Appendix A
A.1 Factory Reset
In the event that a reset is required, the DriveRack
Soft Reset resets all operating parameters except user programs. The Hard Reset Procedure will reset all programmable
information back to the factory defaults.
All Power-Up Functions require a button(s) to be pressed and held as the unit power is turned on.
DriveRack PA Power-Up Button Functions
Factory ("Hard") Reset.
Press and hold the <STORE> button at power-up until the following message appears:
• Pressing the <PREV PAGE> button will start a Factory Reset (All User Programs will become
copies of the Factory Programs, all Utility settings will be defaulted, and all Security settings
will be defaulted).
• Pressing the <PROGRAM> button will abort the Factory Reset sequence and the unit will reset
normally.
System ("SOFT") Reset
• Press and hold the <UTILITY> button at power-up until the following message appears:
• Pressing the <PREV PAGE> button will start a System Reset (All Utility settings will be defaulted.)
• Pressing the <PROGRAM> button will abort the System Reset sequence and the unit will
reset normally.
A.2 Power Up Quick Key Options
®
The DriveRack PA offer several "Quick Key" options for initial power up and are as follow:
Change Initial Program Number
• To change the initial power program number, Press and hold the <PROGRAM> button at
power-up until the following message appears:
U U s s e e W W h h e e e e l l t t o o "C C h h a a n n g g e e R R e e s s t t a a r r t t "P P r r o o g g r r a a m m N N u u m m b b e e r r "
• Turning the <DATA> wheel will select the program you wish to load at initial reset.
• Press the <PROGRAM> button again when the selection is complete. Normal resetting will
continue.
System Lock Out
• Press and hold <WIZARD> at power-up until one of the following messages appears:
S S y y s s t t e e m m U U n n l l o o c c k k e e d d A A l l l l u u s s e e r r i i n n p p u u t t w w i i l l l l b b e e a a c c c c e e p p t t e e d d
S S y y s s t t e e m m L L o o c c k k e e d d N N o o u u s s e e r r i i n n p p u u t t w w i i l l l l b b e e a a c c c c e e p p t t e e d d
• Rotating the <DATA> wheel to select either Lock, Unlock or Filter Unlocked the system.
• Pressing <PREV PAGE> will unlock the system if it were locked or it will lock the system if it were unlocked.
• If you wish to leave the system locked with the exception of being able to clear the feedback filters, follow the same
procedure on power up and then rotate the <DATA> wheel to select the feedback filter unlock feature.
• Pressing any other button will abort the System Lockout sequence and the unit will reset normally.
DriveRack
36
" " ! ! H H A A R R D D R R E E S S E E T T ? ? "
" " Y Y e e s s < < P P R R E E V V P P A A G G E E > > "
" " N N o o < < P P R R O O G G R R A A M M > > "
" " ! ! S S O O F F T T R R E E S S E E T T ? ? "
" " Y Y e e s s < < P P R R E E V V P P A A G G E E > > "
" " N N o o < < P P R R O O G G R R A A M M > > "
or
® PA User Manual
®
PA offers you the option of performing a "Soft" or "Hard" reset. The
DriveRack
®
®
PA
®
®
