CMO Operations & Logistics
Training and Vendor Development
Multimedia Creation & Support
Service Manual N73- RM-33 / N73-5 RM-33
Page
CONFIDENTIAL
SERVICE MANUAL
Level &2
RM-33
Copyright © 2006 NOKIA Corporation. All rights reserved.

(36)
RM-32
Transceiver characteristics:
Band:
- RM-133: Dual Mode WCDMA2100/EGSM 850/900/1800/1900MHz
- RM-132: Quadband EDGE GSM phone for 850/900/1800/1900MHz
Camera: 3.2 Megapixel (2048x1536 pixels) with 20x digital zoom
Display: QVGA color TFT display with 262.144 colors,
resolution 240 x 320 pixel
Bluetooth
IrDA
FM radio
Memory Card: miniSD™
Connector: Pop-Port™ connector
Transceiver with BP-6M Li-Ion battery pack
Talk time
GSM: up to 4.1 h
GSM: up to 14.6 days
WCDMA: up to 3.8 h
WCDMA: up to 15.4 days
Environmental characteristics:
•
Lead-free soldered
Approved 2.0
5.Sep.2006
Standby
Note
Depends on network
parameters
MGR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N73-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nokia N73-1

Summary of Contents for Nokia N73-1

  • Page 1 GSM: up to 4.1 h GSM: up to 14.6 days Depends on network WCDMA: up to 3.8 h WCDMA: up to 15.4 days parameters Environmental characteristics: • Lead-free soldered Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 2: Table Of Contents

    QUICK TROUBLE SHOOTER - ZOOMS PART 5 GONOGO TEST BATTERY TEST CHANGE HISTORY Status Version No. Date Comments Draft 13.Jun.2006 Initial draft Approved 13.Jul.2006 Approval Apporved 5.Sep.2006 Exploded view updated Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 3: Introduction

    INTRODUCTION The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential.

  • Page 4: General Repair Information

    Common Software Service Bulletins etc,… Use General SB-217 as a reference or overview. Please also check NOKIA Online (NOL) for latest news and files on a regular basis. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 5: Pathfinder For Workshop Staff

    Videos – Disassembly/Assembly NOKIA Online Care Services Training Phone Models Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use the phone: Overview & Guides Disassembly & Assembly Troubleshooting Basic information about the phone,...

  • Page 6: Exploded View And Component Disposal

    Recommendation for the ecologically friendly disposal of components. Colorized components show the different categories. See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 7: Component Overview

    Page (36) Approved 2.0 CMO Operations & Logistics Training and Vendor Development 5.Sep.2006 Multimedia Creation & Support CONFIDENTIAL COMPONENT OVERVIEW Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 8: Spare Parts List

    Bulletins (spare parts, SWAP units and service tools). This will ensure, that you are using up-to-date order codes only. Therefore Service Bulletins have to be checked from NOL on daily basis. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 9: Service Tools

    FM radio or music player. CA-53 Service Cable to connect the PC with the Pop-Port™ connector. RJ-32 Soldering Jig Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 10 For more informations refer to the Service Bulletin (SB-011) on NOKIA Online. Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on NOKIA Online. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 11: Sw-Update

    To use FLS-4S Flash Dongle you have to follow the user guide inside the sales package. Please check always for the latest version of flash software, which is available on NOKIA Online. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 12: Disassembly Instruction 2

    6. Hold the SS-93 in the shown position and unlock the side clip A-COVER and unlock the button clip first. with SRT-6 by pressing it between the A-COVER and the B-COVER. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 13 10. Lift the A-COVER a bit and unlock its top side from the B- COVER with the SS-93. 11. Remember to protect the inner side of the window with a 12. Unlock and remove the KEYMAT. protective film. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 14 15. Gently lift out the DISPLAY with the SS-93 from the UI 16. …and disconnect it from the ENGINE MODULE. FRAME… 17. Open the FRONT CAMERA connector. 18. Remove the FRONT CAMERA from the UI-FRAME. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 15 22. Remove the screws and discard them. 23. The UI FRAME is attached with two snaps to the B-COVER. 24. Unlock the UI FRAME with the SS-93. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 16 28. Remove the UI FRAME with the UI MODULE from the B-COVER. 29. Take special care to the BASEBAND GASKET. 30. Open the snap if it snapped back and remove the LIGHT GUIDE. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 17 36. The ENGINE MODULE is snapped to the B-COVER with two remove it carefully from its housing. snaps. Unlock the ENGINE MODULE with the SS-93 ... Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 18 40. Lift the IHF SPEAKER from its housing and remove it easily. 41. Gently push down the FLASH LED from the ANTENNA 42. Remove the GASKET IHF HOUSING. MOULDING. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 19 45. Use the DC plug to release the DC-JACK. 46. The DC-JACK drops out easily when turning the B-COVER. 47. The disassembly procedure is now finished. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 20: Assembly Instruction

    5. Place the DC-JACK with tweezers into its housing ... 6. and push it carefully into place with the SS-93. Do not bend the spring contacts. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 21 IHF SPEAKER. with the SS-93. 11. Insert the ANTENNA MOULDING in the B-COVER... 12..and press it lightly into place. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 22 15. Pay special attention to the SWITCHES when inserting the 16. Secure the ENGINE MODULE. ENGINE MODULE into the B-COVER. 17. Clean the camera window. 18. and the MAIN CAMERA with compressed air. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 23 23. Ensure the correct position of the CAMERA BOOT when 24. Fit the FRONT CAMERA to the UI-FRAME. putting it onto the FRONT CAMERA. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 24 28. Put the UI FRAME into the B-COVER and press it into place. it to the UI FRAME. 29. Gently, close the connectors. 30. Use always new screws when assembling the unit. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 25 34. Set the torque driver to the torque of 28 Newton centimeter. shown. 35. Now, tighten the last screw to the correct torque. 36. Connect the DISPLAY to the ENGINE MODULE... Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 26 40. Insert the SD DOOR but do not close it yet. 41. Put the KEYMAT into the A-COVER. 42. Check the window for cleanliness ... Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.
  • Page 27 44. Now, close the SD DOOR. 45. Fit the SLIDE COVER ASSEMBLY 46. Finally, check the functionality of the keys and ensure that there are no gaps between the covers. Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 28: Legend For Quick Trouble Shooter

    Page (36) Approved 2.0 CMO Operations & Logistics Training and Vendor Development 5.Sep.2006 Multimedia Creation & Support CONFIDENTIAL LEGEND FOR QUICK TROUBLE SHOOTER Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 29: Quick Trouble Shooter - Main Overview

    Page (36) Approved 2.0 CMO Operations & Logistics Training and Vendor Development 5.Sep.2006 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - MAIN OVERVIEW Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 30: Quick Trouble Shooter - Zooms Part 2

    Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - ZOOMS PART  . POWER (4) 2. CHARGING (4) 3. NO SERVICE (2) 4. SIM () Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 31: Quick Trouble Shooter - Zooms Part

    Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - ZOOMS PART 2 5. IHF SPEAKER/2 (4) 6. KEYMAT (4) 7. JOYSTICK (3) 8. DISPLAY (3) Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 32: Quick Trouble Shooter - Zooms Part

    Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - ZOOMS PART 3 9. MICROPHONE (2) 0. EARPIECE (2) . LEDs (3) 2. VOLUME KEY (2) Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 33: Quick Trouble Shooter - Zooms Part 4

    CONFIDENTIAL QUICK TROUBLE SHOOTER - ZOOMS PART 4 3. SLIDE DETECT (3) 4. CAMERA KEY (2) 5. CAMERA MODE KEY (2) 6. FRONT CAMERA (3) Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 34: Quick Trouble Shooter - Zooms Part 5

    Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - ZOOMS PART 5 7. MAIN CAMERA (3) 8. SD CARD READER (3) 9. FLASH LED (2) Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 35: Gonogo Test

    Warning: Do not point the IR (infrared) beam at anyone’s eye or allow it to interfere with other IR devices. This device is a Class 1 Laser product. Reference unit, Bluetooth /infrared activated Test unit Service Manual N73- RM-33 / N73-5 RM-33 Copyright © 2006 NOKIA Corporation. All rights reserved.

  • Page 36: Battery Test

    Training and Vendor Development 5.Sep.2006 Multimedia Creation & Support CONFIDENTIAL BATTERY TEST A battery tester lets you test the capacity of NOKIA batteries. Please refer to the actual information on NOKIA Online. http://www.astratec.co.uk/ http://www.cadex.com/ Service Manual N73- RM-33 / N73-5 RM-33...
