Projector Parts
Ventilation slots
Infrared
receiver
Lens
S-video
Video port
Input B
port
(composite
(computer)
video)
Remote
Audio ports
RS-232 port
control
holder
Ceiling mount holders
Air filter intake vent
Adjustable feet
Control panel
Focus lever
Zoom lever
Adjustable foot
Input A
Infrared
(component
receiver
video)
Speaker
Power
Security lock
inlet
Rubber foot
Lamp cover
EPSON PowerLite Home 10 Projector
Projector Specifications
General
Type of display
Size of LCD panels
Lens
Focus adjustment
Zoom ratio
Resolution
Color
reproduction
Brightness
Contrast ratio
Image size
Projection distance
Projection methods Front, rear, upside-down (shelf or ceiling
Sound output
Optical aspect ratio 16.9
Keystone correction
angle
Keystone correction
ratio
Noise level
Supported video
interface standards
Projection Lamp
Type
Power consumption 132W
Lamp life
Part number
Remote Control
Range
Battery
7/03
EPSON PowerLite Home 10 Projector - 1
Poly-silicon Thin Film Transistor (TFT)
active matrix with Micro Lens Array
Diagonal: 0.55 inches (14 mm)
F=1.7 to 2.1 mm, f=13.9 to 21.4 mm
Manual
Digital 1.1 to 1.54, lens at maximum size
854 × 480 pixels (480p native resolution)
24 bit, 16.7 million colors
1000 ANSI lumens (Dynamic color
mode)
700:1 (Theatre Black color mode)
30 to 300 inches (0.76 to 7.6 m)
Tele: 3.7 to 38 ft (1.1 to 11.6 m)
Wide: 2.4 to 25 ft (0.7 to 7.6 m)
mount)
1W monaural
±
15° vertical
9.6:1
29 dB (Theatre Black color mode)
32 dB (all other color modes)
HDTV, NTSC, NTSC4.43, PAL,
M-PAL, N-PAL, PAL60, SECAM
UHE (Ultra High Efficiency)
About 3000 hours (Theatre Black
color mode)
About 2000 hours (other color modes)
V13H010L2H
20 feet (6 meters)
Lithium (CR2025)
