Sony SA-WCT100 Service Manual

Active subwoofer speaker system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

SA-WCT100/SS-MCT100

SERVICE MANUAL

Ver. 1.0 2008.02

• SA-WCT100 is the ampliﬁ er, HDMI and active sub-

woofer section in HT-CT100.

• SS-MCT100 is the satellite speaker in HT-CT100.

• Repair in the state of having connected with SA-

WCT100 and SS-MCT100.

This system incorporates Dolby* Digital and Pro Logic Surround and the DTS** Digital Surround System.

* Manufactured under license from Dolby Laboratories.

Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories.

** Manufactured under license under U.S. Patent

6,487,535 & other U.S. and worldwide patents #'s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; issued & pending. DTS and DTS Digital

This system incorporates High-Definition Multimedia Interface (HDMI™) technology.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

"BRAVIA" is a trademark of Sony Corporation.

Formats supported by this

system

Digital input formats supported by this system

are as follows.

Format

Supported/Not supported

Dolby Digital

DTS

Linear PCM (2ch)*

Linear PCM (5.1ch,

7.1ch)* (Only on

HDMI)

Dolby Digital Plus

Dolby True HD

DTS-HD

* Linear PCM accepts sampling frequencies of no

more than 48 kHz.

Sony Corporation

9-887-974-01

2008B05-1

Audio Business Group

2008.02

Published by Sony Techno Create Corporation

Photo: SA-WCT100

SPECIFICATIONS

AUDIO POWER SPECIFICATIONS

(SA-WCT100)

POWER OUTPUT AND TOTAL HARMONIC

DISTORTION (Stereo mode):

With 8 ohms loads, both channels driven, from 180 -

20,000 Hz; rated 40 Watts per channel minimum RMS

power, with no more than 1 % total harmonic distortion

from 250 milli Watts to rated output.

Amplifier section (SA-WCT100)

Reference Output Power

Surround mode

Front: 50 Watts/ch

(8 ohms at 1 kHz,

THD 10 %)

Center*: 50 Watts/ch

(8 ohms at 1 kHz, THD

10 %)

Subwoofer: 100 Watts/ch

(4 ohms at 100 Hz,

THD 10 %)

* Depending on the sound field settings and the source,

there may be no sound output.

US Model

Canadian Model

Photo: SS-MCT100

Inputs (Analog)

Impedance: 30 kohms

Inputs (Digital)

TV, DVD

Optical

SAT

Coaxial, optical

HDMI section (SA-WCT100)

Connector

HDMI 19pin-standard

connector

Video inputs/outputs

BD, DVD, SAT:

640 × 480p@60 Hz

720 × 480p@59.94/60 Hz

1440 × 480p@59.94/60 Hz

(pixel sent 2 times)

1280 × 720p@59.94/60 Hz

1920 × 1080i@59.94/

60 Hz

1920 × 1080p@59.94/

60 Hz

720 × 576p@50 Hz

1440 × 576p@50 Hz

(pixel sent 2 times)

– Continued on next page –

SA-WCT100

ACTIVE SUBWOOFER

SS-MCT100

SPEAKER SYSTEM

Table of Contents

Need help?

Do you have a question about the SA-WCT100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony SA-WCT100

Page 1: Specifications
SERVICE MANUAL US Model Canadian Model Ver. 1.0 2008.02 • SA-WCT100 is the ampliﬁ er, HDMI and active sub- woofer section in HT-CT100. • SS-MCT100 is the satellite speaker in HT-CT100. • Repair in the state of having connected with SA- WCT100 and SS-MCT100.
Page 2 LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONC- TIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DON- NÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
Page 3: Table Of Contents
- MAIN Board (Component Side) (SA-WCT100) - ..26 5-13. Printed Wiring Board - MAIN Board (Conductor Side) (SA-WCT100) - ..27 5-14. Printed Wiring Board - IO Board (SA-WCT100) - ..28 5-15. Schematic Diagram - IO Board (SA-WCT100) - ... 29 5-16. Printed Wiring Board - HDMI Board (Side A) (SA-WCT100) - .......
Page 4: Servicing Notes
Part No.: J-2501-238-A JIG FOR SPEAKER REMOVAL NOTE OF REPAIR CONFIRMING Repair in the state of having connected with SA-WCT100 and SS- MCT100. NOTE THE IC3511 and IC3513 ON THE HDMI BOARD REPLACING When IC3511 and IC3513 cannot exchange with single. When IC3511 and IC3513 are damaged, exchange the entire mounted board.
Page 5 SA-WCT100/SS-MCT100 SERVICE POSITION Note 1: Take all board out from SA-WCT100 and connect each board. Note 2: In checking the board, make a capacitor discharge of C903 for electric shock prevention. 800 Ω/2W Note 4: SA-WCT100 is connected with SS-MCT100, and remote commander is operation.
Page 6: Top Panel Overview
The buttons are factory assigned to control Lights as follows: Sony components. You can change the Green: The system is turned on. factory settings of the input buttons to suit Amber: Control for HDMI function is the components in your system.
Page 7: Power Board (Sa-Wct100)
SA-WCT100/SS-MCT100 SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW (SA-WCT100) 3-4. AMP BLOCK 3-2. FRONT PANEL ASSY 3-3. GRILLE ASSY (Page 8) (Page 9) (Page 10) 3-5. IO BOARD (Page 10) 3-6.
Page 8: Front Panel Assy
SA-WCT100/SS-MCT100 Note: Follow the disassembly procedure in the numerical order given. 3-2. FRONT PANEL ASSY Note: Please do set by placing the grille assy side up as shown in the ﬁ gure and work. Insert the jig (J-2501-238-A) into a space made by inserting the screwdriver, and raise the front panel assy gradually.
Page 9: Grille Assy
SA-WCT100/SS-MCT100 3-3. GRILLE ASSY Note: Please do set by placing the grille assy side up as shown in the ﬁ gure and work. Insert a flat-tip screwdriver into a recess grille assy in the bottom of the grille assy to raise the front panel assy a little.
Page 10: Amp Block
SA-WCT100/SS-MCT100 3-4. AMP BLOCK AMP block connector (CN252) five screws (4 × 20) 3-5. IO BOARD twelve screws (BVTP3 × 8) bracket (top) wire (flat type) (19 core) (IO board: CN202/MAIN board: CN1018) IO board screw (BVTT3 × 6) screw (BVTP3 ×...
Page 11: Hdmi Board
SA-WCT100/SS-MCT100 3-6. HDMI BOARD harness three screws (HDMI board: CN3509/ (BVTP3 × 8) MAIN board: CN1005) screw (BVTP3 × 8) wire (flat type) (17 core) (HDMI board: CN3511/ MAIN board: CN1004) HDMI board left HDMI bracket two screws (BVTP3 × 8) four screws (BVTP3 ×...
Page 12 SA-WCT100/SS-MCT100 3-8. MAIN BOARD two screws (BVTP3 × 8) radiation sheet heat sink connector two connectors (CN1002) (CN3003,CN3005) six screws (BVTP3 × 8) MAIN board seven screws (BVTP3 × 8) bracket (shield) 3-9. POWER BOARD five screws (BVTP3 × 8)
Page 13: Test Modes In Test Menu
1. TEST MODES OTHER THAN THE TEST MENU 2-2. Tone Test 2-8. Digital Media Port Test Note: SA-WCT100 is connected with SS-MCT100, and remote com- These are executable test mode even if not entering the test menu. Procedure: mander is operation. If SS-MCT100 is not connected, remote 1.
Page 14 SA-WCT100/SS-MCT100 SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM - MAIN Section (SA-WCT100) - DIR_XSTAE, DIR_LRCK, DIR_MCK, DIR_BCK, DATA_AD DIGITAL AUDIO (Page 15) INTERFACE RECEIVER D1FLFR, D3CSW, IC1011 DPDVLRCK, J201 SCHMITT D1FLFR DSP_BCK COAX TRIGGER DIN1 DATA0(O) 16 DPSIA DPSOA 64 IC206...
Page 15 SA-WCT100/SS-MCT100 5-2. BLOCK DIAGRAM - HDMI Section (SA-WCT100) - (Page 14) DATA0+ DATA0- DATA1+ DATA1- TX0+ 30 DATA0+ TX0- 29 DATA0- DATA2+ DATA2- Y2 31 RX0+ TX1+ 33 DATA1+ CN3501 Z2 32 RX0- TX1- 32 DATA1- SAT IN CLOCK+ CLOCK-...
Page 16 SA-WCT100/SS-MCT100 5-3. BLOCK DIAGRAM - AMP Section (SA-WCT100) - M3001 (FAN) FAN DRIVE D1FLFR, D3CSW, +12V Q3000 - 3002 DPDVLRCK, DSP_BCK CN3008 (Page 14) ONLY FOR D3505 D3504 SS-CMT100 STREAM PROCESSOR POWER AMP SPEAKER IC3010 IC3056 D1FLFR 31 DATA OUTL1 11...
Page 17 (HDMI (AMBER)) LED2 IC951 IC3050 Q802 RESET RESET SIGNAL RESET SWITCH GENERATOR Q1003 IC1006 +3.3V SYSTEM REGULATOR HDMI+3.3V CONTROLLER ISOLATOR IC3526 IC1002 (4/4) PC902 +1.8V +3.3V REGULATOR HDMI+1.8V REGULATOR CN871 IC3527 IC3528 REMOTE CONTROL (TO SA-WCT100) SIRCS RECEIVER P_CONT4 IC871 SA-WCT100/SS-MCT100...
Page 18 SA-WCT100/SS-MCT100 THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. • Circuit Boards Location (In addition to this, the necessary note is printed in each block.) – SA-WCT100 – For Printed Wiring Boards. For Schematic Diagrams. Note: Note: •...
Page 19: Schematic Diagram Main Board (1/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-5. SCHEMATIC DIAGRAM - MAIN Board (1/7) (SA-WCT100) - • See Page 40 for IC Block Diagrams. MAIN BOARD IC B/D (1/7) IC1015 DGND SELECTOR SW3.3V HDMI_SD0 2.6V R1180 MAIN SI_B BOARD R1183 HDMI_LRCK C1029 (2/7) MAIN SI_C BOARD...
Page 20: Schematic Diagram Main Board (2/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-6. SCHEMATIC DIAGRAM - MAIN Board (2/7) (SA-WCT100) - • See Page 40 for Waveforms. • See Page 40 for IC Block Diagrams. MAIN BOARD IC B/D (2/7) IC1208 R1098 100 A/D CONVERTER CN1018 MAIN AGND BOARD (1/7) L CH...
Page 21: Schematic Diagram Main Board (3/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-7. SCHEMATIC DIAGRAM - MAIN Board (3/7) (SA-WCT100) - • See Page 40 for Waveforms. • See Page 40 for IC Block Diagrams. • See page 50 for IC Pin Function Description. MAIN BOARD (3/7) SW3.3V SI-3010KM-TL IC B/D +1.2V REGULATOR...
Page 22: Schematic Diagram Main Board (4/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-8. SCHEMATIC DIAGRAM - MAIN Board (4/7) (SA-WCT100) - • See Page 40 for Waveforms. • See Page 40 for IC Block Diagrams. MAIN BOARD (4/7) R3060 NSP_MUTE SOFT_MUTE R3059 PGMUTE SCDT SHIFT LAT3 C3067 R3067 100p R3031 OVF2...
Page 23: Schematic Diagram Main Board (5/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-9. SCHEMATIC DIAGRAM - MAIN Board (5/7) (SA-WCT100) - • See Page 40 for IC Block Diagrams. MAIN BOARD (5/7) R3010 100k MAIN IC3500 BOARD IC3500 CXD9883M C3004 IC B/D (4/7) 26.7 (Page 22) PVDD_A R3503 POWER AMP BST_A C3520 31.3...
Page 24: Schematic Diagram Main Board (6/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-10. SCHEMATIC DIAGRAM - MAIN Board (6/7) (SA-WCT100) - • See Page 40 for IC Block Diagrams. (Page 23) MAIN BOARD (5/7) MAIN BOARD (6/7) Q3102 Q3152 ISA1235AC1TP-1EF ISA1235AC1TP-1EF OVER LOAD DETECT OVER LOAD DETECT IC B/D IC3056 POWER AMP...
Page 25: Schematic Diagram Main Board (7/7) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-11. SCHEMATIC DIAGRAM - MAIN Board (7/7) (SA-WCT100) - • See Page 40 for IC Block Diagrams. • See page 50 for IC Pin Function Description. MAIN BOARD (7/7) DMPORT MAIN BOARD (2/7) (Page 20) (Page 22) AMP_3.3V MAIN...
Page 26: Printed Wiring Board Main Board (Component Side) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-12. PRINTED WIRING BOARD - MAIN Board (Component Side) (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. (Page 35) DISPLAY BOARD MAIN BOARD (COMPONENT SIDE) CN801 CN1017 C3055 C3053 IC1002 C1036 R3067...
Page 27: Printed Wiring Board Main Board (Conductor Side) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-13. PRINTED WIRING BOARD - MAIN Board (Conductor Side) (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. MAIN BOARD (CONDUCTOR SIDE) (CHASSIS) (Page 34) (Page 38) SPOUT POWER BOARD BOARD (CHASSIS) CN251...
Page 28 SA-WCT100/SS-MCT100 5-14. PRINTED WIRING BOARD - IO Board (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. • Semiconductor Location Ref. No. Location IC201 IC202 IO BOARD IO BOARD (COMPONENT SIDE) (CONDUCTOR SIDE) IC203...
Page 29 SA-WCT100/SS-MCT100 5-15. SCHEMATIC DIAGRAM - IO Boards (SA-WCT100) - • See Page 40 for IC Block Diagrams. IO BOARD J201 C213 COAX L201 220uH R213 IC201 IC204 IC B/D TC74VHC153FT(EL) OPTICAL RECEIVER R214 IC201 TORX147L IC206 TC7WHU04FU(TE12R) C202 R215 C201...
Page 30: Printed Wiring Board Hdmi Board (Side A) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-16. PRINTED WIRING BOARD - HDMI Board (Side A) (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. • Semiconductor Location Ref. No. Location HDMI BOARD D3501 HDMI D3502 (SIDE A) TV OUT...
Page 31: Printed Wiring Board Hdmi Board (Side B) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-17. PRINTED WIRING BOARD - HDMI Board (Side B) (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. • Semiconductor Location Ref. No. Location D3513 (SIDE B) HDMI BOARD IC3507 IC3509 IC3521 Q3507...
Page 32: Schematic Diagram Hdmi Board (1/2) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-18. SCHEMATIC DIAGRAM - HDMI Board (1/2) (SA-WCT100) - • See Page 40 for waveforms. • See Page 40 for IC Block Diagrams. • See page 50 for IC Pin Function Description. ( 1 / 2 ) H D M I B O A R D 1 .
Page 33: Schematic Diagram Hdmi Board (2/2) (Sa-Wct100)
SA-WCT100/SS-MCT100 5-19. SCHEMATIC DIAGRAM - HDMI Board (2/2) (SA-WCT100) - • See Page 40 for waveforms. • See Page 40 for IC Block Diagrams. • See page 50 for IC Pin Function Description. ( 2 / 2 ) H D M I B O A R D C N 3 5 1 0 3 .
Page 34: Printed Wiring Board Spout Board (Sa-Wct100)
SA-WCT100/SS-MCT100 5-20. PRINTED WIRING BOARD - SPOUT Board (SA-WCT100) - 5-22. PRINTED WIRING BOARD - REMOTE Board (SS-MCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. • See Page 18 for Circuit Boards Location. •...
Page 35: Printed Wiring Board Display Board (Sa-Wct100)
SA-WCT100/SS-MCT100 5-24. PRINTED WIRING BOARD - DISPLAY Board (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. • Semiconductor Location Ref. No. Location D801 (Page 37) (Page 26) (Page 37) D802 TSW2 MAIN D803...
Page 36: Schematic Diagram Display Board (Sa-Wct100)
SA-WCT100/SS-MCT100 5-25. SCHEMATIC DIAGRAM - DISPLAY Board (SA-WCT100) - • See Page 40 for IC Block Diagrams. ND801 DISPLAY BOARD FLUORESCENT INDICATOR TUBE CN803 DGND Q801 Q802 KEY2 RT1N141C-TP-1 RT1N141C-TP-1 LED DRIVE LED DRIVE KEY1 48 47 44 43 39 38...
Page 37: Printed Wiring Boards Panel Section (Sa-Wct100)
SA-WCT100/SS-MCT100 5-26. PRINTED WIRING BOARDS - PANEL Section (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. S801 - 804 TSW2 BOARD (SIDE A) TSW BOARD (SIDE A) S804 S803 S802 S801 DISPLAY –...
Page 38 SA-WCT100/SS-MCT100 5-28. PRINTED WIRING BOARD - POWER Board (SA-WCT100) - • See Page 18 for Circuit Boards Location. • : Uses unleaded solder. (CHASSIS) R969 D907 D906 R906 R926 R925 EB902 C907 D908 IC901 R907 C913 D913 JW919 R919 JW907...
Page 39 SA-WCT100/SS-MCT100 5-29. SCHEMATIC DIAGRAM - POWER Board (SA-WCT100) - • See Page 40 for IC Block Diagram. D931 FCU20UC20 C938 330p 250V CN902 (CHASSIS) TP903 CN901 P31.5 LF901 LF902 C963 D901 C930 L931 TP901 LINE 0.0022 LINE R931 R940 R937 P31.5...
Page 40 SA-WCT100/SS-MCT100 • Waveforms • IC Block Diagrams – MAIN Board – – HDMI Board – – MAIN Board – IC1, 1001 SI-3010KM-TL IC1011 (CKOUT) (XTAL) IC3511 (XTALOUT) 3.8 Vp-p 1.6 Vp-p 2.2 Vp-p 81.4 ns 40 ns 35.3 ns 1 V/DIV, 50 ns/DIV...
Page 41 SA-WCT100/SS-MCT100 IC1011 LC890561W IC1014, 1015 TC74VHC157FT (EKJ) SELECT 11 1 1A 2 STROBE INPUT 36 35 32 31 30 INPUT OUTPUT REGULATOR FS CALCULATION 11 12 OUTPUT INPUT PA,PB DETECT 24 AUDIO INPUT OUTPUT C-BIT DETECT 23 EMPHA GND 8...
Page 42 SA-WCT100/SS-MCT100 IC3010, 3030 CXD9843AR CLOCK CLOCK GENERATOR 36 XFSIIN GENERATOR (SECONDARY) (PRIMARY) XVSS 35 DVDD VSUBC 34 TEST 33 BFVSS VSSR OUTR2 32 BFVDD VDDR DATA FILTER & SAMPLING OUTR1 LINER GAIN LOW CUT RATE INTERPOLATOR CONTROL VSSR FILTER CONVERTER...
Page 43 SA-WCT100/SS-MCT100 IC3056 CXD9845AM GVDD_B 1 GVDD_B GVDD_A GVDD_A BST_A /UVP OVER CURRENT FAULT VREG /HIZ_HS PVDD_A GATE /OTW 2 /HIZ_LS DRIVE STUCK /SD 3 DETECT PROTECTION TIMING PWM_A 4 LOGIC CONTROL OUT_A GATE /OCH DRIVE /OCL /RESET OVER CURRENT FAULT...
Page 44 SA-WCT100/SS-MCT100 IC3400, 3500 CXD9883M BST_A PVDD_A Over Current Fault GVDD_A PVDD_A /OTW PVDD_A VREG Gate Drive /HIZ_HS_A PGND /HIZ_LS_A Stuck Detect /RESET PGND Protection Logic Timing PWM_A PGND Control /OCH_A Programmable OC_ADJ OUT_A /OCL_A Current sense Gate Drive OUT_A /RESET_A...
Page 45 SA-WCT100/SS-MCT100 IC208 SI-3010KM-TL – VOUT – HDMI Board – IC3503 TMDS341APFCR 80 79 RX W/EQ RX W/EQ RX W/EQ RX W/EQ SDA1 RX W/EQ SCL1 RX W/EQ RX W/EQ RX W/EQ RX W/EQ RX W/EQ RX W/EQ RX W/EQ SCL3...
Page 46 SA-WCT100/SS-MCT100 IC3507 PCA9517DP.118 VCCA 8 VCCB SCLA 7 SCLB SDAA 6 SDAB 5 EN IC3513 SII9030CTU-7 HSYNC 60 CGND VSYNC 59 CVCC18 VIDEO DATA CAPTURE / DE GEN / 656 LOGIC BLOCK CGND 58 D14 CVCC18 57 D15 56 D16...
Page 47 SA-WCT100/SS-MCT100 IC3516 TK11150CSCL-G IC3526, 3527 SI-3033KM-TL OVER HEAT & OVER CURRENT PROTECTION CONTROL – CIRCUIT – BANDGAP REFERENCE VOUT – DISPLAY Board – IC802 ML9208-03MBZ03B 64 VDD 63 DA 8 BIT SHIFT 62 CP REGISTER 61 CS 60 RESET COMMAND...
Page 48 SA-WCT100/SS-MCT100 – POWER Board – IC901 STR-F6138-LF1352 CURRENT MIRROR DELAY LATCH DELAY OVER BOTTOM CURRENT PROTECT SKIP LOGIC LOGIC OVER OVER OVER VOLTAGE THERMAL OVER LOAD FEED CURRENT CURRENT PROTECT SHUT DOWN PROTECT PROTECT BACK PROTECT INTERNAL BIAS SWITCHING UNDER VOLTAGE...
Page 49 SA-WCT100/SS-MCT100 IC921 STR-V153 UVLO INTERNAL − DELAY LATCH − BIAS OFF TIMER DRIVE POWER PRC LATCH MOS FET − − BLANKING BURST − DISCHARGE – − BUFFER 1 2 3 IC941 SI-3120KM-TL IC942 SI-3050KM-TL IC943 SI-3033KM-TL – VOUT...
Page 50 SA-WCT100/SS-MCT100 • IC Pin Function Description MAIN BOARD IC2 ADSST-AVR-1115 (DSP) Pin No. Pin Name Description VDDINT Power supply terminal (+1.2V) (for core) Core instruction rate to CLKIN (pin 142) ratio selection signal input terminal CLKCFG0 Fixed at "L" in this set...
Page 51 SA-WCT100/SS-MCT100 Pin No. Pin Name Description DPSOB Audio serial data output terminal Not used VDDINT Power supply terminal (+1.2V) (for core) Ground terminal VDDINT Power supply terminal (+1.2V) (for core) Ground terminal DPSOC Audio serial data output to the stream processor...
Page 52 SA-WCT100/SS-MCT100 Pin No. Pin Name Description MISO Serial data output to the system controller MOSI Serial data input from the system controller Ground terminal VDDINT Power supply terminal (+1.2V) (for core) VDDEXT Power supply terminal (+3.3V) (for I/0) AVDD Power supply terminal (+1.2V) (analog system)
Page 53 SA-WCT100/SS-MCT100 MAIN BOARD IC1002 M30626MJP-A16FPU (SYSTEM CONTROLLER) Pin No. Pin Name Description DAMP_SCD Serial data output to the stream processor DAMP_SHIFT Shift clock signal output to the stream processor XCEC_DI CEC serial data input from the HDMI TV OUT connector "L"...
Page 54 SA-WCT100/SS-MCT100 Pin No. Pin Name Description P_CONT4 Power on/off control signal output for HDMI section "H": power on DIR DO Serial data input from the digital audio interface receiver DIR_XSTATE Source clock selection monitor input from the digital audio interface receiver "L"...
Page 55 SA-WCT100/SS-MCT100 HDMI BOARD IC3511 SII9011CLU (HDMI RECEIVER) Pin No. Pin Name Description VSYNC Vertical synchronize signal output for the HDMI transceiver 2 to 5 QO23 to QO20 Not used IOGND Ground terminal IOVCC Power supply terminal (+3.3V) 8 to 11...
Page 56 SA-WCT100/SS-MCT100 Pin No. Pin Name Description IOGND Ground terminal MCLK Audio clock signal output for the DSP and HDMI transceiver CGND Ground terminal CVCC18 Power supply terminal (+1.8V) AUDPVCC18 Power supply terminal (+1.8V) AUDPGND Ground terminal XTALOUT System clock output termnal (28.322 MHz) XTALIN System clock input terminal (28.322 MHz)
Page 57 SA-WCT100/SS-MCT100 HDMI RE BOARD IC3519 M30620FCPGP-RCT01 (HDMI CONTROLLER) Pin No. Pin Name Description 1 to 5 Not used BYTE Not used CNVSS Processor mode switch input terminal (for test) 8, 9 Not used RESET Reset signal input from the main system controller "L": reset...
Page 58: Cabinet Section (Sa-Wct100)
Les composants identiﬁ és par la marque 9 contiennent des informations conﬁ den- tielles. Suivre scrupuleusement les instructions 6-1. CABINET SECTION (SA-WCT100) chaque fois qu’un composant est remplacé et / ou réparé. not supplied not supplied not supplied not supplied...
Page 59: Front Panel Section (Sa-Wct100)
SA-WCT100/SS-MCT100 6-2. FRONT PANEL SECTION (SA-WCT100) not supplied not supplied not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-281-147-01 FRONT PANEL 2-588-799-01 FILTER (FL) 3-281-148-01 WINDOW...
Page 60: Amp Section (Sa-Wct100)
SA-WCT100/SS-MCT100 6-3. AMP SECTION (SA-WCT100) supplied with CN3008 not supplied supplied supplied not supplied not supplied not supplied M3001 not supplied CN3008 main section not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1-828-362-51 WIRE (FLAT TYPE) (19 CORE)
Page 61: Main Section (Sa-Wct100)
SA-WCT100/SS-MCT100 6-4. MAIN SECTION (SA-WCT100) not supplied not supplied not supplied F901 not supplied not supplied not supplied not supplied not supplied (SPOUT board) not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No.
Page 62 KEY HOLE SEALED CAP 4-986-971-02 SCREW (3.5) 1-826-832-11 LOUD SPEAKER (4X7 cm) 1-834-923-11 CORD (WITH CONNECTOR) 1-826-832-11 LOUD SPEAKER (4X7 cm) (for SA-WCT100 connection) 3-287-022-01 CUSHION (REMOTE PWB) 1-826-832-11 LOUD SPEAKER (4X7 cm) 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 3-279-902-01 FOOT (8pieces, 1set)
Page 63 Replace only with part number speciﬁ ed. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1441-738-A DISPLAY BOARD, COMPLETE (SA-WCT100) D806 6-501-736-01 DIODE MAZ8062G0LS0 *********************** < IC > 4-921-941-01 CUSHION (FL) IC802 6-705-899-01 IC ML9208-03MBZ03B <...
Page 64 SA-WCT100/SS-MCT100 HDMI Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1441-922-A HDMI BOARD, COMPLETE (for SERVICE) C3564 1-107-826-11 CERAMIC CHIP 0.1uF (SA-WCT100) C3566 1-107-826-11 CERAMIC CHIP 0.1uF ********************* C3567 1-107-826-11 CERAMIC CHIP 0.1uF C3568 1-107-826-11 CERAMIC CHIP 0.1uF <...
Page 65 SA-WCT100/SS-MCT100 HDMI Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < FERRITE BEAD > R3544 1-216-805-11 METAL CHIP 1/10W R3545 1-216-805-11 METAL CHIP 1/10W FB3501 1-414-234-22 INDUCTOR, FERRITE BEAD FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD R3546 1-216-857-11...
Page 66 (INPUT DMPORT) R3799 1-216-805-11 METAL CHIP 1/10W < IC > < COMPOSITION CIRCUIT BLOCK > IC201 6-600-466-01 IC TORX147L (SONY) (INPUT SAT OPT) * RB3501 1-234-723-11 RES, NETWORK 75 (1005X4) IC202 6-600-466-01 IC TORX147L (SONY) (INPUT DVD OPT) * RB3502 1-234-723-11...
Page 67 R260 1-216-825-11 METAL CHIP 2.2K 1/10W ************************************************************* L200 1-414-754-11 INDUCTOR 10uH L201 1-414-406-41 INDUCTOR 220uH A-1441-736-A MAIN BOARD, COMPLETE (SA-WCT100) ********************* < TRANSISTOR > < CAPACITOR > Q201 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q202 8-729-027-43 TRANSISTOR DTC114EKA-T146 C001 1-117-681-11 ELECT CHIP 100uF 1-107-826-11 CERAMIC CHIP 0.1uF...
Page 68 SA-WCT100/SS-MCT100 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C1003 1-107-826-11 CERAMIC CHIP 0.1uF C3004 1-126-960-11 ELECT C1004 1-107-826-11 CERAMIC CHIP 0.1uF C3005 1-126-200-11 ELECT CHIP 10uF C1005 1-107-826-11 CERAMIC CHIP 0.1uF C3011 1-128-994-21 ELECT CHIP...
Page 69 SA-WCT100/SS-MCT100 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C3159 1-137-198-81 FILM C3586 1-162-964-11 CERAMIC CHIP 0.001uF C3160 1-137-198-81 FILM C3587 1-162-964-11 CERAMIC CHIP 0.001uF C3161 1-137-198-81 FILM C3588 1-162-964-11 CERAMIC CHIP 0.001uF C3162 1-137-198-81...
Page 70 SA-WCT100/SS-MCT100 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark IC783 6-704-099-01 IC TC7WZ08FK (TE85R) IC1001 6-705-308-01 IC SI-3010KM-TL Q3302 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF Q3401 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF IC1002 6-807-911-01 IC M30626MJP-A16FPU0 Q3402 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF IC1006...
Page 71 SA-WCT100/SS-MCT100 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R1012 1-216-821-11 METAL CHIP 1/10W R1083 1-216-813-11 METAL CHIP 1/10W R1013 1-216-833-11 METAL CHIP 1/10W R1085 1-216-821-11 METAL CHIP 1/10W R1014 1-216-809-11 METAL CHIP 1/10W R1086...
Page 72 R3073 1-216-809-11 METAL CHIP 1/10W ************************************************************* R3074 1-216-809-11 METAL CHIP 1/10W R3076 1-216-809-11 METAL CHIP 1/10W A-1441-743-A POWER BOARD, COMPLETE (SA-WCT100) *********************** R3098 1-216-833-11 METAL CHIP 1/10W R3101 1-216-809-11 METAL CHIP 1/10W 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 R3102 1-216-809-11...
Page 73 SA-WCT100/SS-MCT100 POWER Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0 C918 0 D926 1-113-925-51 CERAMIC 0.01uF 250V 6-501-174-01 DIODE UDZW-TE17-10B 0 C920 1-113-925-51 CERAMIC 0.01uF 250V D931 6-501-413-01 DIODE FCU20UC20 0 C922 1-128-560-91 ELECT 22uF...
Page 74: Spout Board (Sa-Wct100)
METAL CHIP 1/10W L252 1-457-078-11 AIR-CORE COIL R955 1-216-817-11 METAL CHIP 1/10W ************************************************************* R956 1-216-821-11 METAL CHIP 1/10W A-1441-739-A TSW BOARD, COMPLETE (SA-WCT100) R965 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W ******************** R966 1-216-821-11 METAL CHIP 1/10W < CAPACITOR > R967 1-216-821-11...
Page 75 (for SA-WCT100 connection) 0 F901 1-576-537-12 FUSE, GLASS TUBE (DIA.5) (8A/125V) M3001 1-787-396-11 D.C. FAN (50 SQUARE) 1-826-943-11 LOUDSPEAKER (16 cm) (SA-WCT100) 1-826-832-11 LOUD SPEAKER (4X7 cm) (SS-WCT100) 1-826-832-11 LOUD SPEAKER (4X7 cm) (SS-WCT100) 1-826-832-11 LOUD SPEAKER (4X7 cm) (SS-WCT100)
Page 76: Revision History
SA-WCT100/SS-MCT100 REVISION HISTORY Checking the version allows you to jump to the revised page. Also, clicking the version at the top of the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2008.02...
