block during multiple 8 Sectors...

  • Page 49: Advanced Menu

    Advanced Menu Choices or Description Your Setting Feature Display Only PCI Configuration Select sub-menu. Peripheral Configuration Select sub-menu. Memory Configuration Select sub-menu. Advanced Chipset Select sub-menu. Control Specifies whether POST Disabled Boot-time Diagnostic messages are displayed. Screen Enabled If this item is set to "Disabled," the logo appears during POST.

  • Page 50: Pci Configuration Menu

    PCI Configuration Menu Choices or Feature Display Only Description Your Setting Onboard NIC 1 Select sub-menu. (10/100MB) Onboard NIC 2 Select sub-menu. (1.0GB) Onboard SCSI Select sub-menu. Onboard Video Select sub-menu. PCI Slot 1 ROM Disabled Used to enable or disable an Enabled option ROM that may be present on a PCI add-in card...

  • Page 51: Onboard Nic 1 / Onboard Nic 2 Submenu

    Onboard NIC 1 / Onboard NIC 2 Submenu Description Your Setting Choices or Feature Display Only Onboard NIC 1 Enabled Enables or disables onboard LAN controller. Disabled Onboard NIC 2 Enabled Enables or disables onboard LAN controller. Disabled Enabled Onboard NIC 1 Enables or disables onboard LAN controller expansion ROM.

  • Page 52: Memory Configuration Submenu

    Bi-Directional EPP Version Selects the version for Enhanced Parallel Port (EPP) mode. ECP Mode DMA Selects the DMA channel for Channel Extended Capabilities Port (ECP) mode. Disables or enables support for USB Legacy USB Disabled Support keyboards and mice. Set to Enable for Keyboard Only Auto use with a non-USB aware operation...

  • Page 53: Security Menu

    Wake on PME Disabled Enables or disables the remote power- on features by PCI device (PCI Power Enabled Management Enable wake up event) installed to the PCI riser C. Wake on RTC Disabled Enables or disables the remote power- Alarm on features using RTC Alarm features.

  • Page 54: Server Menu

    Server Menu Choices or Display Description Your Feature Only Setting System Select Submenu Management Console Select Submenu Redirection Event Log Select Submenu Configuration Disabled Assert NMI on Sets support of PCI PERR. PERR Enabled Assert NMI on Disabled Sets support of PCI SERR. SERR Enabled Disable BSP...

  • Page 55: System Management Submenu

    Server Menu (Continued) Choices or Display Description Your Setting Feature Only Boot Retry 3 Times This item indicates the processing at Monitoring the occurrence of timeout during boot Retry Service Boot Policy monitoring. Always Retest If [Retry 3 times] is selected, the system is reset after the occurrence of timeout and OS boot is retried up to three times.

  • Page 56: Console Redirection Submenu

    Secondary HSBP – Indicates secondary HSBP (Hot-Swap Revision Backplane) revision number. (View only) Console Redirection Submenu Choices or Display Description Your Setting Feature Only Disabled BIOS Specify the serial port to which a Redirection hardware console is connected. Serial Port A (DB-9) Port Serial Port B (RJ45) Disabled...

  • Page 57: Boot Menu

    Boot Menu Choices or Display Description Your Setting Feature Only Boot Device Select sub-menu. Priority Hard Disk Select sub-menu. Drives Removable Select sub-menu. Devices ATAPI Select sub-menu. CDROM Drives Boot Device Priority Submenu Choices or Display Description Your Setting Feature Only 1st Boot ATAPI CD-ROM...

  • Page 58: Removable Devices Submenu

    Removable Devices Submenu Item Description Lists Bootable Removable Select one of the detected devices. devices in the system. This list includes legacy 1.44-MB floppy drives and 120- MB floppy drives. Lists ATAPI CDROM Drives Selects the Boot sequence from available devices. Exit Menu You can make the following selections on the Exit Menu.

  • Page 59: Scsiselect Utility

    SCSISelect Utility The SCSISelect Utility detects and configures the SCSI controller located on the system board or an optional SCSI controller board installed in your system. This utility may be started with a simple key operation while POST is in progress and requires no specific start-up disk.

  • Page 60: Adaptec Scsi Utility Configuration Settings

    Adaptec SCSI Utility Configuration Settings The following keys are active for all Adaptec SCSI Utility screens: Action Arrows Up and down arrows move from one parameter to another within a screen. ENTER Displays options for a configurable parameter. Selects an option. Moves back to previous screen or parameter or EXIT if at the Main menu.

  • Page 61: Scsi Disk Utilities

    Table 3-1. SCSISelect Utility Setup Configurations (continued) RECOMMENDED SETTING YOUR OR DISPLAY ONLY CONFIGURATION OPTION Display <Ctrl-A> Messages During BIOS Enabled Initialization Extended Int13 Translation for DOS Enabled Drives >1 GByte POST Display Mode Verbose SCSI Controller Int13 Support Enabled Domain Validation Enabled 1, 2...

  • Page 62: Exiting Adaptec Scsi Utility

    With this screen you can determine the SCSI IDs for installed options. You can also view the device information by selecting a device and pressing Enter. The following sub menu appears. SCSI ID#4 : xxxxxxxxx Firmware : xxxx xxx Capacity : xxGB Format Verify Disk Media The following table lists submenu items and descriptions.

  • Page 63: Configuring The Raid Controller

    Configuring the RAID Controller RAID (Redundant Array of Independent Devices) options are available for your system, providing added security and high availability. If you order a system with a RAID controller, the system is pre-configured at the factory according to Table 3-2 below. Table 3-2.

  • Page 64: Configuring System Board Jumpers

    Configuring System Board Jumpers Before You Begin Only a qualified technical person should perform the procedures in this section. ! CAUTION Electrostatic discharge (ESD) can damage the system board. Modify the system board only at an ESD workstation. Otherwise, wear an antistatic wrist strap attached to chassis ground.

  • Page 65: Moving System Board Jumpers

    Table 3-3. Password/CMOS System Board Jumper Summary Jumper On/Off Jumper Function (default in bold) What it does at system reset. Off, Protect CMOS clear Preserves the contents of CMOS. On, Erase Clears CMOS. Password disable Off, Enable Enables password protection. On, Disable Disables the password.

  • Page 66: Clearing And Changing The Passwords

    Clearing and Changing the Passwords To clear and change the passwords: 1. Shut down the OS. 2. Press the POWER switch to turn off the power of the server. (The POWER/SLEEP lamp goes off.) 3. Remove the side cover. Refer to Chapter 4 for information on removing the side cover.

  • Page 67: Disassembly And Reassembly

    Disassembly and Reassembly General Information Static Precautions Equipment Log Tools Recommended for Upgrading Your System Preparing Your System for Disassembly and Reassembly Side Access Panel Processor Air Duct Modifying the System Board Hard Disk Drives Hot-Swap Power Supply Non-Hot-Swap Power Supply Front Cooling Fan Unit Removable 5.25-inch Media Devices PCI Boards...
  • Page 68 Hot-Swap SCSI Backplane Replacing the Rear Cooling Fan System Board Power Supply Back Board Tower Feet I/O Shield LED/Switch Assembly Intrusion Switch Assembly 4-2 Disassembly and Reassembly...

  • Page 69: General Information

    General Information WARNING The DC push-button on/off switch on the front panel does not turn off the system AC power. Also, +5vdc is present on the system board whenever the AC power cord is connected between the system and an AC outlet. Before doing the procedures in this manual, make sure that your system is powered off and unplug the AC power cord from the back of the chassis.

  • Page 70: Tools Recommended For Upgrading Your System

    Tools Recommended for Upgrading Your System Depending on the upgrade, you will need one or more of the following tools: ! Phillips screwdriver (#1 bit and #2 bit) ! Flat-head screwdriver ! Small needle nose pliers ! Pen or pencil ! ESD workstation or antistatic wrist strap (recommended) Preparing Your System for Disassembly and Reassembly...

  • Page 71: Side Access Panel

    Side Access Panel To install options in your system, you must remove the access panel on the left- hand side of the system (as viewed from the front). The side access panel on the right-hand side of the system (as viewed from the front) does not have to be removed.
  • Page 72 Figure 4-1. Removing the Left-Hand Side Access Panel To install the left side access panel (see Figure 4-2): 1. Check to make sure that no tools or loose parts have been left inside the system chassis. 2. Make sure all option boards are firmly seated in their respective slots and that all interior cables are properly connected.
  • Page 73 Figure 4-2. Installing the Left-Hand Side Access Panel Disassembly and Reassembly 4-7...

  • Page 74: Processor Air Duct

    Processor Air Duct To install or remove the DIMM or a processor, you will need to remove the air duct. IMPORTANT: Do not assemble the server without installing the air duct. If the duct is not installed in the system, reduced cooling efficiency and can affect performance or cause damage due to overheating.

  • Page 75: Installation

    Installation Follow these steps to install the air duct. 1. Holding the internal cables clear, place the air duct into the chassis. See Figure 4-4. 2. Adjust the air duct until the tab on the right end of the duct is aligned with the slot on the chassis.

  • Page 76: Modifying The System Board

    Modifying the System Board The following sections provide procedures for upgrading and configuring the system board in your system. Topics covered include: ! Replacing the real-time clock battery ! Removing and installing a processor ! Installing or removing DIMMs. ! CAUTION Electrostatic discharge (ESD) can damage add-in boards and other components;...
  • Page 77 To replace the RTC battery, perform the following procedures: 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Open the front bezel of your system's cabinet. For rack-mount systems you must remove the front panels of the system chassis.
  • Page 78 19. Run the BIOS Setup to restore the configuration settings to the real-time clock. Figure 4-5. Replacing the Real-Time Clock Battery 4-12 Disassembly and Reassembly...

  • Page 79: Removing And Installing A Processor

    Removing and Installing a Processor This subsection provides the procedures for removing and installing a Xeon processor in your system. The system board has sockets for two processors. Each Xeon processor plugs into a standard Xeon ZIF socket. The processor comes with up to 512K cache. The primary processor connector is shown in the illustration below (see Figure 4-6, C).

  • Page 80: Cpu Installation

    CPU Installation 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Open the front bezel of your system's cabinet. 3. Shutdown the operating system (OS). 4. Press the power on/off switch on the front panel of the server (see Front View in Chapter 1).
  • Page 81 Retention Figure 4-7. Raising the Locking Lever 11. Aligning the pins of the CPU with the socket, insert the CPU slowly and gently into the socket. See Figure 4-8. IMPORTANT Be aware of CPU direction. Pin layouts on two corners among four differ from others to prevent an incorrect insertion.
  • Page 82 Figure 4-9. Closing the Locking Lever 13. Very carefully apply the thermal interface material (heat radiation sheet) on top of the processor so that it is completely covered. See Figure 4-10. Notes: The thermal material may already be applied to the heat sink.
  • Page 83 Figure 4-11. Installing the Heatsink 15. Install both heat sink clips as follows: ! CAUTION Do not allow the heat sink to rock back and forth while securing the heat sink clips. If the CPU becomes dislodged from the socket, catastrophic failure may occur. Place the heat sink clip on the center tab of the retention module and rotate the clip towards the heat sink to engage the center tab (1).
  • Page 84 16. Ensure the heat sink is level. NOTES: If the heat sink is not level, remove it, and then install it again. The following probably causes the heat sink not to be level: – The CPU is not positioned correctly. –...

  • Page 85: Cpu Removal

    CPU Removal 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Prepare your system for upgrade. See Preparing Your System for Disassembly and Reassembly described earlier in this chapter. 3.

  • Page 86: Dimms

    8. Reinstall the air duct. 9. Reinstall the left-hand side access panel on the system chassis. 10. Plug in the system power cord(s) and power up the system. DIMMs The system board contains four DIMM sockets (Figure 4-15). Each socket can hold a single 72-bit DIMM module with 256MB, 512MB, or 1GB of memory.

  • Page 87: Installing Dimms

    Installing DIMMs 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Open the front bezel of your system's cabinet. For tower-based systems see Opening the Front Bezel of the Tower Cabinet in Chapter 2. For rack-mount systems you must remove the front panels of the system chassis.
  • Page 88 Figure 4-16. Removing the DIMM Connector Cover 11. Holding a DIMM module only by the edges, remove it from its antistatic package. ! CAUTION Observe static precautions. Use an antistatic wrist strap. Hold the DIMM only by its edges. 12. Position the DIMM so that the two notches in the bottom edge of the DIMM align with the keyed socket.

  • Page 89: Removing Dimms

    Removing DIMMs ! CAUTION Use extreme care when removing a DIMM. Too much pressure can damage the socket slot. Apply only enough pressure on the plastic ejector levers to release the DIMM 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter.
  • Page 90 Figure 4-18. Removing a DIMM 12. Repeat the above steps to remove the remaining DIMMs. 13. Reinstall the processor air duct. 14. Reinstall the left-hand side access panel on the system chassis. 15. Plug in the system power cord(s) and power up the system. 4-24 Disassembly and Reassembly...

  • Page 91: Hard Disk Drives

    Hard Disk Drives Your system supports a variety of SCSI hard disk drives installed in the system’s hard disk drive bay. Contact your sales representative or dealer for a list of approved devices. The 3.5-inch hard disk drive bay on the front of the server contains six slots on which hard disks can be installed.
  • Page 92 Figure 4-19. Removing the Dummy Tray 5. Unlock the lever of the hard disk drive carrier and open the handle. See Figure 4-20. Figure 4-20. Unlocking the Drive Carrier 6. Align the drive carrier with the bay guide rail. 7. Slide the drive carrier into the bay until if docks with the SCSI backplane connector.
  • Page 93 Handle Figure 4-21. Installing the Hard Disk Drive 8. Close the lever ensuring the drive is secured. The handle is locked when a distinct click is heard.. See Figure 4-22. Hook Frame Handle Figure 4-22. Locking the Hard Disk Drive Carrier 9.

  • Page 94: Removal

    Removal NOTE: The disk LED of a defective hard disk drive is amber. 1. Prepare your system for upgrade. See Preparing Your System for Disassembly and Reassembly described earlier in this chapter. 2. Release the lock of the front bezel by using the security key to open the front bezel.

  • Page 95: Auto Rebuild Functionality

    Figure 4-25. Removing a Hard Disk Drive 6. If not replacing the hard disk removed, insert a dummy carrier tray into the empty slot. IMPORTANT To maintain the cooling effect in the server, install the dummy tray in the vacant slot of the disk bay. 7.

  • Page 96: Hot-Swap Power Supply

    Hot-Swap Power Supply Your server may contain a modular hot-swap power supply like the one shown in Figure 4-26. The addition of a second hot-swap power supply makes your system so that it has redundant power and can be operated continuously without interruption if either of the power supplies malfunction.
  • Page 97 4. Slide the power supply into the vacant slot until you feel resistance. See Figure 4-28. IMPORTANT Make sure that the handle is in full-open position. To avoid damaging the power supply unit, do not tilt or twist the unit as you push it into the connector.
  • Page 98 6. Push the power supply handle toward the power supply until the locking tab snaps into place. See Figure 4-30. Figure 4-30. Securing the Power Supply 7. Connect two power cords to the AC inlets. The AC Power lamps go on and DC Power lamps blink when the power cords are connected.

  • Page 99: Removal

    Removal 1. Check the Power Status lamps of the power supplies on the rear face and determine which module needs to be replaced. (If a power supply is defective, the Power Status lamp is lit amber.) NOTE: When the server is equipped with two power supplies and one of the power supplies operates normally (with the power lamp of the power supply being on), the other defective power supply can be replaced while the system is in operation (or in the power-on status).

  • Page 100: Non-Hot-Swap Power Supply

    Non-Hot-Swap Power Supply Your server system may contain a single non-hot-swap power supply that is housed in the rear of the chassis as shown in Figure 4-33. Removal 1. Prepare your system for disassembly. See Preparing Your System for Disassembly and Reassembly earlier in this chapter. 2.

  • Page 101: Front Cooling Fan Unit

    Front Cooling Fan Unit The optional front cooling fan unit contains up to two fans for cooling the CPU, memory, and PCI devices built in the server. Installation 1. Prepare your system for upgrade. See Preparing Your System for Disassembly and Reassembly described earlier in this chapter. 2.
  • Page 102 4. Insert the tabs into holes on the frame of the server, and push the cooling fan unit toward the frame. See Figure 4-35. Figure 4-35. Securing the Fan Unit 5. Connect the cooling fan cable to the system board. See Figure 4-36. Fan Connectors Figure 4-36.

  • Page 103: Removal

    Removal 1. Prepare your system for upgrade. See Preparing Your System for Upgrade described earlier in this chapter. 2. Remove the left-hand side cover. 3. Remove the fan unit connector from the system board. See Figure 4-37. 4. Push the locking tab to unlock the cooling fan unit, and remove the fan unit from the server.

  • Page 104: Removable 5.25-Inch Media Devices

    Removable 5.25-inch Media Devices A variety of SCSI 5.25-inch removable media devices (i.e., tape backup, etc.) can be installed in the four half-height media bays (Figure 4-38). The media devices should be installed in the first available media bay from the top (slot 1).

  • Page 105: Installation

    Installation 1. Prepare your system for upgrade. See Preparing Your System for Disassembly and Reassembly described earlier in this chapter. 2. Remove the side cover. 3. Remove the two screws fixing the dummy cover. See Figure 4-39. 4. Pull out the dummy cover toward you carefully. NOTE: When installing a full-height device, remove two dummy covers.

  • Page 106: Removal

    6. Push the 5.25-inch device to the device bay carefully. NOTE: Make sure the cables are not caught while the 5.25-inch device is pushed into the slot. 7. Secure the device using the screws removed in step 3. See Figure 4-41. Half-height device Full-height device Figure 4-41.

  • Page 107: Pci Boards

    PCI Boards The server contains six slots into which PCI boards can be inserted. See Figure 4-42. IMPORTANT: PCI boards are easily affected by static electricity. Handle a PCI board after making your body contact with a metallic frame section of the server to discharge the static electricity on your body. Do not make bare hands contact with terminals and components on the PCI board.

  • Page 108: Installation

    Installation IMPORTANT: For ease of installation, remove the external SCSI cable when installing the full-length PCI card. 3.3V or universal PCI boards can be installed in PCI board slots #1 to 5V or universal PCI boards can be installed in PCI board slots #5 and NOTE: To install a PCI board, make sure that the board connecting section is engaged with the connector of the PCI board slot.
  • Page 109 1. Prepare your system for upgrade. See Preparing Your System for Disassembly and Reassembly described earlier in this chapter. 2. Remove the left-hand side cover. 3. Define the slot in which a board is installed and remove the connector cap of the slot.

  • Page 110: Removal

    Guide rail Figure 4-44. Installing a PCI Board 8. Secure the board with a screw removed in Step 4. 9. Reinstall the removed components. 10. Turn on the power of the server 11. Check for any POST error messages. 12. Start the BIOS Setup Utility to set the "Reset Configuration Data" in the "Advanced"...

  • Page 111: Raid Controller Board

    RAID Controller Board The functions of a disk array controller are described in the following table. Functions of a Disk Array Controller Function Description Level Support RAID levels RAID0, RAID1, RAID5, and RAID0+1. Allows a hard disk to be replaced while the system is running depending on Hot plug RAID level and system configuration.
  • Page 112 ! Set "PCI SLOT n ROM (n: slot number)," a parameter of the slot in which a hard disk is installed, to "Enable" in "PCI Configuration" on the Advanced menu of the BIOS utility SETUP. ! Replacement of disk array controller board Restore the disk array configuration information in the disk array controller boards.

  • Page 113: Using Internal Disks In Disk Array Configuration

    Using Internal Disks in Disk Array Configuration For the installation of the RAID controller board, see "PCI Board" and the manual that comes with the RAID controller board. The DISK access lamp on the front panel of the server indicates the access status of the hard disk drive connected to the RAID controller board.

  • Page 114: Diskette Drive And Carrier Assembly

    Diskette Drive and Carrier Assembly Your server system contains a 3.5-inch diskette drive housed in a carrier located inside the front of the server chassis. To remove the diskette drive and carrier assembly, perform the following procedures: 1. Prepare your system for disassembly. See Preparing Your System for Disassembly and Reassembly earlier in this chapter.
  • Page 115 7. Remove the drive from the carrier. Diskette drive Carrier Screws (4) Figure 4-47. Removing the Diskette Drive from the Carrier Assembly 8. Install the replacement diskette drive into the carrier and secure it with the four screws removed in Step 6. See Figure 4-47. 9.

  • Page 116: Front Bezel And Front Bezel Hinge (Tower-Based System)

    Front Bezel and Front Bezel Hinge (Tower- Based System) Your server system contains a front bezel that covers the front of the chassis. The bezel is secured to the front of the chassis by metal pins located at the top and bottom of a front bezel hinge.

  • Page 117: Front Panel

    5. Remove the four screws securing the bezel hinge to the chassis and remove the hinge. See Figure 4-49. Screws (4) Bezel hinge Figure 4-49. Removing the Front Bezel Hinge 6. Install the replacement bezel hinge using the four screws removed in Step 5. 7.
  • Page 118 3. Remove the front panel (A) by releasing its locking lever (B) and then sliding the front panel up to disengage its hooks from the chassis. The locking lever is located at the back of the front panel and is released by pushing the lever towards the right so that it clears the notch in its locking slot.

  • Page 119: Hot-Swap Hdd Bay

    Hot-Swap HDD Bay This procedure describes how to remove the Hot-Swap SCSI Hard Disk Drive (HDD) Bay that is housed in the front of your system. WARNING Before doing these procedures, make sure that your system is powered off and unplug all AC power cords. Failure to disconnect power before opening your system can result in personal injury and equipment damage.

  • Page 120: Hot-Swap Scsi Backplane

    Figure 4-51. Removing the HDD Bay Hot-Swap SCSI Backplane This procedure describes how to remove the hot-swap SCSI backplane that is attached to the back of the hot-swap HDD bay. WARNING Before doing these procedures, make sure that your system is powered off and unplug all AC power cords.
  • Page 121 Hot-swap HDD bay Hot-swap SCSI backplane Screws (8) Figure 4-52. Removing the SCSI Backplane Bracket 4. Carefully pull the SCSI backplane straight out from the HDD bay and place the backplane on an antistatic wrapper. 5. Carefully position the replacement SCSI backplane on to the rear of the HDD bay and secure it with the eight screws removed in Step 3.

  • Page 122: Replacing The Rear Cooling Fan

    Replacing the Rear Cooling Fan 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Open the front bezel of your system's cabinet. 3. Shutdown the operating system (OS). 4.
  • Page 123 10. To release the fan from the fan housing, pull the fan housing tab (Figure 4-54, A) towards you until the tab clears the edge of the fan. Swivel the fan towards the front of the server and remove it from the fan housing. Figure 4-54.

  • Page 124: System Board

    System Board To remove the system board all the processor(s), DIMMs, and PCI option boards (if installed) on the board must be removed and all system board cable connectors tagged and unplugged. ! CAUTION The system board can be extremely sensitive to ESD and always requires careful handling.
  • Page 125 11. Tag and remove any PCI option boards installed on the system board. See PCI Boards earlier in this chapter. Save the PCI option boards for reassembly. Note: The PCI option boards must be reinstalled in the same slots when you reassemble the system. 12.

  • Page 126: Power Supply Back Board

    16. Install the two retention modules to the system board using the screws removed in Step 15. 17. Install the replacement system board into the server securing it with the eight screws removed in Step 13. 18. Connect all the power, signal, and fan cable connectors to their mating connectors on the system board.
  • Page 127 8. Remove any power supply installed in the system following procedures described earlier it this chapter. 9. Figure 4-56, A shows the location of the power supply back board. Tag and remove all power supply back board cables connected to the system board, SCSI backplane, and peripheral devices installed in the system.

  • Page 128: Tower Feet

    Tower Feet Your tower system has four stabilizer feet located on the bottom of the chassis. To remove the stabilizer feet you must have the chassis positioned on its side with its stabilizer feet overhanging the edge of a table or workbench. To remove the tower feet (see Figure 4-57), perform the following procedures: 1.

  • Page 129: I/O Shield

    I/O Shield To remove the I/O, perform the following procedures: 1. Observe the safety and ESD precautions listed under General Information and Static Precautions at the beginning of this chapter. 2. Open the front bezel of your system. 3. Shutdown the operating system (OS). 4.

  • Page 130: Led/Switch Assembly

    10. Snap the replacement I/O shield into place in the rear panel. 11. Install the system board following procedures previously described in this chapter. 12. Install the left-hand side access panel. LED/Switch Assembly Your server system contains a front panel that houses the LED/switch assembly. You must open the front bezel to access the front panel.

  • Page 131: Intrusion Switch Assembly

    5. Tag and disconnect the LED/Switch Assembly cable (Figure 4-59, B) from its mating connector on the system board. See Figure 4-59, C. Carefully remove the LED/Switch assembly from the system. Intrusion Switch Assembly Your server system includes two chassis intrusion switches that are located on the front and rear of the system chassis.

  • Page 133: Problem Solving

    Problem Solving Problem Solving Static Precautions Resetting the Server Forced Shutdown Troubleshooting Checklists Diagnostic Procedures Specific Problems and Corrective Actions Problems with the Network Plug and Play Installation Tips Error Messages How to Identify BIOS and BMC Revision Levels Lamps...

  • Page 134: Static Precautions

    Problem Solving This chapter helps you identify and solve problems that may occur during system installation or while using your system. The first section of this chapter tells you how to reset your system in the event of problems. The next few sections provide troubleshooting checklists and procedural steps that help you isolate specific system problems.

  • Page 135: Resetting The Server

    Resetting the Server There are two ways to reset the server. IMPORTANT Resetting the server clears the DIMM memory and the data in process. To reset the server when it is not frozen, make sure that no processing is in progress. Hard reset Press the RESET switch at the front of the server.

  • Page 136: Forced Shutdown

    Forced Shutdown Use this function when an OS command does not shut down the server, the POWER switch does not turn off the server, or resetting does not work. Press and hold the POWER switch on the server for at least four seconds. The power is forcibly turned off.

  • Page 137: Troubleshooting Checklists

    Troubleshooting Checklists The following subsections provide troubleshooting checklists for problems that occur at initial system startup, when you run new application software, and after the system hardware and software have been running correctly. Initial System Startup Incorrect installation or configuration usually causes problems that occur at initial system startup.

  • Page 138: Running New Application Software

    If the above items are all correct, but the problem reoccurs, refer to Additional Troubleshooting Procedures in this chapter. Running New Application Software Problems that occur when you run new application software are usually related to the software. Faulty equipment is much less likely, especially if other software runs correctly.

  • Page 139: After System Has Been Running Correctly

    After System Has Been Running Correctly Problems that occur after the system hardware and software have been running correctly often indicate equipment failure. However, many situations that are easy to correct can also cause such problems. If you have problems after the system has been running correctly, check the following: If you are running the software from a diskette or CD-ROM, try a new copy of the software.

  • Page 140: Diagnostic Procedures

    Diagnostic Procedures This section provides a more detailed approach to diagnosing and identifying problems and then locating their sources. Error Checking Each time you turn on the system, POST (Power-On-Self-Test) runs automatically and checks the system board, processors, memory board, keyboard, and mouse. If POST finds an error, it displays an error message.

  • Page 141: Monitoring Post

    Monitoring POST Each time you turn on the system, the Power-On Self-Test (POST) runs automatically and checks the system board, processors, memory board, keyboard, and mouse. During the memory test, POST displays the amount of memory that it is able to access and test.

  • Page 142: Verifying Proper Operation Of Key System Indicators

    Verifying Proper Operation of Key System Indicators As POST determines the system configuration, it tests for the presence of each mass storage device installed in the system. As each device is checked, its activity indicator should turn on briefly. Check for the following: Does the diskette drive activity indicator turn on briefly? If not, refer to “Diskette Drive Activity Indicator Does Not Light”...

  • Page 143: Specific Problems And Corrective Actions

    Specific Problems and Corrective Actions This section provides possible solutions for the following specific problems: Power LED does not light No beep or incorrect beep pattern No characters appear on screen Characters on the screen appear distorted or incorrect System cooling fan does not rotate Diskette drive activity LED does not light Hard disk drive activity LED does not light CD-ROM drive activity LED does not light...

  • Page 144: No Characters Appear On Screen

    No Characters Appear on Screen Check the following: Is the keyboard working? Check to see if the Num Lock light is functioning. Is the video display monitor plugged in and turned on? Are the brightness and contrast controls on the video monitor properly adjusted? Are the video monitor switch settings correct? Is the video monitor signal cable properly installed? Is the onboard video controller enabled?

  • Page 145: Diskette Drive Activity Led Does Not Light

    Diskette Drive Activity LED Does Not Light Check the following: Is the diskette drive properly configured? Is the CDROM/Floppy Disk Drive combo properly installed in the flex bay? Use BIOS Setup to make sure that the diskette drive controller is set to Enabled. For information about running BIOS Setup, refer to the Configuring Your System chapter.

  • Page 146: Bootable Cd-Rom Is Not Detected

    Bootable CD-ROM Is Not Detected Check the following: Is the BIOS set to allow the CD-ROM to be the first bootable device? Check your BIOS Setup (F2) configuration. Problems with the Network Diagnostics pass, but the connection fails: Make sure the network cable is securely attached. The controller stopped working when an add-in adapter was installed: Make sure the cable is connected to the port from the onboard network controller.

  • Page 147: Error Messages

    Error Messages This section describes the POST error codes and messages. POST Error Codes and Messages Whenever a recoverable error occurs during POST, BIOS displays a message on the video display screen and causes the speaker to beep as the message appears. BIOS also issues a beep code (one long tone followed by two short tones) during POST if the video configuration fails or if an external ROM module does not have the correct checksum.
  • Page 148 Table 5-1. POST Error Codes and Messages (continued) On-screen error message Action External Cache Failure Install the CPU (processor) correctly. Contact your service representative to replace the CPU. Floppy Controller Error Contact your service representative to replace the floppy disk drive or system board. This server does not support Floppy A: Error floppy disk drive B.
  • Page 149 Table 5-1. POST Error Codes and Messages (continued) On-screen error message Action 8110 Processor 1 Internal error Securely install the processor. (IERR) Contact your service representative to replace the 8111 Processor 2 Internal error processor or system board. (IERR) 8120 Processor 1 Thermal Trip error 8121 Processor 2 Thermal Trip error...
  • Page 150 Table 5-1. POST Error Codes and Messages (continued) On-screen error message Action 8192 L2 Cache size mismatch Install processors under the same specification. 8193 CPUID, Processor Stepping are different 8194 CPUID, Processor Family are different 8195 Front Side Bus Speed Securely install the processor.
  • Page 151 Table 5-1. POST Error Codes and Messages (continued) On-screen error message Action 84FF System Event Log Full Clear the event log by using the BIOS SETUP utility. If the error is not eliminated, contact your service representative to replace the system board. The error message is displayed periodically if ESMPRO is not installed.

  • Page 152: Post Error Code Hardware References

    POST Error Code Hardware References Figure 5-3 shows the location of specific components referenced in the POST Error Codes and Messages table. Fan modules Fan 5 (Option) Fan 1 Fan 3 (Option) Processor/Memory Slot 1A (DIMM 1A) Processor 1 Slot 1B (DIMM 1B) Slot 2A (DIMM 2A) Slot 2B (DIMM 2B) Processor 2...

  • Page 153: Beep Codes

    Beep Codes If an error occurs during the POST, the server beeps, indicating the type of error. Each number indicates the number of short beeps, and a hyphen indicates a pause. For example, the beep interval 1-5-2-2 indicates 1 beep, pause, 2 beeps, pause, 2 beeps, pause, and 3 beeps notifying that no processor is detected on the system board.

  • Page 154: How To Identify Bios And Bmc Revision Levels

    How to Identify BIOS and BMC Revision Levels To identify your system's current BIOS and BMC revision levels, perform the following procedure: 1. Power-on or reboot the system. “Press <F2> to enter SETUP” displays. 2. Press F2. The BIOS Setup Utility starts and the Main Menu is displayed. The menu bar at the top of the Main Menu lists the following selections: Menu Main...

  • Page 155: Lamps

    Lamps The following describes lamps on the server and their indications. See Chapter 2 for each location. LAN ACCESS Lamp ( The LAN ACCESS lamp is lit green when the server is connected to LAN. The lamp blinks while the server is accessed through the LAN (for packet transmission). The value next to the icon indicates the number of the network port on the rear panel.
  • Page 156 STATUS lamp Description Procedure indication On (green) The server is operating normally. – Flashing The server is operating with the Check the AC POWER lamp (green) memory, CPU, or power supply indication on the rear panel of the unit in degraded state. server.

  • Page 157: Power/Sleep Lamp

    POWER/SLEEP Lamp ( The green POWER/SLEEP lamp lights to indicate normal operation while the server is powered. When the server is off-powered, the POWER/SLEEP lamp stays unlit. The POWER/SLEEP lamp indicates that the server is running in the power-saving mode (sleep mode). If the OS supports the power-saving mode such as Windows 2000, pressing the SLEEP switch blinks the POWER/SLEEP lamp in green and places the server in the power-saving mode.

  • Page 158: Hard Disk Drive Lamp

    Hard Disk Drive Lamp The disk lamp on the 3.5-inch hard disk drive bay has different meanings depending on the display status. See Figure 5-4. Lamp Figure 5-4. Hard Disk Drive Lamp Location Lighting green Indicates that the power is supplied to the hard disk. Blinking green Indicates that the hard disk is accessed.

  • Page 159: Power Supply Lamps

    Power Supply Lamps The power supply on the rear of the server has three lamps. See Figure 5-5. DC power lamp Power status lamp AC power lamp Figure 5-5. Power Supply Lamp Locations NOTE: The server equipped with an optional power unit can continue the operation with the normal power unit if the other power unit is defected (redundant function).

  • Page 160: Lan Connector Lamps

    LAN Connector Lamps Each of the two LAN connectors on the rear panel has two lamps as follows. LINK/ACT lamp LAN2 1000/100/10 lamp LINK/ACT lamp LAN1 100/10 lamp LINK/ACT lamp The link/ACT lamp indicates the state of each network port normally equipped with the server.

  • Page 161: Illustrated Parts Breakdown

    Illustrated Parts Breakdown Exploded View Field Replaceable Units...

  • Page 162: Exploded View

    This chapter provides an exploded view and parts lists for the major assemblies of your server. Exploded View 6-2 Illustrated Parts Breakdown...

  • Page 163: Field Replaceable Units

    Field Replaceable Units Reference Number Description Part Number 5.25-inch Peripheral Devices. Refer to subsection “Tape Drives” in this chapter. CDROM Drive Mitsumi FX-4840W 856-850222-001A Sub Bezel (Front Panel) 6896470000 3.5-Inch FDD, Mist White D353M3D 6786020200 Hard Disk Drive Carrier 245-01509-000 Hard Disk Drives: Refer to subsection “Hard Disk Drives”...
  • Page 164 Reference Number Description Part Number Master Key SCSI Backplane 856-122575-001 DLT Bracket Kit 104-Key Keyboard Intrusion Switch Assembly (included in 6896590000) 6901600000 LED/Switch Assembly (included in 6896590000) Redundant Fan Assembly 856-060342-502A 6884800000 Front Bezel (Door) 6896480000 6-4 Illustrated Parts Breakdown...

  • Page 165: Pentium Processors

    Pentium Processors Replaceable Parts Description Part Number Intel™ Xeon™ 2.0GHz/533/512 Processor 6884920000 Intel™ Xeon™ 2.4GHz/533/512 Processor 6884940000 Intel™ Xeon™ 2.66GHz/533/512 Processor 6889470000 Intel™ Xeon™ 2.8GHz/533/512 Processor 6884930000 Hard Disk Drives Replaceable Parts Description Part Number Kit, 18 GB ATLAS320-18SCA FWB411 6893360000 Kit, 36 GB ATLAS320-36SCA FWB411 6893370000...

  • Page 166: Raid Controllers And Cache

    RAID Controllers and Cache Replaceable Parts Description Part Number RAID LSI 518, 2-CH 320-2 1L19 6893990000 RAID LSI 520, 1-CH 320-1 1L19 6894000000 Cache, 128 MB, M374S1723DTS-C7A 6865270000 Battery Backup, FOR LSI RAID Card 320-2 6891630000 RAID LED Cable 320-01688-000 Battery Backup, FOR LSI RAID Card 320-1 6891640000 SCSI Controllers...

  • Page 167: Cable List

    Cable List Description Part Number 120Lg Cable Kit (not a FRU, Only for order) 6896590000 LED/SW Cable (included in 6896590000) 6896490000 HDD Activity Cable (included in 6896590000) 6896510000 Port COM Cable (included in 6896590000) 6896420000 IDE CDROM Cable (included in 6896590000) 6896430000 FDD Cable (included in 6896590000) 6896450000...

  • Page 169: Specifications

    Specifications System Specifications...

  • Page 170: System Specifications

    10 to 35°C requirements Humidity 20 to 80% RH (no condensation) Others NEC EXPRESSBUILDER supported, NEC ESMPRO provided in the standard configuration * A maximum of three file devices can be installed in this system (including standard ATAPI CD-ROM drive). A-2 Specifications...

  • Page 171: Installing And Configuring Windows

    Installing and Configuring ® Windows 2000 Overview Device Drivers Installation Assumption Installation Preparation ® Installing Microsoft Windows 2000 Operating System Installing LAN Adapters Driver Installation for the ATI RAGE XL Display Adapter...

  • Page 172: Device Drivers

    Overview This appendix contains supplemental instructions needed to install and ® configure hardware and software used with the Microsoft Windows 2000 Operating System. This information is intended to supplement the more detailed procedural documents available from Microsoft. This information is not intended to be the central source of installation and configuration information ®...

  • Page 173: Installation Assumption

    Installation Assumption The installation and configuration instructions in this chapter assume the following: You have properly completed the hardware installation. You have run the BIOS Setup Utility to check system configuration. ® You will be installing Windows 2000 Operating System from the CD-ROM media.

  • Page 174: Installation Preparation

    Installation Preparation Before starting the installation procedure, you need to obtain certain information for use during the installation. Table B-2 lists the information you need in advance for the installation. It is recommended that you obtain the information from your server administrator and record it in Table B-2 before starting. After completing the installation, you might want to use the Windows 2000 Control Panel to configure additional devices or Windows 2000 services and facilities.

  • Page 175: Installing Microsoft Windows 2000 Operating System

    ® Installing Microsoft Windows 2000 Operating System Use the following procedure to set up and perform a clean Windows 2000 Operating System installation on your server. Before performing the installation, read the “Installation Notes” in the following section. Installation Notes Before beginning the Windows 2000 installation, consult your server’s “System Release Notes”...
  • Page 176 Administrator’s group. 11. Insert the EXPRESSBUILDER CD into the system CDROM drive. The “Master Control” menu displays. Select Setup and then select Update NEC 5800 System from the displayed menu items.

  • Page 177: Installing Lan Adapters

    Installing LAN Adapters The following section includes special driver installation instructions for the Intel PRO/100+ LAN adapter used in your system. Driver Installation for the Intel PRO/100+ LAN Adapter The PRO/100+ driver is initially installed during the installation of Windows 2000 and upgraded when you run the “Windows 2000 Update Module, see ®...

  • Page 178: Driver Installation For The Ati Rage Xl Display Adapter

    5. Select the “Link Configuration” tab and set the “Auto Negotiation” value to DISABLE. Also set the “Forced Speed and Duplex” value according to the value specified for your HUB. Note: When selecting the "1000/Full" setting, set “Auto Negotiation” to ENABLE and select only the "1000/Full"...

  • Page 179: Irq And I/O Port Addresses

    IRQ and I/O Port Addresses Interrupt Requests PIRQ and PCI Device...

  • Page 180: Interrupt Requests

    Interrupt Requests The factory-set interrupt requests (IRQs) are listed below. Peripheral Device (Controller) Peripheral Device (Controller) System timer Mouse Keyboard Numeric processor – Primary IDE COM2 serial port (PCI) Secondary IDE COM1 serial port (PCI) Floppy disk drive – Real-time clock LAN1 ACPI compliant system LAN2...

  • Page 181: I/O Port Address

    I/O Port Address The factory-set I/O port addresses for the server are assigned as follows: Address Chip in Use 00 - 1F 8-bit DMA control register 20 - 21 Master 8259 programming interface 2E - 2F Configuration 40 - 43 8254 programming interface Keyboard &...
  • Page 182 Address Chip in Use PCI IRQ mapping index register PCI IRQ mapping data register PCI error status register Address & status control Rise time counter control General register (GPMs) ISA wait register Other control registers CA2 - CA3 IPMI (MPI KCS interface) CA4 - CA5 IPMI (SMI interface) CA6 - CA7...

  • Page 183: Internal Cabling Diagrams

    Internal Cabling Diagrams Standard Configuration Disk Array Configuration of Built-in Hard Disks Installing a SCSI File Device...

  • Page 184: Standard Configuration

    Standard Configuration The figure below shows an example of the connections in the standard configuration. Option 5.25-inch device bay System board CD-ROM Option Floppy disk drive Floppy disk PCI #1 PCI #2 PCI #3 PCI #4 PCI #5 3.5-inch PCI #6 hard disk drive bay SCSI...

  • Page 185: Disk Array Configuration Of Built-In Hard Disks

    Disk Array Configuration of Built-in Hard Disks For the disk array configuration of hard disks installed in the built-in 3.5-inch device bays, the disk array controller board of an option is installed in the server and the SCSI cable connected to the Ultra320 connector is disconnected from the connector and then connected to the disk array controller board instead.

  • Page 186: Installing A Scsi File Device

    Installing a SCSI File Device With the standard configuration, you need an optional SCSI controller and internal SCSI cable to install a file device. Terminator SCSI ID1 5.25-inch System board device bay CD-ROM SCSI cable (optional) SCSI ID0 Floppy disk SCSI controller board drive Floppy disk...

  • Page 187: Raid Controller

    The following figure shows an example of onboard SCSI connection for SCSI file devices. Terminator SCSI ID1 System board 5.25-inch device bay CD-ROM SCSI cable (optional) SCSI ID0 Floppy disk Disk array controller board drive Floppy disk PCI #1 PCI #2 PCI #3 PCI #4 PCI #5...

  • Page 189: Glossary

    Glossary (Alternating Current) The type of current available in wall outlets. All computers must convert alternating current to direct current to operate. See also DC. ACPI (Advanced Configuration and Power Interface) Provides the programming standard for power management features. address A label, name, or number that identifies a location in computer memory.
  • Page 190 Derived from BInary digiT, a bit is the smallest unit of information a computer handles. See also byte. (Baseboard Management Controller) Contains all of the server management functions. One major function of the BMC is to monitor system management events and log their occurrence in the System Event Log (SEL).
  • Page 191 (Central Processing Unit) See microprocessor. (Cathode-Ray Tube) The type of video display used in monitors for desktop computers. (Direct Current) The type of current available in the rechargeable battery packs used in portable computers. See also AC. default The factory setting your computer uses unless you instruct it otherwise. For example, when powering up, the computer will boot from the default drive.
  • Page 192 The Emergency Management Port (EMP) provides an interface to the console manager. This interface allows remote server management via a modem or direct connection. (Expanded Memory Specification) A method of accessing memory beyond the 640K limit of DOS by exchanging data in and out of main memory at high speeds. Some software requires EMS to operate.
  • Page 193 hard disk drive See disk drive. hardware The physical parts of your computer, including the keyboard, monitor, disk drives, cables, and circuit cards. hot swap A method used to insert or remove SCSI disk drives into or from an operating bus. This method is typically used in RAID subsystems.
  • Page 194 (Light-Emitting Diode) A small electronic device that glows when current flows through it. LPT1 or LPT2 The name you can assign a parallel port to specify its address. See also parallel port. Super-fast Ultra 2 SCSI Low Voltage Differential (LVD) Parallel SCSI Interface. A new SCSI interface that provides greater I/O bandwidth, device connectivity, data reliability, and longer cable lengths for Ultra2 SCSI hard disk drives.
  • Page 195 parallel port The connector on the back of your computer that allows the transfer of data between the computer and a parallel device, such as a parallel printer. partition The process of dividing the storage space on a hard disk into separate areas so that the operating system treats them as separate disk drives.
  • Page 196 (Read-Only Memory) A type of memory device that usually is used to store system BIOS code. This code cannot be altered and is not lost when the computer is powered off. See also BIOS, EPROM, and flash EPROM. RS-232C port An industry standard serial port.
  • Page 197 SVGA (Super VGA) A type of video display system that provides very high-resolution text and graphics on analog color monitors. system board The main circuit board in your computer. It contains most of the connectors and ports. tape drive A type of storage device using magnetic tape. (Transistor-Transistor Logic) A type of integrated circuit used in computers.
  • Page 199 Equipment Log Use this equipment log form to record pertinent information about your system. You will need some of this information to run the System Setup Utility. Be sure to update the equipment log when you add options. Record the model and serial numbers of the system components, dates of component removal or replacement, and the name of the vendor from whom the component was purchased.
  • Page 200 Serial Number Component Manufacturer Name & Model (if available) Date Installed Server System Board Processor 1 Processor 2 DIMM Slot 1A DIMM Slot 1B DIMM Slot 2A DIMM Slot 2B Modem Diskette Drive Tape Drive CD-ROM Drive Hard Disk Drive 1 Hard Disk Drive 2 Hard Disk Drive 3 Hard Disk Drive 4...
  • Page 201 Index Access lamp, 5-25 Hard disk, A-2 Advance menu Humidity, A-2 configuring in setup, 3-7 I/O port address, C-3 Battery Installation assumption installing, 4-11 Windows 2000, B-3 BIOS Installing using the setup utility, 3-3 Windows 2000, B-5 Integrated peripheral configuration menu, configuring in Setup, 3-8 CD-ROM, A-2 Interface, A-2...
  • Page 202 Power consumption, A-2 unpacking, 2-3 POWER lamp, 1-4, 5-25 System board Power on/off removing, 4-58 switch does not turn off AC power, 4-3 System disassembly and reassembly Power supply, A-2 removing the diskette drive and carrier POWER switch, 5-4 assembly, 4-48 Problems removing the front door and front door hinge application software, 5-13...
