Philips Lytespan 23S20P3 Specification

Page 1 of 2
7
4 3/4 in
[121 mm]
Ordering Information
Catalog No. Finish
23S20P3AL
Aluminum
23S20P3BK Black
23S20P3WH White
Features
1. Track Attachment Fitting: Locking lever for mechanical/
electrical connection.
2. Brass Contact: Extends for connection to second circuit (Advent track only).
3. Horizontal Pivot: Wireless stem profile with 365° horizontal rotation.
Position may be locked using an allen key.
4. Vertical Pivot: 0-90° vertical adjustment with aiming indicator.
Position may be locked using an allen key.
5. Fixture Housing: Die cast aluminum
6. Ballast Housing: Molded polycarbonate
7. On/Off Switch: Rocker switch to disconnect power to the ballast.
8. Accessory Cartridge: Hinged and captive; retaining ring included. Inside
painted black to reduce glare.
9. Safety Locking Lever: Locks ballast housing to track.
Finish
All Painted finishes are baked enamel.
Accessories
Accessory Holder: Integral
Accessories: Accepts 1 snoot plus 2 lenses or 1 louver plus 1 lens.
Louver can be used without lens.
Lens: AF3, ADF3 Series
Louver: AL3HC
Lightolier is a Philips group brand
1 15/16 in 2
[49 mm]
7/8 in
[23 mm]
7 7/8 in
[201 mm]
Mounting
For use with Lytespan Radius, Basic and Advent
Track. Not compatible with monopoints, extension
wands or slope ceiling adapters. for monopoint
applications refer to spec sheet 6171.
Lytespan Track Lighting System
®
Alcyon HID 20W CMH PAR30L Step Spot
7 5/8 in
[193 mm]
5 11/16 in
1 3/8 in
[144 mm]
[35 mm]
9
5 1/8 in
6
[130 mm]
8
[165 mm]
Lamps
20W PAR30L Ceramic Metal Halide
Electrical
Electronic Ballast
Input Voltage: 120V, 50/60Hz
Power Factor: High
Input Power: 24.5W
Max. Input Current: 0.20A
ANSI Code: M156
Do not use on dimming circuit.
Labels
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A0608
23S20P3
1
3
4 in
[101 mm]
1/4 in
4
[6 mm]
5
6 1/2 in
Type:
