P D
LACING A ISPATCH
1 Select the desired zone and group ID using the Zone and CH/GID keys.
2 Press and hold the PTT switch.
3 If the "PTT Proceed" tone sounds, communication is possible; start speaking
into the microphone. Release the PTT switch to receive.
• For best sound quality at the receiving station, hold the microphone approximately
1.5 inches (3 ~ 4 cm) from your mouth.
• Your dealer can deactivate the PTT Proceed tone, if necessary. Ask your dealer
for details.
R D
ECEIVING A ISPATCH
1 When a dispatch call is received, the transceiver will automatically change to
the correct group ID and you will hear the call.
2 Readjust the volume as necessary, using the Volume keys.
P T
LACING A ELEPHONE
1 Select the desired zone and group ID using the Zone and CH/GID keys.
• Alternatively, you can press the key programmed as Auto Telephone to
automatically search for a Telephone Repeater.
2 Press and hold the PTT switch for approximately 1 second to ensure a
connection.
• Confirm that there is a dial tone after you release the PTT switch.
3 Place the call, following the instructions for making a DTMF call {page 19}.
4 When the called party responds, press the PTT switch and speak into the
microphone. Release the PTT switch to receive.
• Only one person can speak at a time.
5 To end the call, press and hold the PTT switch, then press the DTMF # key or
the key programmed as Telephone Disconnect.
R T
ECEIVING A ELEPHONE
1 When a telephone call is received, the transceiver will automatically change
to the correct group ID and you will hear the call.
• A ringer tone will sound when a call is received.
2 Press and hold the PTT switch to speak, and release it to receive.
• Only one person can speak at a time.
3 To end the call, press and hold the PTT switch, then press the DTMF # key or
the key programmed as Telephone Disconnect.

TRUNKING ZONES

C
ALL
C
ALL
C
ALL
C
ALL
11
