ROSETTA 800 – User's Guide
Features and Specifications
• 8 channels of premium 24-bit AD/DA conversion
• Sample rates up to 96k with optional 192k upgrade
• 8 channels of AES, ADAT I/O
• Optional Firewire card for compatibility with OS X, and Windows XP
• "Soft Limit" for maximum digital level without overs
• "UV22HR" for superior dither to 16-bit
INPUTS:
• Analog In 1-8: Balanced, DSUB connector
• AES in: x 4, transformer balanced, DSUB connector
• Optical - ADAT/SMUX In: Toslink
• WC In: BNC 75 ohm
OUTPUTS:
• Analog Out 1-8: Balanced, DSUB connector.
• AES Out: x 4, transformer balanced, DSUB connector
• Optical - ADAT/SMUX Out: Toslink
• WC Out: BNC 75 ohm
Due to on-going development Apogee reserves the right to change all information and specifications without notice.
SPECS:
• Sample rates: 44.1 - 48k, 88.2 - 96k (+/-10%);
176.4 - 192k (optional)
• Frequency response: 10 –20k (+/- 0.2 dB) at 44.1k
• Analog max levels: +6dBV, +20dBu, +24dBu max
(set by internal jumper)
• Dynamic range: 114 dB A weighted (AD + DA)
• THD+N: -105 dB (AD), -103 dB (DA)
• Power: 90-250 VAC, 50-60Hz, 45Watt
14
