HP Kayak XM600 Series 1
Desktop PC Workstations
Look at the label on the side or rear of the PC Workstation:
Identified as
Product numbers
This chapter deals exclusively with the XM600 Series 1.
Medium-Profile
Desktop
PC Workstations
XM600 Series 1 or Series 2?
XM600 Series 1
"Kayak XM600"
Any Dxxxx
PxxxxN up to P2189N
PxxxxT up to P2189T
XM 600 Series 2
"Kayak XM600 Series 2"
P2190N or higher
P2190T or higher
HP Kayak XM600 Series 1 Desktop PC
1
Workstations 1-1
1
Advertisement
Table of Contents
Related Manuals for HP XM600 - Kayak - 128 MB RAM
Summary of Contents for HP XM600 - Kayak - 128 MB RAM
- Page 1 HP Kayak XM600 Series 1 Desktop PC Workstations XM600 Series 1 or Series 2? Look at the label on the side or rear of the PC Workstation: XM600 Series 1 XM 600 Series 2 Identified as “Kayak XM600” “Kayak XM600 Series 2” Any Dxxxx P2190N or higher Product numbers...
-
Page 2: Models And Accessories
HP Kayak XM600 Series 1 Desktop PC Workstations Models and Accessories Product Cache Std. Hard Video Multi-media Number Memory Drive Controller HP Kayak XM600 7/xxx PC Workstation HP Kayak XM600 500 MHz - 100 MHz FSB (CPL: 01/2000 ) ® D9531N Pentium 128 MB... - Page 3 HP Kayak XM600 Series 1 Desktop PC Workstations Product Cache Std. Hard Video Multi-media Number Memory Drive Controller HP Kayak XM600 600 MHz -133 MHz FSB (CPL: 01/2000 ) D9538N Pentium 128 MB 15 GB Matrox 48 IDE 10/100 III with SDRAM Ultra Millennium...
- Page 4 HP Kayak XM600 Series 1 Desktop PC Workstations Product Cache Std. Hard Video Multi-media Number Memory Drive Controller HP Kayak XM600 667 MHz -133 MHz FSB (CPL: 01/2000 ) D9548N Pentium 128 MB 15 GB Matrox 48 IDE 10/100 III with SDRAM Ultra Millennium...
- Page 5 HP Kayak XM600 Series 1 Desktop PC Workstations Product Cache Std. Hard Video Multi-media Number Memory Drive Controller HP Kayak XM600 733 MHz -133 MHz FSB (CPL: 01/2000 ) D9558N Pentium 128 MB 15 GB Matrox 48 IDE 10/100 III with SDRAM Ultra Millennium...
- Page 6 HP Kayak XM600 Series 1 Desktop PC Workstations Product Cache Std. Hard Video Multi-media Number Memory Drive Controller HP Kayak XM600 (CPL: 01/2000 ) D8488AV V-Exp Base Model IDE D8808AV V-Exp Base Model SCSI Unless otherwise mentioned, the operating system for the HP Kayak XM600 Desktop PC Workstations is Windows NT4.0 FSB = Front Side Bus HP Kayak XM600 Desktop PC Workstation supplied with a MS-DOS operating system.
-
Page 7: Supported Accessories
HP Kayak XM600 Series 1 Desktop PC Workstations Supported Accessories Memory Upgrades RDRAM 64 MB PC700 non-ECC main memory D9500A RDRAM 128 MB PC700 non-ECC main memory D9502A RDRAM 256 MB PC700 non-ECC main memory D9503A RDRAM 64 MB PC800 ECC main memory D9504A RDRAM 128 MB PC800 ECC main memory D9506A... - Page 8 HP Kayak XM600 Series 1 Desktop PC Workstations Input Devices ® HP Windows keyboard C4735A HP multimedia keyboard C4742A HP standard 2-button mini-din mouse C3751B HP mouse with scrolling wheel C4736A HP cordless scrolling mouse C4740A Security HP Master Pass Key System kit D6655B HP Master Pass Key D6658B...
-
Page 9: System Board Connectors, Bios, And Memory
HP Kayak XM600 Series 1 Desktop PC Workstations System Board Connectors, BIOS, and Memory Mouse (upper) & Keyboard (lower) AUX Power Processor 1 Connector Power Two USB CPU FAN 1 Serial Port A Serial Port B Primary IDE Processor 2 Connector (Both ports are Secondary IDE stacked with the... -
Page 10: System Board Switches
HP Kayak XM600 Series 1 Desktop PC Workstations System Board Switches Switch Default Function Reserved 1-5. Do Not Change Default Settings. Disables keyboard power-on. Enables keyboard power-on. Enables normal mode. Enables the BIOS recovery mode at next boot. Retains CMOS memory. Clears CMOS memory at next boot. -
Page 11: Main Memory
HP Kayak XM600 Series 1 Desktop PC Workstations Installing a Dual Processor / Replacing a Processor HP Kayak XM600 Desktop PC Workstations are supplied with a Pentium III processor and an integrated VRM (Voltage Regulator Module) on the system board. A separate VRM is not required. Single processor models can be upgraded to dual processor systems by installing a second processor accessory in the vacant processor slot. - Page 12 HP Kayak XM600 Series 1 Desktop PC Workstations The SDRAM Memory Expansion Card socket always contains a “RDRAM Terminator Module”. Second RIMM module, or RDRAM Continuity Module if unused First RIMM module Processor 2, or processor RDRAM terminator card if unused Terminator Module Processor 1 System board edge...
-
Page 13: Parts And Part Numbers
HP Kayak XM600 Series 1 Desktop PC Workstations Parts and Part Numbers Medium-Profile HP Kayak XM600 Series 1 Desktop PC Desktop Workstations 1-13 PC Workstations... - Page 14 HP Kayak XM600 Series 1 Desktop PC Workstations Parts List Item Description Replacement Exchange Part Number Part Number Chassis assembly: 5065-0420 — Front Bezel assembly (includes status 5065-0421 — panel) Fan assembly 5065-0424 — Top cover assembly 5065-0426 — Hard disk drive and speaker assembly 5065-0427 —...
- Page 15 HP Kayak XM600 Series 1 Desktop PC Workstations Parts List Item Description Replacement Exchange Part Number Part Number Available Parts that are not shown in the graphic on page 13. Floppy disk drive (1.44) D2035-60293 — Ultra 2 SCSI card (Symbios 8952U) 5064-7466 —...
- Page 16 HP Kayak XM600 Series 1 Desktop PC Workstations Parts List Item Description Replacement Exchange Part Number Part Number Standard Keyboard C4739-601xx — Multimedia keyboard C4742-601xx — CR2032 battery (3V) 1420-0356 — All models shipped with SDRAM memory should be converted to RDRAM memory. Consult HP Support for further information.
- Page 17 HP Kayak XM600 Series 1 Desktop PC Workstations System Board Parts List Description Repl. Exchange Part Part Number Number System board: XM600 Series 1 system board D8350-63002 D8350-69002 Processors (Slot): Intel Pentium III 500 MHz, 100 MHz FSB, 512 KB cache D7947-63001 D7947-69001 Intel Pentium III 533EB MHz, 133 MHz FSB, 256 KB cache D9026-63001...
- Page 18 HP Kayak XM600 Series 1 Desktop PC Workstations Notes: _____________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ 1-18 HP Kayak XM600 Series 1 Desktop PC Medium-Profile Workstations Desktop PC Workstations...
