Colour/Color Monitor CML200UXWB USER MANUAL Congratulations on your selection of the HITACHI Colour Monitor. Read the instructions inside carefully, and keep this user manual for future reference. NOTE: * The information in this manual is subject to change without notice. The manufacturer assumes no responsibility for any errors that may appear in this manual.
Page 6
Setting the Refresh Rate ..................19 Minimizing Power Consumption ................20 Caring for and Cleaning the Display ................. 20 Adjusting Your Display ................21 Summary of Control Buttons ..................21 Displaying the OSD “Main Menu” ................21 Selecting Items in the OSD Menu ................22 Doing Adjustment in the OSD Menu .................
Introduction This latest LCD monitor has a 20.1-inch active matrix TFT (thin film transistor) liquid ® crystal display module. It is designed for use with any Windows -based PC. The monitor’s compact-sized design provides great space savings on your computer desk. Features Important features include: Automatic configuration to the PC video settings with maximum UXGA resolution.
Using this Display Safely Common Safety Precautions Please read carefully and make sure you fully understand the following safety precautions: Operations should be done according to instructions and procedures described in this manual. Make sure to heed all warnings displayed on the device and manual. Neglecting to do so may result in fire or damage the device.
Warning Abnormal heat, smoke, sounds or smells. If anything abnormal should happen, turn OFF the power and unplug the power cord. Continued use in this condition may lea d to electrical shock or fire. The area around the cord should be clear to allow the cord to be easily unplugged. Repair, Modification, Disassembly DO NOT attempt to repair, modify or disassemble the product.
Page 10
Handling of the power cord Use the power cord supplied with the product and be careful of the following during use. If handled improperly, the cord may be damaged resulting in electrical shock or fire. Never place objects on it. DO NOT pull DO NOT apply pressure DO NOT fold...
Page 11
Handling the AC adapter DO NOT wet or handle with wet hands. This may result in electrical shock. DO NOT use with devices other than this display. This may result in shock, fire, or damage to the device. DO NOT use or place in areas where heat accumulates. This may result in fire. Multi-Tap Usage TO not attach multiple extension plugs into one outlet.
CAUTION Contact with Metal and Other Edges When moving the computer be careful when coming in contact with the plastic and metal edges. It is possible to be injured. Use in Unstable Places DO NOT place on sloping or narrow areas that are unstable. The device may drop or fall and cause injury.
Page 13
Electronic Interference If used in the vicinity of other electronic devices, they may interfere with each other’s performances. Especially for devices such as radios and televisions, noise may enter their sound reception. If this should happen, try the following: Place in a location as far away from radios and televisions as possible. Change the facing of the antenna on the radio or television.
FCC Statement Warning WARNING : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
For the Customers in the UK THIS PRODUCT IS SUPPLIED WITH A TWO PIN MAINS PLUG FOR USE IN MAINLAND EUROPE. FOR THE UK PLEASE REFER TO THE NOTES ON THIS PAGE. IMPORTANT FOR UNITED KINGDOM WORDING FOR CLASS I EQUIPMENT INSTRUCTION BOOKS AND LABELS The mains lead on this equipment is supplied with a moulded plug incorporating a fuse, the value of which is indicated on the pin face of the plug.
Installation Please follow the instructions in this chapter to install your LCD Monitor. Note: Before connecting your display, first read through the instructions in this chapter and the safety precautions in the previous chapter. Unpacking the Display When you are unpacking the display, make sure that you have the following items: The LCD monitor AC power adapter with attached power cable A power cord...
You will use the power button located at the lower right side of the front panel of your display to turn on and off the display. The functions of the three control buttons, which are located at the lower middle-left side of the front panel of your display, are described as below: Button Function Description...
Page 18
Speaker housing Note: For best display performance, it is strongly recommended that you use Auto Setup to automatically configure your display’s settings (only for Analog input).
Using Your Display This chapter contains information about using your LCD Monitor. Turning the Display On and Off Use the power button located at the lower right side of the front panel of the display to turn the display on and off. When the display is on, the light (LED) near the Power button is illuminated.
Tilting the Display The monitors have a tilt feature that allows you to tilt the display back and forth as well as left and right to find the most comfortable viewing position. To tilt the display, grasp the sides and push the display back or pull it toward you, or turn it left or right until it is in the desired position.
The table in “Video Mode” on page 32 shows the image refresh rates supported by the display at different screen resolution. Although your LCD monitor supports up to 75 Hz for analog video input, we recommend that you use 60 Hz refresh rate for best performance. To set the refresh rate with a standard Windows installation, follow the steps mentioned in your Windows’s or graphic card’s user’s manual.
Adjusting Your Display This chapter contains information about how to changing display settings for your LCD Monitor. It is designed with an OSD menu to help you easily adjust to its optimum performance. Note: You must perform auto setup before making any adjustment. Summary of Control Buttons There are three control buttons located at the lower part of the front panel of your display: Select: Display the On-Screen Display (OSD) “Main Menu”...
The following table briefly describes each of the items in the OSD “Main Menu”. Item Description Brightness Controls the brightness of the display by adjusting the light output of the backlight. The default setting of brightness is at maximum. Contrast Adjust the level of difference between light and dark areas of the image.
Page 24
Adjusting the Contrast Setting To adjust Contrast setting you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Select’ button to move forward to the contrast icon and highlight it. 3. Use ‘Right’ and ‘Left’ button to adjust its value. The range for adjustment is from 0 to 100.
Page 25
Color Exit Color Temp RGB Adjust Black Level Adjust If ‘Exit’ is selected, it will exit the “Color” submenu and forward to the next item in the “Main Menu”. (i.e., Clock/Phase icon.) If ‘Color Temperature’ is selected, it will bring-up “Color Temp” submenu. Use ‘Right’ and ‘Left’...
Page 26
Colok/Phase Exit Auto Setup Clock Phase If ‘Exit’ is selected, it will exit the “Clock/Phase” submenu and forward to the next item in the “Main Menu”. (i.e., Management icon.) If ‘Auto Setup’ is selected, it will execute ‘Auto Setup’ function. Please refer to ‘Auto Setup by Direct Key’...
Page 27
Adjustment in the “Management” submenu To adjust Management settings you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Select’ button to move forward to Management icon and highlight it. This will bring-up the “Management” submenu. There are seven items for your choice in this submenu: Exit, Mode Info, OSD Display, Scale/Center, Language, Source and Recall Factory Setting.
buttons to highlight and switch Analog, Digital input signal. If your selected input signal is missing it will search next input signal by automatic untill get available. The searched sequence by ‘Left’ button is downward, and by ‘Right’ button is upward. Note: As you choose an item, your display immediately updates to reflect this setting.
Page 29
If the image requires further adjustment, choose No, it will shown up ‘Phase’ bar for your further adjustment by manual. Then you can adjust the phase by ‘Right’ or ‘Left’ buttons. When all text appears well focused and there is no instability in the image, press the ‘Select’...
If ‘Surround’ is selected, it will bring-up “Surround” submenu with ‘On’ and ‘Off’ prompt for your confirmation. Use ‘Right’ and ‘Left’ buttons to choose and ‘Select’ button to make your confirmation for audio surround output or not. ‘Key Lock’ Functions: Press ‘RIGHT’...
Troubleshooting This chapter contains information about how to troubleshoot your LCD Monitor. If you have tried all of the items listed below, please contact a qualified service personnel. A. My display doesn’t work, even though the computer appears to work. 1.
Technical Information This chapter contains technical information about your LCD Monitor. Display Information LCD Module 20.1-in (51 cm), active matrix TFT, anti-glare coating, 0.255 mm pixel pitch Display Size 408 mm x 306 mm Viewing Angle Left/Right -85 ~ 85 Up/Down -85 ~ 85 Luminance...
Digital: Supported Resolution Vertical Frequency (dots x lines) (Refresh Rate) 640 x 480 60 Hz 640 x 480 75 Hz SVGA 800 x 600 60 Hz 800 x 600 75 Hz 1024 x 768 60Hz SXGA 1280 x 1024 60Hz UXGA 1600 x 1200 60Hz...
Page 35
Fax: +46 (0) 8 562 711 13 Tel: +39 02 38073415 Servizio Clienti Email: csgswe@hitachi -eu.com Fax: +39 02 48786381/2 Email: customerservice.italy@hitachi -eu.com HITACHI EUROPE S.A.S HITACHI EUROPE LTD (Norway) AB Lyon Office STRANDVEIEN 18 B.P. 45, 69671 BRON CEDEX 1366 Lysaker FRANCE...
