Page 7
ABOVE ALL NEVER let anyone, especially children push anything into holes, slots or any other opening in the case - this could re- sult in a fatal electric shock. NEVER guess or take chances with elec- trical equipment of any kind - it is better to be safe than sorry!
Page 8
The mains plug is used to disconnect the TV from the mains and therefore it shall remain readily operable. Warning: To prevent injury, this device must be securely attached to the floor/wall in ac- cordance with the installation instrutions. WARNING: When the device is not in use for a long time, disconnect from power.
Before Switching On Your TV NOTE: Remove the batteries from remote control handset when it is not to be used for a long period.Otherwise it can be damaged due to any leakage of batteries. Switching The TV ON/OFF...
Specifications RMS. ',0(16,216 PP Information for users applicable in European Union countries This symbol on the product or on its packaging means that your electrical and electronic equipment should be disposed at the end of life separately from your household wastes. There are separate collection systems for recycling in EU.
• It is recommended that a scart lead should be fitted between your TV and VCR to enhance your picture and sound quality. Scart leads are essential if you have a stereo TV and VCR and wish to obtain stereo sound from your equipment. These leads can be purchased from your Hitachi dealer or any good High Street electrical retailer.
Page 31
...or through a satellite decoder... TFT-LCD TV RF Lead from Aerial Satellite to TV • Scart Lead to EXT-1 on TV. ANT.IN RF Lead to Aerial Satellite LNB lead ...or through a VCR and satellite decoder. TFT-LCD TV RF Lead from •...
connect the TV plug to the mains socket UK plug European plug Power Cord Power on/off Input button ...and switch on insert plug... Plug the mains lead into the TV insert plug... switch your TV on by pressing the On/Off button TV/AV MENU P/CH...
important note before starting Auto Setup If you have a Video Cassette Recorder or a Satellite receiver connected to your TV please ensure that they are switched on before automatic tuning begins. In the case of a VCR, insert a pre-recorded tape and begin playback of your equipment. These measures ensure that all your external equipment is tuned in during the Auto Setup procedure.
Page 34
To install the TFT TV on the wall, first of all, foot assembly should be removed. (Figure 1). Unscrew the screws (M4 x 8) that attach the foot assembly to the TFT panel and remove the foot assembly from the TFT panel. Decide the place on the wall where the TFT panel would be placed.
Page 36
Hitachi Ltd. Consumer Business Group Shin-Otemachi Bldg 5f, 2-1, Otemachi 2-Chome, Chiyoda-Ku, Tokyo 100-0004 Japan HITACHI EUROPE LTD. HITACHI EUROPE S.A. Consumer Affairs Department 364, Kifissias Ave. & 1, Delfon Str. PO Box 3007 152 33 Chalandri Maidenhead Athens Berkshire SL6 8ZE...
