Ford 2002 Windstar Owner's Manual

Ford motor company 2002 ford windstar owner's guide
Hide thumbs Also See for 2002 Windstar:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Quick Start — How to get going
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from Ford Motor Company. Ford may change the contents without
notice and without incurring obligation.
Copyright © 2001 Ford Motor Company

Table of contents

2
4
8
17
21
23
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2002 Windstar and is the answer not in the manual?

Questions and answers

Related Manuals for Ford 2002 Windstar

Summary of Contents for Ford 2002 Windstar

  • Page 1 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2001 Ford Motor Company...

  • Page 2: Quick Start — How To Get Going

    Quick Start — How to get going QUICK START — HOW TO GET GOING To operate the system: 1. Your AutoVision Video Entertainment System is automatically activated when the vehicle ignition and the audio system are ON. 2. If a movie is desired, insert a VHS cassette into the VCP and the video should start playing.
  • Page 3 Quick Start — How to get going To play a video game: 1. Connect the video line from your game device to the VIDEO jack. 2. Connect the left and right audio cables to the left (L) and right (R) audio jacks.

  • Page 4: Introduction

    Read all of the safety and operating instructions before operating the system and retain for future reference. Do not attempt to service, repair or modify the AutoVision Video Entertainment System. See your Ford or Lincoln Mercury dealer. Do not insert foreign objects into the videocassette player (VCP) tape cassette compartment.
  • Page 5 FEDERAL COMMUNICATION COMMISSION (FCC) COMPLIANCE Changes or modifications not approved by Ford Lincoln Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 6 Introduction Temperature extremes When the vehicle is parked under direct sunlight or in an extremely cold place for a long period of time, wait until the cabin temperature of the vehicle is at normal temperature before operating the system. High/low temperature sensor circuit Excessively high or low temperatures may cause damage to the VCP.
  • Page 7 Introduction Cleaning video heads Magnetic video heads convert the videocassette into pictures on the screen during playback. Over a period of time, particles rub off the tape and are left on the heads. Using an old or poor quality tape together with dust and air particles, high temperature and humidity cause dirty heads.

  • Page 8: Description

    Description AUTOVISION VIDEO ENTERTAINMENT SYSTEM Features 2–head hi-fi playback AutoPlay feature Digital auto tracking Dual stereo headphone with electric volume control Self docking connection for easy mobile installation Latching system for secure safety Carrying handle for portability Water resistant tape door On screen display Protection circuits Playback and format...
  • Page 9 Description VCP CONTROLS 1. LED display The display lamp will light up in green when power is supplied to the videocassette player. 2. POWER key Press to toggle between ON/OFF. When the power is ON, other keys (PLAY, FF, REW, STOP) will illuminate. 3.
  • Page 10 Description REMOTE CONTROL 1. POWER button Press to turn the videocassette player (VCP) ON or OFF. 2. ENCORE button Press to reverse the cassette for 5 seconds. Normal playback will then resume when in PLAYBACK mode. 3. STILL/ADVANCE (frame advance button) Press to temporarily suspend playback.
  • Page 11 Description 8. REW button Press to rewind the tape. 9. FF button Press to fast forward the tape. 10. STOP button Press to stop the tape. BATTERY REPLACEMENT Batteries are supplied with the remote control unit. However, they are simply for operation check and will only work for a short time. Slide battery cover off as shown on remote control to access the batteries.
  • Page 12 Description AUTOVISION VIDEO ENTERTAINMENT SYSTEM CONTROLS The AutoVision Video Entertainment System controls allow the rear seat passengers to operate the radio, tape, CD or CD DJ (if equipped). PARENTAL CONTROL Your AutoVision Video Entertainment System allows you to have control over the rear seat controls.
  • Page 13 Description ADJUSTING THE VOLUME This control allows the rear seat passengers to adjust the volume level of the audio system. Press the + control to increase the volume. Press the — control to decrease the volume. From the AutoVision Video Entertainment System controls, the speaker volume cannot be set higher than the current volume radio setting.
  • Page 14 Description Press the control again to engage the rear speakers and deactivate the Personal Audio Feature. SINGLE PLAY will appear in the radio display. For more information on Single Play and Dual Play, please refer to the Rear Seat Controls section in the Entertainment Chapter of your Owner’s Guide.
  • Page 15 MEMORY PRESET CONTROL In radio mode, press the MEM (Memory) control successively to scroll through the memory presets in AM, FM1 or FM2. In CDDJ mode, press the MEM (Memory) control to select the next disc in the compact disc changer. Play will begin with the first track.
  • Page 16 Description FLIP-DOWN SCREEN The screen rotates down to view and up into the housing to store when not in use. Ensure that the screen is latched into the housing when being stored. 1. 6.4” (diagonal) color liquid crystal display (LCD) screen. 2.

  • Page 17: Operating Instructions

    GENERAL OPERATION When the engine is not running, use the system sparingly otherwise it will run the battery down. Do not leave the videocassette in the VCP overnight or for long periods of time. When the ignition is turned ON, audio is through the headphones as LOW volume.
  • Page 18 Operating Instructions 2. Connect the left and right audio cables to the WHITE and RED jacks respectively. 3. Ensure that the system is in AUX mode. The LCD screen will turn on and the AUX indicator will illuminate. On-screen indicators Playback operation 1.
  • Page 19 If still playback/or frame-to-frame playback is engaged for five minutes or longer, the VCP will automatically begin playback to protect the tape. Automatic tracking is automatically activated the moment the VCP is turned ON or a cassette is inserted. If a videocassette is in poor shape (i.e., badly recorded), any tracking adjustment may result in failure.
  • Page 20 Operating Instructions Video source selection The MEDIA control determines which video (VCP or Auxiliary input) is seen on the AutoVision screen. When the vehicle ignition is ON and the system is not in VCP mode, the AutoVision selects the Auxiliary input as the video source.

  • Page 21: Videocassette Player Display Messages

    Videocassette Player Display Messages INDICATIONS ON THE VCP The operation and status of the VCP can be checked by the indications appearing on the LED display. 1. The Power indicator flashes on during POWER ON and will blink when in emergency mode. 2.
  • Page 22 Videocassette Player Display Messages Illuminates during power off when there is not a cassette present in the system. Illuminates when the videocassette is in REW (rewind) mode. Illuminates when the videocassette is in FF (fast forward) mode. Illuminates when the videocassette is in STIL (pause) mode.

  • Page 23: In-Home Use

    IN-HOME USE Your AutoVision Video Entertainment System is UL registered for in-home use. This system has the unique feature of also being a completely portable and able to be used in your home. To remove your AutoVision Video Entertainment System from your vehicle, depress the lever on the center console labeled VCP RELEASE.
  • Page 24 In-Home Use 1. VIDEO IN Connect this terminal to the VIDEO OUT terminal of your other apparatus (DVD, game machine, etc.). 2. AUDIO IN LR Connect these terminal(s) to the AUDIO OUT terminals of your other apparatus (DVD, game machine, etc.). Plug headphones into these jacks.
