Philips Lytecaster 1021 Specification

Page 1 of 2
1021/1002P1 Series
Standard Incandescent
7 1/2"
1021/1004IC
0
™
Non-IC Only
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1000P1
1002P1
1003R
1021 Opal
1000IC
1000AICM
1004ICX/N
1004IC/N
1004ICR
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); Anobrite™
(anodic-processed) semi-specular finish for permanent reflectivity.
2. Diffuser: Pressed and blown 3-layer cased opal glass; twists tight into
reflector trim. Neoprene (captive on flange of reflector) seals unit under
pressure of twist lock. Concealed wire-hinge supports glass enclosure
for servicing.
3. Frame-In Kit: (1002P1 standard frame shown). Other frames listed above
and shown on the right. See Frame-In Kit specification sheets for more
details.
Options & Accessories
Retaining Clips: 1955 - For installing in existing ceiling.
Labels
UL (Suitable for Wet Locations - covered ceiling, showers, spas), I.B.E.W.
Lightolier is a Philips group brand
Convertible
Incandescent
Ceiling Type Lamping
Non-IC 75W A19 6 3/4"
Non-IC
Non-IC
Remodeler
IC 40W A19 7 5/16"
IC AirSeal
®
IC AirSeal ®
Non-IC 40W A19 7 1/2"
Non-IC
Remodeler
Lytecaster
5" Aperture Opal Disk Diffuser Reflector Trim
7 1/4"
6 3/4"
Height Frame-In Kit Ceiling Type
1001F13U Series Uniframe
6 3/4"
1001F18U Series Uniframe
7 5/16"
7 1/4"
1001F13ICU/N
Performance IC
7 1/2"
1001F18ICU/N Performance IC
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • M0608
Recessed Downlighting
®
1021/1004ICX/N
0
AirSeal Insulated Ceiling
™ ®
1021/1003R
0
Non-IC Remodeler
Fluorescent
Lamping
Non-IC (1) Quad 13W (G24q-1)
™
Non-IC (1) Quad 18W (G24q-2)
™
(1) Quad 13W (G24q-1)
(1) Quad 18W (G24q-2)
Type:
1021
™
Height
5 7/8"
5 7/8"
7 1/4"
7 1/4"
