- Page 1 PB-210E TYPE 1E PART NUMBER QTY DESCRIPTION REMARKS POWER BLOWER PARTS CATALOG MODEL PB-210E TYPE 1E SERIAL NUMBER 001001 & UP ECHO, INCORPORATED 400 OAKWOOD ROAD LAKE ZURICH, IL 60047 999222028464 11/99...
- Page 2 PB-210E TYPE 1E ENGINE, EXTERNAL/INTERNAL/CRANKCASE/COVER...
- Page 3 PB-210E TYPE 1E ENGINE, EXTERNAL/INTERNAL/CRANKCASE/COVER PART NUMBER QTY DESCRIPTION REMARKS 90032303014 KEY, WOODRUFF 10000003360 PISTON KIT INCLUDES ITEMS 3 - 6 10001504630 CIRCLIP, PISTON PIN 10001105530 RING, PISTON 10001303360 PIN, PISTON 10001221230 BEARING, NEEDLE 10101003361 GASKET, CYLINDER BASE INCLUDED IN KIT 88900003361 90016205020 BOLT, H.S.
- Page 4 PB-210E TYPE 1E INTAKE, AIR CLEANER, EXHAUST...
- Page 5 PB-210E TYPE 1E INTAKE, AIR CLEANER, EXHAUST PART NUMBER QTY DESCRIPTION REMARKS 90024205045 SCREW 5X45 17851600830 WASHER 12300003662 CARBURETOR WT-409B 90024204010 SCREW 4X10 10027003360 INSULATOR 14585803360 MUFFLER 14551003361 GASKET, MUFFLER INCLUDED IN KIT 88900003361 90016205016 BOLT, H.S. 5X16 14580903361 LID, MUFFLER 14590603361 COVER, MUFFLER 90024205020...
- Page 6 PB-210E TYPE 1E IGNITION/FUEL SYSTEM/STARTER 10 11 14 15...
- Page 7 CASE, STARTER ------------------- ROPE, STARTER USE BULK ROPE 99944400040 DIA. 3.0 MM (.12 IN.) LENGTH 850 MM (33.5 IN.) 17722705020 GUIDE, ROPE 17722806530 GRIP, STARTER 89011849330 LABEL, ECHO 90024205025 SCREW 5X25 17730703360 HOLDER, PAWL 15680003361 FLYWHEEL 90024204020 SCREW 4X20 15662703361...
- Page 8 PB-210E TYPE 1E FAN/CASES/PIPES...
- Page 9 90024905020 SCREW 5X20 89011503360 LABEL, MODEL 90024905025 SCREW 89017603361 LABEL, NOISE 21000103360 PIPE, STRAIGHT W/LABEL INCLUDES ITEM 33 89011804261 LABEL, ECHO 21040003360 CLAMP INCLUDES ITEMS 35 & 36 90050000004 NUT 4 90022004025 SCREW 4X25 21001403360 PIPE, STRAIGHT 21002301060 PIPE, CURVED...
- Page 10 PB-210E TYPE 1E CARBURETOR...
- Page 11 PB-210E TYPE 1E CARBURETOR PART NUMBER QTY DESCRIPTION REMARKS 12300003662 CARBURETOR ASY WT-409B INCLUDES THE FOLLOWING 12313002960 SCREW 12314203930 COVER, METERING DIAPHRAGM DIAPHRAGM, METERING GASKET, METERING DIAPHRAGM LEVER, METERING SPRING, METERING LEVER VALVE, INLET NEEDLE 12313903930 SCREW, METERING LEVER PIN PIN, METERING LEVER PLUG, WELCH 12312715030...
