6. In order to re-create disk partitions to their initial state prior to the disaster, record
the following information for each partition (it will be needed during the recovery
process):
• partitions length and order
• drive letters assigned to the partitions
• partitions filesystem type
This information is stored in the SRD file. The -type option in the diskinfo section
of the SRD file shows the partition filesystem type for a particular partition:
Table 4 How to determine the filesystem type from the SRD File
Type number
1
4 and 6
5 and 15
7
1 1 and 12
18
66
The table on the next page is an example of the preparation for the disaster recovery.
Note that data in the table belongs to a specific system and cannot be used on any
other system. Refer to
template" on page 149 for an empty template which can be used when preparing for
the Assisted Manual Disaster Recovery.
Table 5 Example of the AMDR preparation template
Client properties
Drivers
46 Disaster recovery for Windows
"Windows manual disaster recovery preparation
computer name
hostname
Filesystem
Fat12
Fat32
Extended partition
NTFS
Fat32
EISA
LDM partition
ANDES
andes.company.com
hpn.sys, hpncin.dll
