Wheelock RS-2415 Installation Instructions Manual

273 Branchport Ave.
Long Branch, N.J. 07740
(732) 222-6880
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

RS (Universal Mounting) and RSP Strobe Appliances are UL Listed under Standard 1971 (Signaling Devices for the Hearing
Impaired) for indoor fire protection service. The 1575 candela strobes are listed at 15 candela under UL Standard 1971 and meet 75
candela intensity on axis with low current draw. Series RS Strobes are listed for indoor use only. 15cd, 30cd and 75cd models are
Listed for ceiling or wall mount and 15cd* models are Listed for wall mount with the backboxes specified in these instructions (See
Mounting Options). The strobes use a Xenon flashtube with solid state circuitry enclosed in a rugged Lexan lens to provide
maximum visibility and reliability for effective visible signaling. All inputs are polarized for compatibility with standard reverse
polarity supervision of circuit wiring by a Fire Alarm Control Panel (FACP).
: All and
NOTE CAUTIONS
WARNING: READ THESE INSTRUCTIONS CAREFULLY. FAILURE TO COMPLY WITH ANY OF THE FOLLOWING
INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, INSTALLATION AND/OR
OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND
SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Table 1: Ratings Per UL 1971
Model Nominal
Voltage
(VDC)
RS-2415 24
RS-241575 24
RS-2430 24
RS-2475 24
RS-1215 12
RS-121575 12
RS-1230 12
RSP-2415 24
RSP-241575 24
RSP-2430 24
RSP-2475 24
RSP-1215 12
RSP-121575 12
RSP-1230 12
THAT THESE STROBES FUNCTION EVEN AT 80% OF THEIR MINIMUM RATING AND 110% OF THEIR MAXIMUM RATING,
WHEELOCK STRONGLY RECOMMENDS THAT THE VOLTAGE APPLIED TO THESE PRODUCTS BE WITHIN THEIR RATED
INPUT VOLTAGE RANGE. THE APPLICATION OF IMPROPER VOLTAGE MAY RESULT IN DEGRADED OPERATION OR
DAMAGE TO THESE PRODUCTS, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO
YOU AND/OR OTHERS.
Voltage Rated Average Current
15cd
20.0VDC 0.80
24.0VDC 0.80
31.0VDC 0.80
20.0VFWR 0.80
24.0VFWR 0.81
31.0VFWR 0.91
Note: All VFWR voltage ratings are measured with a DC volt meter. Multiply VFWR voltage by 1.11 to convert to VRMS.
Copyright 1995-1997 Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES RS STROBE APPLIANCES
are identified by the symbol
WARNINGS
Rated Input Strobe Mounting
Voltage Candela
(VDC) (CD)
20.0-31.0 15
20.0-31.0 15*
20.0-31.0 30
20.0-31.0 75
10.5-15.6 15
10.5-15.6 15*
10.5-15.6 30
20.0-31.0 15
20.0-31.0 15*
20.0-31.0 30
20.0-31.0 75
10.5-15.6 15
10.5-15.6 15*
10.5-15.6 30
Table 2: Strobe Current Requirements (AMPS) 24VDC Models
30cd 15cd* 75cd
.135 .115 .245
.135 .115 .225
.135 .115 .195
.135 .125 .258
.135 .125 .233
.135 .125 .196
*15cd models are UL Listed at 15cd and meet 75cd on axis.
. All warnings are printed in bold capital letters.
Options
Product
Multitone Appliances
A,B,C,D
Motor Bells
A,B,C,D
Speakers
A,B,C,D
Chimes
A,B,C,D
RSP-241575 and RSP-121575 are used only with MT4, MB-G6/G10
A,B,C,D
and ET-1010
A,B,C,D
A,B,C,D
The UL Listed "Rated Input Voltage" is 20.0-31.0VDC or 10.5-
15.6VDC using either filtered (DC) or unfiltered full-wave-rectified
E,F
(FWR) voltage. Check the minimum and maximum output of the
E,F
E,F power supply and standby battery and subtract the voltage drop
E,F from the circuit wiring resistance to determine the applied voltage to
E,F
the strobes.
E,F
E,F
WARNING:
Rated Peak Current
15cd 30cd 15cd*
.160 .288 .250
.190 .296 .260
.210 .296 .260
.210 .390 .350
.216 .390 .365
.240 .390 .365
Table 1A.
Audibles/Speakers for RSP Strobe/Plate
Series
MT, MT4, AH
MB-G6/G10
ET-1010/1070/1080, E70/90, ET70/90
CH-DF1/DF2, CH70
ALTHOUGH UL TESTING HAS VERIFIED
Rated Inrush Current
75cd 15cd 30cd
.510 .210 .280
.450 .250 .280
.370 .320 .300
.714 .320 .390
.640 .380 .390
.520 .450 .420
15cd* 75cd
.225 .660
.270 .660
.360 .880
.315 .930
.380 .930
.500 1.25
P83134 G
Sheet 1 of 6
