Summary of Contents for Motorola LS350

  • Page 2: Table Of Contents

    Introduction ........... 1 Reading Stored Messages....16 Getting Started ........2 Saving Messages......17 Installing/Replacing the Battery ..3 Deleting Messages ......18 Control Buttons ........4 Deleting a Single Message ....18 Turning Your Pager On ......5 Deleting All Messages....... 19 Turning Your Pager Off ......

  • Page 3: Introduction

    ™ If your LS350 has the f symbol, it uses FLEX technology. The Motorola FLEX protocol-based pagers offer extended battery life and improved paging reliability. To fully understand the features this pager offers, please take a few minutes to read this user’s guide.

  • Page 4: Getting Started

    Effective Use of Your Pager Your pager can help you keep in contact with everyone important to you. By giving your pager number to your business associates, family, and friends, you can be contacted whenever needed. If you have a cellular phone, give your pager number instead of your cellular number.

  • Page 5: Installing/Replacing The Battery

    Installing/Replacing the Battery Turn the pager off. Refer to “Turning Your Pager Off” on page 6. Locate the battery door on the back of the pager. Slide the battery door in the direction of the arrow to unlatch the battery door. Lift the battery door up to open.

  • Page 6: Control Buttons

    Control Buttons Read Button Menu Button Select Button Menu Used to access pager menus and to turn on the backlight. Read Used to turn the pager on, read messages, and navigate through menus. Select Used to select pager settings and features. Also used to read additional screens of messages.

  • Page 7: Turning Your Pager On

    Turning Your Pager On Press . The start-up screens are f hjlb e displayed and your pager activates the MOTOROLA power on chime (when in audible mode). Press any button to stop the alert. The unread message (home) screen f hjlb e is displayed.

  • Page 8: Turning Your Pager Off

    Turning Your Pager Off From the Standby screen, press twice. f hjlb e PAGER OFF Press and release until PAGER OFF displayed, then press is displayed momentarily before f ojlb e the pager shuts off, and is removed from the display. The off screen displays the time and f ojlb e date, and if the alarm is set, the alarm...

  • Page 9: Sending A Test Page To Yourself

    Sending a Test Page to Yourself After you have read this guide and your pager has been activated by your service provider, send yourself a test page. Refer to “Functionality and Use of Your Pager” on page 34. Backlight In low-light conditions, press and hold for 2 seconds to turn on the pager’s backlight.

  • Page 10: Time And Date

    Setting the Time and Date From the Standby screen, press twice. f hjlb e Press and release until SET UP PAGER SET UP PAGER is displayed. Press f hjlb e TIME/DATE is displayed. TIME/DATE Press f hjlbe FORMAT! AM/PM FORMAT!AM/PM FORMAT!24HR displayed.
  • Page 11 Press and release until your choice of (for AM/PM time), or FORMAT!AM/PM FORMAT!24HR (for 24-hour time) is displayed, then press The screen used to set the time is f hjlbe displayed with the hour digit flashing. TIME! 12!00A Press until the correct hour is f hjlbe displayed, then press TIME! 03!00A...
  • Page 12 After the time has been set, the f hjlbe screen used to set the date is DATE! 07/01 displayed. Press and release until the correct f hjlbe month is displayed, then press DATE! 07/05 Press and release until the correct day is displayed, the press is displayed momentarily.

  • Page 13: Alerts

    Selecting the Incoming Message Alert You can set your pager’s incoming message alert to a vibration alert or you can select one of the musical alerts. From the Standby screen, press twice. f ojlbe SELECT ALERT Press and release until SELECT ALERT is displayed, then press The current alert setting is displayed.

  • Page 14: Alert Audio

    When the desired alert is displayed, f ojlbe press . The pager gives a sample of SELECTED your selection. SELECTED is displayed momentarily. Alert Audio The Alert Audio feature allows you to select one of the musical alerts. When Alert Audio is selected in the f hjlbe Select Alert feature the previously AUDIO 1...
  • Page 15 Press and release until your choice of f hjlbe musical alert is displayed. The pager AUDIO 2 gives a sample of each alert as you scroll through the choices. Press to select the alert. SELECTED is displayed and the pager f hjlbe gives a sample of the alert.

  • Page 16: Messages

    Messages Your pager can receive up to 30 messages. When a message is received, your pager alerts according to the current alert setting flashes. Reading New Messages Press to stop the alert and display the f hjlbe number of new messages. NEW! 2 Press again to display the first unread...
  • Page 17 Repeat Steps 2 and 3 to read the next f hjlbe message. is displayed after the very last message is displayed. To exit from any screen while reading your messages, press GO)HOME displayed, then press . The number of unread (new) messages is displayed before the pager returns to the Standby mode.

  • Page 18: Reading Stored Messages

    Reading Stored Messages From the Standby screen, press hjlbe twice. The first screen of the first stored 555-1212 message is displayed. Note: If no messages are stored, MESSAGES is displayed. Press to display the second screen of f hjlbe your message. If you want to view the 3!30P first screen again, press again.

  • Page 19: Saving Messages

    After you have viewed all stored f hjlbe messages, is displayed. Note: To exit from any screen while reading your messages, press GO)HOME is displayed, then press . The number of unread messages is displayed before the pager returns to the Standby mode.

  • Page 20: Deleting Messages

    Deleting Messages Messages that you no longer want can be deleted one at a time or all at once (delete all). Unread messages and messages that have been moved to the message folder are not deleted. Deleting a Single Message Display the message you want to delete.

  • Page 21: Deleting All Messages

    Deleting All Messages This feature allows you to delete all previously read messages at one time. Unread messages and messages stored in the message folder are not deleted with this feature. From the Standby screen, press twice. Press and release until DEL ALL MSGS f hjlbe...

  • Page 22: Message Folder

    Message Folder You can prevent important messages from being deleted, or from being overwritten by new messages, by moving them into the folder. Messages moved into the folder retain their original time stamp. Up to 15 messages can be moved into the folder. MEM FULL is displayed if you try to move a message into the folder when there is not enough storage space left.
  • Page 23 Press f hjlbe MOVED is displayed indicating the MOVED message has been moved to the folder and the pager returns to the read-message mode. Note: After messages are moved to the folder, they can not be moved back into the personal message area. They can only be read or deleted.

  • Page 24: Reading Messages In The Folder

    Reading Messages in the Folder From the Standby screen, press twice. f hjlbe GO)FOLDER is displayed. GO)FOLDER Press to display the first screen of your f hjlbe message. 555-1212 Note: If no messages are stored in the folder, NO MESSAGES is displayed.
  • Page 25 Press to display the next stored f hjlbe message. If you want to display just the 555-1234 first screen of your messages, continue to press and release After you have viewed all messages f hjlbe stored in the folder, is displayed. Note: To exit from any screen while reading your messages, press GO)HOME...

  • Page 26: Deleting Messages From The Folder

    Deleting Messages from the Folder Note: Messages in the folder can only be deleted one at a time. With the message displayed, press f hjlbe 555-1212 Press and release until DELETE MSG f hjlbe displayed. DELETE MSG Press f hjlbe DELETED is displayed.

  • Page 27: Alarm 1

    Alarm Your pager has an alarm that can be set for one time on a specific date, a specific time daily, or a specific time weekly. At the selected alarm time, your pager alerts with the same alert as the incoming message alert.
  • Page 28 Press f hjlbe is displayed. Press and release until displayed, then press The screen used to set the alarm time f hjlbe is displayed. TIME! 12!00A Set the alarm time by following the steps in “Setting the Time and Date” on page 8.
  • Page 29 When you have finished setting the f hjlbe alarm time, the screen used to set the DATE! 01/01 alarm date is displayed. Enter the alarm date by following the steps in “Setting the Time and Date” on page 8. When you have finished setting the f hjlbe alarm date, press and release until...

  • Page 30: Turning Off A Daily Or Weekly Alarm

    At the alarm time, your pager alerts, ALARM 1 is displayed, and the indicator flashes. Press any button to remove the alarm indication. Note: If the alarm is set for Weekly or Daily, the indicator stays on the display. Turning Off a Daily or Weekly Alarm From the Standby screen, press twice.

  • Page 31: Message And Pager Indicators

    Connect Function The menu selection is intended for use by service personnel only. CONNECT When selected, an alternating pattern of cC Cc is displayed. To exit this screen, press any button twice and the pager restarts. Message and Pager Indicators Your pager has several indicators to inform you of the status of your messages and your pager.

  • Page 32: Indicators

    Alarm The alarm icon is displayed when the alarm is set and flashes during the alarm alert. Memory Full When the pager memory is full, for example, all message locations are occupied, MEM FULL is displayed in the Standby screen until a button is pressed.

  • Page 33: Belt Clip

    Belt Clip Your pager has a removable belt clip. To remove and replace the belt clip, follow the instructions below. Removing the Belt Clip Push down on tab Insert the pointed end of a non-metallic to release item (such as a pen cap) into the top belt clip end of the belt clip as shown in the illustration.

  • Page 34: Use And Care

    Cleaning Your Pager To clean smudges and grime from the exterior of your pager, use a soft, non-abrasive cloth moistened in a mild soap and water solution. Use a second cloth moistened in clean water to wipe the surface clean. Do not immerse in water.

  • Page 35: Care And Maintenance

    For more information about warranties, please contact either your paging service provider, retailer, or Motorola, Inc. at 1-800-548-9954. For repairs, call Motorola, Inc. at 1-800-548-9954 in the U.S. or 1-800-323-9685 in Canada. In the U.S., to contact Motorola, Inc. on your TTY, call 1-800-793-7834.

  • Page 36: Patent Information

    Functionality and Use of Your Pager For questions pertaining to the functions and use of your Motorola pager please visit our web site at www.motorola.com/pagers or in the U.S. call 1-800-548-9954 or 1-800-793-7834 (TTY). For questions pertaining to your paging service, contact your paging service provider.
  • Page 37 Regulatory Agency Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 41 SUCH PRODUCT, TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW. Motorola pagers are shipped from the factory with a standard limited warranty of one (1) year on parts and labor from date of purchase by the original end user purchaser, based on proof of purchase. In the event of a defect, malfunction, or failure to conform to specifications during the warranty period,...
  • Page 42 • Pagers whose serial numbers do not match on the boards, or pagers in which the board serial numbers don’t match the housing. • Pagers that have been opened by, or had work performed by, anyone other than a Motorola authorized pager service center.
  • Page 43 Personal Numbers Use the spaces provided below to write down your pager and personal identification number (PIN), and the number of your service provider. Additional spaces have been provided to write down the pager and PIN of your family and friends. Service Provider Pager Number and PIN Family and Friends...
  • Page 44 Tested To Comply With FCC Standards FOR HOME OR OFFICE USE t, Motorola, FLEX, f, and LS350 are trademarks or registered trademarks of Motorola Inc. Reg. U.S. Pat. & Tm. Off. © 1998, 1999 by Motorola, Inc. All Rights Reserved.
  • Page 45 LS350 Quick Reference Card Control Buttons Turning Your Pager Off From the Standby screen, Read press twice. Select Press and release until PAGER Menu is displayed, then press Indicators and Icons Setting the Time and Date Pager is on. When flashing, From the Standby screen, indicates an unread message.
  • Page 46 Press and release until the Setting the Alarm correct month is displayed, then From the Standby screen, press . Repeat this step to set the press twice. day. Press and release until ALARM is displayed, then Moving Messages to the Folder press twice.
